LIA 0608HXCF M
LIA 0911HXCF M
LIA 1316HXCF
LIA 1316HXCF M
Installation and
Operating Instruction
Split air-to-water heat
pump with Hydrobox
Order no.: 452172.66.05-EN
LIA 0608HXCF M
LIA 0911HXCF M
LIA 1316HXCF (M)
Glen
Dimplex
Deutschland
Dimplex
EN · FD 0306

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIA 0608HXCF M and is the answer not in the manual?

Questions and answers

Related Manuals for Dimplex LIA 0608HXCF M

Summary of Contents for Dimplex LIA 0608HXCF M

  • Page 1 Glen Dimplex Deutschland Dimplex LIA 0608HXCF M LIA 0911HXCF M LIA 1316HXCF LIA 1316HXCF M LIA 0911HXCF M LIA 1316HXCF (M) LIA 0608HXCF M Installation and Operating Instruction Split air-to-water heat pump with Hydrobox Order no.: 452172.66.05-EN EN · FD 0306...

  • Page 3: Table Of Contents

    11 Faults / troubleshooting ......................... EN-29 12 Decommissioning / disposal ......................... EN-29 13 Device information ..........................EN-30 14 Performance values..........................EN-34 14.1 Performance values, heating LIA 0608HXCF M ....................EN-34 14.2 Performance values, heating LIA 0911HXCF M ....................EN-35 www.dimplex.de 452172.66.05-EN · FD 0306...
  • Page 4 17.1 Operating limits diagram heating ..........................EN-48 17.2 Operating limits diagram cooling ..........................EN-49 18 Circuit diagrams ............................EN-50 18.1 Circuit diagram LIA 0608HXCF M / LIA 0911HXCF M ..................EN-50 18.2 Circuit diagram LIA 1316HXCF M 1-phase......................EN-51 18.3 Circuit diagram LIA 1316HXCF 3-phase....................... EN-52 18.4 Legend ....................................

  • Page 5: Safety Notes

    LIA 0608HXCF M - LIA 1316HXCF M English 1.3 General safety notes Safety notes CAUTION! 1.1 Symbols and markings Work on the heat pump must only be performed by authorised and qualified specialist personnel. Particularly important information in these instructions is marked with CAUTION! and NOTE.

  • Page 6: Legal Regulations And Directives

    English LIA 0608HXCF M - LIA 1316HXCF M 1.5 Legal regulations and directives Purpose This heat pump is designed for use in a domestic environment 2.1 Area of application according to Article 1, Paragraph 2 k) of EU directive 2006/42/...

  • Page 7: Scope Of Supply

    LIA 0608HXCF M - LIA 1316HXCF M English 3.3 Outdoor unit Scope of supply 3.3.1 6 kW outdoor unit 3.1 Indoor unit 3.3.2 10 kW / 14 kW outdoor unit Hydraulic components  Unmixed heating circuit including controlled circulating pump 2nd heat generator, electrical pipe heater, heat output 2 / ...

  • Page 8: Transport And Storage

    English LIA 0608HXCF M - LIA 1316HXCF M 4.1 Removing transport fastening Transport and storage (depending on the device) During transport and storage, the unit must be kept in a dry place and must not be exposed to temperatures below freez- After transportation, the transport fastening in the device is to ing.

  • Page 9: Installation

    LIA 0608HXCF M - LIA 1316HXCF M English 5.2 Outdoor unit Installation  It is advisable to install the outdoor unit close to a wall, on a 5.1 Indoor unit foundation separate from the building with a minimum clearance of 0.3 m on the intake side (Fig. 5.1 + Fig. 5.2).
  • Page 10 English LIA 0608HXCF M - LIA 1316HXCF M 5.2.1 Wall opening, split lines and electric Wall or obstacle wires Air inlet Maintenance Please proceed as follows when laying split lines and electric area >300 wires: Drill a 70 mm opening for the pipework using a core drill.

  • Page 11: Heat Pump Installation Conditions

    LIA 0608HXCF M - LIA 1316HXCF M English 5.3 Heat pump installation 5.3.2 Minimum installation space requirements: conditions: The heat pump described in this manual is a refrigerant-filled The refrigerating system described in this manual is filled with device that must be installed in accordance with the require- R32.
  • Page 12 English LIA 0608HXCF M - LIA 1316HXCF M 5.3.3 Toxicity and flammability limit values: stallation conditions. It should be noted here that, in contrast to the toxicity limit value, this relates to the room area. If the refrigerant fill quantity is below 1.842 kg, the toxicity limit Calculation of the maximum permissible refrigerant fill quantity value is the determining factor for the installation conditions.

  • Page 13: Installation In Coastal Areas

    LIA 0608HXCF M - LIA 1316HXCF M English 5.4 Installation in coastal areas NOTE The use of heat pumps is safe from a distance of 12 km from If the unit is installed close to the sea, the high salt concentra- the sea with a maximum salt content of 3.5%...

  • Page 14: Assembly Indoor Unit

    English LIA 0608HXCF M - LIA 1316HXCF M Assembly indoor unit 6.1 General The following connections need to be established on the indoor unit (see “Dimension drawing indoor unit” on page 47.) Flow / return of the heating system ...

  • Page 15: Connection On Heating Side

    LIA 0608HXCF M - LIA 1316HXCF M English 6.4 Connection on heating side If necessary, for example in bivalent systems, the specifications listed in the table below must also be observed, or the precise The heating system connections on the indoor unit have a 1"...
  • Page 16 English LIA 0608HXCF M - LIA 1316HXCF M 6.5.2 Corrosion Saturation Index < -0.2 -0.2 - 0.1 The VDI 2035 recommends the use of partially demineralised water or demineralised water in systems with larger-than-aver- 0.1 - 0.2 age specific system volumes of 50 l/kW.

  • Page 17: Connecting The Pipework And Cables To The Outdoor Unit

    LIA 0608HXCF M - LIA 1316HXCF M English Minimum heating water flow rate Connecting the pipework The minimum heating water flow rate through the heat pump and cables to the outdoor must be assured in all operating statuses of the heating system.
  • Page 18 English LIA 0608HXCF M - LIA 1316HXCF M CAUTION! CAUTION! Only equipment and tools intended for the product, pressure Incorrect filling with refrigerant could lead to faults during and temperatures may be used for work on the unit. operation. CAUTION!
  • Page 19 LIA 0608HXCF M - LIA 1316HXCF M English 7.1.2 Preparation for pipework Step 5: Checks Compare the flanging with the figure.  The preparation of the pipework takes place in five steps. One If the flanging is visibly damaged, cut the relevant section ...

  • Page 20: Electrical Connections

    English LIA 0608HXCF M - LIA 1316HXCF M 7.2 Electrical connections Step 2: Fastening Align the centre of the pipes and tighten the screw nuts by  hand. 7.2.1 Outdoor unit Tighten the screw nuts with a spanner until they click.
  • Page 21 LIA 0608HXCF M - LIA 1316HXCF M English 7.2.2 Indoor unit Connecting electronically regulated circulating pumps Two supply cables must be connected to the indoor unit: The Electronically regulated circulating pumps may have high start- power supply for the electric heating element and the control ing currents, which may reduce the service life of the heat voltage for the integrated heat pump manager.

  • Page 22: Final Work

    English LIA 0608HXCF M - LIA 1316HXCF M 7.3 Final work Once the pipes and electric cables have been connected, the pipes must be bent and a leak test must be carried out. The leak Seal small gaps around test must be carried out with particular care, as a refrigerant the pipe, e.g.
  • Page 23 LIA 0608HXCF M - LIA 1316HXCF M English 7.4.2 Leakage tightness test 7.4.3 Evacuation Connect the multi-way valve (with pressure gauges) and Connect the end of the filling hose mentioned above to the  dry nitrogen gas cylinder with the filling hoses on this vacuum pump to pump the pipework and indoor unit maintenance connection.

  • Page 24: Commissioning

    English LIA 0608HXCF M - LIA 1316HXCF M Special notes for the integration of heat pumps in Commissioning existing systems (renovations): The existing heat distribution network (pipe materials, connec- 8.1 General tion types, etc.) and the existing heating systems (e.g. radiators, underfloor heating, etc.) can impact the quality of the water in...

  • Page 25: Commissioning Procedure

    LIA 0608HXCF M - LIA 1316HXCF M English 8.3 Commissioning procedure At heating water temperatures under 7 °C, commissioning is not possible. The water in the buffer tank must be heated with The heat pump is commissioned via the heat pump manager.

  • Page 26: Test Points, Maintenance And Troubleshooting

    English LIA 0608HXCF M - LIA 1316HXCF M CAUTION! Test points, maintenance Always wear adequate personal protective equipment and troubleshooting (protective gloves, safety glasses, etc.) when working with refrigerant. If no faults have occurred up to this point, the unit can now be put into operation.

  • Page 27: Maintenance

    LIA 0608HXCF M - LIA 1316HXCF M English 9.2 Maintenance CAUTION! For cleaning and maintenance, especially when removing To maintain an optimal output on the split heat pump, regular covers, the entire system must be disconnected from the checks and maintenance work should be carried out on the power supply beforehand.

  • Page 28: Troubleshooting

    English LIA 0608HXCF M - LIA 1316HXCF M 9.3 Troubleshooting CAUTION! Before opening the device, ensure that all electric circuits are If the split heat pump is experiencing problems during opera- disconnected from the power supply. tion or is not working at all, check the following points.

  • Page 29: Characteristic Curve Temperature Sensor Outdoor Unit

    LIA 0608HXCF M - LIA 1316HXCF M English If the system needs to be completely refilled due to a fault or Evacuate the system and make sure that there is no oxygen leakage, please proceed as follows: or nitrogen in the pipe system.

  • Page 30: Characteristic Curve Temperature Sensor Indoor Unit

    English LIA 0608HXCF M - LIA 1316HXCF M 9.5 Characteristic curve 9.5.2 Mounting the outside temperature sensor temperature sensor indoor unit The outside temperature is measured via the heat source inlet sensor on the outdoor unit. Optionally, a separate outdoor tem- 9.5.1 Sensor characteristic curves...

  • Page 31: Cleaning / Maintenance

    LIA 0608HXCF M - LIA 1316HXCF M English 10 Cleaning / maintenance 11 Faults / troubleshooting This heat pump is a quality product and is designed for trouble- 10.1 Care free operation. Should a fault occur, however, it will be indi- cated on the heat pump manager display.

  • Page 32: Device Information

    English LIA 0608HXCF M - LIA 1316HXCF M 13 Device information Type and order code LIA 0608HXCF M LIA 0911HXCF M Design Heat source Version Split reversible Split reversible Controller WPM Touch WPM Touch Thermal energy metering Installation location Indoors/outdoors...
  • Page 33 LIA 0608HXCF M - LIA 1316HXCF M English Electrical connection Supply voltage / fusing Outdoor unit 1~/N/PE 230 V (50 Hz) / C20A 1~/N/PE 230 V (50 Hz) / C20A Indoor unit 1~/N/PE 230 V (50 Hz) / B32A 1~/N/PE 230 V (50 Hz) / B32A...
  • Page 34 English LIA 0608HXCF M - LIA 1316HXCF M Type and order code LIA 1316HXCF M LIA 1316HXCF Design Heat source Version Split reversible Split reversible Controller WPM Touch WPM Touch Thermal energy metering Installation location Indoors/outdoors Indoors/outdoors Performance level Variable...
  • Page 35 LIA 0608HXCF M - LIA 1316HXCF M English Electrical connection Supply voltage / fusing Outdoor unit 1~/N/PE 230 V (50 Hz) / C32A 3~/N/PE 400 V (50 Hz) / C16A Indoor unit 1~/N/PE 230 V (50 Hz) / B32A 1~/N/PE 230 V (50 Hz) / B32A...

  • Page 36: Performance Values

    English LIA 0608HXCF M - LIA 1316HXCF M 14 Performance values 14.1 Performance values, heating LIA 0608HXCF M Maximum 2.57 1.49 1.72 2.25 1.53 1.46 2.14 1.67 1.28 1.91 1.64 1.17 1.71 1.57 1.09 3.64 1.56 2.34 3.34 1.86 1.80 2.88...

  • Page 37: Performance Values, Heating Lia 0911Hxcf M

    LIA 0608HXCF M - LIA 1316HXCF M English 14.2 Performance values, heating LIA 0911HXCF M Maximum 4.68 2.06 2.27 4.21 2.12 1.98 3.78 2.28 1.66 3.52 2.24 1.57 2.96 2.26 1.31 5.98 2.12 2.82 5.35 2.24 2.39 4.98 2.34 2.13 4.55...

  • Page 38: Performance Values, Heating Lia 1316Hxcf (M

    English LIA 0608HXCF M - LIA 1316HXCF M 14.3 Performance values, heating LIA 1316HXCF (M) Maximum 6.60 3.09 2.14 6.76 3.20 2.11 5.43 3.18 1.71 4.89 3.35 1.46 4.47 3.47 1.29 8.26 3.22 2.57 8.30 3.30 2.52 7.79 3.58 2.18 6.89...

  • Page 39: Performance Values, Cooling Lia 0608Hxcf M

    LIA 0608HXCF M - LIA 1316HXCF M English 14.4 Performance values, cooling LIA 0608HXCF M Maximum 5.27 0.59 8.93 6.38 0.55 11.53 6.77 0.64 10.62 5.05 0.69 7.28 6.16 0.66 9.39 6.55 0.74 8.85 4.55 0.79 5.74 5.66 0.76 7.48 6.05...

  • Page 40: Performance Values, Cooling Lia 0911Hxcf M

    English LIA 0608HXCF M - LIA 1316HXCF M 14.5 Performance values, cooling LIA 0911HXCF M Maximum 6.83 0.69 9.92 8.79 0.82 10.66 9.35 0.77 12.13 6.61 0.77 8.56 7.76 0.81 9.61 8.30 0.76 10.88 6.38 0.89 7.19 6.74 0.79 8.56 7.25...

  • Page 41: Performance Values, Cooling Lia 1316Hxcf (M

    LIA 0608HXCF M - LIA 1316HXCF M English 14.6 Performance values, cooling LIA 1316HXCF (M) Maximum 10.0 1.32 7.57 10.9 1.47 7.44 12.0 1.42 8.43 9.80 1.67 5.87 11.4 1.58 7.24 12.5 1.59 7.84 9.57 1.76 5.44 12.0 1.61 7.43 13.0...

  • Page 42: Product Information As Per Regulation (Eu) No 813/2013, Annex Ii, Table 2

    Regulation (EU) No 813/ 2013, Annex II, Table 2 Information requirements for heat pump space heaters and heat pump combination heaters Model Dimplex LIA 0608HXCF M (LIA 0608 M + LIA HX) Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump...
  • Page 43 LIA 0608HXCF M - LIA 1316HXCF M English Information requirements for heat pump space heaters and heat pump combination heaters Model Dimplex LIA 0911HXCF M (LIA 0911 M + LIA HX) Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump...
  • Page 44 Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ).
  • Page 45 LIA 0608HXCF M - LIA 1316HXCF M English Information requirements for heat pump space heaters and heat pump combination heaters Model Dimplex LIA 1316HXCF M (LIA 1316 M + LIA HX14) Air-to-water heat pump Water-to-water heat pump Brine-to-water heat pump...

  • Page 46: Dimension Drawings

    English LIA 0608HXCF M - LIA 1316HXCF M 16 Dimension drawings 16.1 Dimension drawing outdoor unit LIA 0608HXCF M 1008 EN-44 452172.66.05-EN · FD 0306 www.dimplex.de...

  • Page 47: Dimension Drawing Outdoor Unit Lia 0911Hxcf M / Lia 1316Hxcf M / Lia 1316Hxcf

    LIA 0608HXCF M - LIA 1316HXCF M English 16.2 Dimension drawing outdoor unit LIA 0911HXCF M / LIA 1316HXCF M / LIA 1316HXCF 1118 www.dimplex.de 452172.66.05-EN · FD 0306 EN-45...

  • Page 48: Foundation Plan Lia 0608Hxcf M

    English LIA 0608HXCF M - LIA 1316HXCF M 16.3 Foundation plan LIA 0608HXCF M Foundation > 80 ca. 1000 16.4 Foundation plan LIA 0911HWCF M / LIA 1316HXCF M / LIA 1316HXCF Foundation > 80 ca. 1110 EN-46 452172.66.05-EN · FD 0306...

  • Page 49: Dimension Drawing Indoor Unit

    LIA 0608HXCF M - LIA 1316HXCF M English 16.5 Dimension drawing indoor unit www.dimplex.de 452172.66.05-EN · FD 0306 EN-47...

  • Page 50: Diagrams

    English LIA 0608HXCF M - LIA 1316HXCF M 17 Diagrams 17.1 Operating limits diagram heating Heat source inlet temperature [°C] EN-48 452172.66.05-EN · FD 0306 www.dimplex.de...

  • Page 51: Operating Limits Diagram Cooling

    LIA 0608HXCF M - LIA 1316HXCF M English 17.2 Operating limits diagram cooling Heatsink inlet temperature [°C] www.dimplex.de 452172.66.05-EN · FD 0306 EN-49...

  • Page 52: Circuit Diagrams

    English LIA 0608HXCF M - LIA 1316HXCF M 18 Circuit diagrams 18.1 Circuit diagram LIA 0608HXCF M / LIA 0911HXCF M FACTORY SETTINGS blue black PCB A, Inverter board for 1-phase brown blue blue brown PCB B, Main control board...

  • Page 53: Circuit Diagram Lia 1316Hxcf M 1-Phase

    LIA 0608HXCF M - LIA 1316HXCF M English 18.2 Circuit diagram LIA 1316HXCF M 1-phase FACTORY SETTINGS blue PCB A, Inverter board black for 1-phase blue brown blue brown PCB B, Main control board for 1-ph brown brown To heater band...

  • Page 54: Circuit Diagram Lia 1316Hxcf 3-Phase

    English LIA 0608HXCF M - LIA 1316HXCF M 18.3 Circuit diagram LIA 1316HXCF 3-phase black black black brown brown brown grey Inverter board grey Ferrite core grey black Ferrite core blue white black Address Ferrite core grey brown black To heater...

  • Page 55: Legend

    LIA 0608HXCF M - LIA 1316HXCF M English 18.4 Legend Inverter board for 3-phase Input connection P_in for IPM module PCB A, inverter board for 1-phase Communication connection for PCB C Connection for fan CN19 Input connection P_out for IPM module...
  • Page 56 English LIA 0608HXCF M - LIA 1316HXCF M Communication connection for power meter CN26 Connection for 2-way valve 6 CN27 Communication connection for XYE CN28 Connection for low pressure switch and quick check CN29 Connection for fan 15 VDC power supply...

  • Page 57: Hydraulic Integration Diagrams

    LIA 0608HXCF M - LIA 1316HXCF M English 19 Hydraulic integration diagrams 19.1 Mono energy system with one heating circuit NOTE The hydraulic integration diagram is an example and intended only as an aid. The system requires professional and safety- approved layout by a specialist planner.

  • Page 58: Mono Energy System With One Heating Circuit And Domestic Hot Water Preparation

    English LIA 0608HXCF M - LIA 1316HXCF M 19.2 Mono energy system with one heating circuit and domestic hot water preparation NOTE The hydraulic integration diagram is an example and intended only as an aid. The system requires professional and safety- approved layout by a specialist planner.

  • Page 59: Legend

    LIA 0608HXCF M - LIA 1316HXCF M English 19.3 Legend Isolating valve Overflow valve Check valve Circulating pump Room-temperature controlled valve Isolating valve with check valve Heat consumer Temperature sensor Three-way mixer Dirt trap Outdoor unit Indoor unit Buffer tank...

  • Page 60: Declaration Of Conformity

    English LIA 0608HXCF M - LIA 1316HXCF M 20 Declaration of conformity You can find the current CE declaration of conformity to down- load https://dimplex.de/lia0608hxcfm https://dimplex.de/lia0911hxcfm https://dimplex.de/lia1316hxcf https://dimplex.de/lia1316hxcfm EN-58 452172.66.05-EN · FD 0306 www.dimplex.de...
  • Page 61 LIA 0608HXCF M - LIA 1316HXCF M English www.dimplex.de 452172.66.05-EN · FD 0306 EN-59...
  • Page 62 English LIA 0608HXCF M - LIA 1316HXCF M EN-60 452172.66.05-EN · FD 0306 www.dimplex.de...
  • Page 63 LIA 0608HXCF M - LIA 1316HXCF M English www.dimplex.de 452172.66.05-EN · FD 0306 EN-61...
  • Page 64 Glen Dimplex Deutschland On site service Head office After-sales service, technical support and Glen Dimplex Deutschland GmbH spare partsl. Assistance before and Am Goldenen Feld 18 after installation of your equipment D-95326 Kulmbach T +49 9221 709-545 T +49 9221 709-101...
