Dimplex M Flex 0609HBC M Installation And Operating Instruction

Dimplex M Flex 0609HBC M Installation And Operating Instruction

Air-to-water heat pump in integral design
Hide thumbs

Advertisement

Quick Links

Download this manual
M Flex 0609HBC M
M Flex 0916HBC
M Flex 0916HBC M
Installation and
Operating Instruction
Air-to-water
heat pump
in integral design
Order no.: DOK4x HCIAO FxDEN
Glen
Dimplex
Deutschland
Dimplex
EN · FD 0206

Advertisement

loading
Need help?

Need help?

Do you have a question about the M Flex 0609HBC M and is the answer not in the manual?

Questions and answers

Related Manuals for Dimplex M Flex 0609HBC M

Summary of Contents for Dimplex M Flex 0609HBC M

  • Page 1 Glen Dimplex Deutschland Dimplex M Flex 0609HBC M M Flex 0916HBC M Flex 0916HBC M Installation and Operating Instruction Air-to-water heat pump in integral design Order no.: DOK4x HCIAO FxDEN EN · FD 0206...
  • Page 2 Subject to alterations and errors.
  • Page 3 Air-to-water heat pump M Flex with cooling English Table of contens Safety notes.................................3 1.1 Symbols and markings ................................3 1.2 Intended use..................................... 3 1.3 Legal regulations and directives ............................3 1.4 Energy-efficient use of the heat pump..........................3 Intended use of the heat pump ........................4 2.1 Area of application..................................
  • Page 4 13 Diagrams ................................29 13.1 Characteristic curve heating M Flex 0609HBC M......................29 13.2 Operating limits diagram cooling M Flex 0609HBC M.....................31 13.3 Characteristic curve heating M Flex 0916HBC/M Flex 0916HBC M..............32 13.4 Characteristic curves for cooling operation M Flex 0916HBC / M Flex 0916HBC M ........34 14 Product information as per Regulation (EU) No 813/2013, Annex II, Table 2 ........
  • Page 5 Air-to-water heat pump M Flex with cooling English Safety notes 1.1 Symbols and markings When connecting the heating system, all country-specific reg- ulations must also be adhered to. Particularly important information in these instructions is This unit can be used by children aged 8 and over and by per- marked with CAUTION! and NOTE.
  • Page 6 English Air-to-water heat pump M Flex with cooling Intended use of the heat pump 2.1 Area of application 2.2 Operating principle The air-to-water heat pump is to be used exclusively for heating Heating and cooling of heating water and domestic hot water. It can be Surrounding air is drawn in by the fan and fed through the evap- used in new or existing heating systems.
  • Page 7 Air-to-water heat pump M Flex with cooling English Scope of supply 3.1 Indoor unit Hydraulic systems (including a dual differential pressureless manifold) 50 l buffer tank Actuator for 3-way reversing valve Refrigeration circuit 3-way reversing valve for generating domestic hot water 10) Heat exchanger refrigerant / heating water Regulated auxiliary circulating pump 11) Compressor...
  • Page 8 English Air-to-water heat pump M Flex with cooling 3.2 Outdoor unit Evaporator Expansion valve Switch box Connection for refrigerant line DOK4x HCIAO FxDEN · FD 0206 www.glendimplex.de...
  • Page 9 Air-to-water heat pump M Flex with cooling English Transport 4.1 Outdoor unit The casing panels must be dismantled in the order outlined be- low. A pallet should be used to transport the heat pump to its final The right side panel must be removed first. For this, loosen the installation location.
  • Page 10 English Air-to-water heat pump M Flex with cooling After the final positioning at the installation location, remove the transport fastening on the sprung floor of the compressor on both sides. ATTENTION! Before commissioning, the transport fastening must be re- moved. DOK4x HCIAO FxDEN ·...
  • Page 11 Air-to-water heat pump M Flex with cooling English Positioning 5.1 Outdoor unit Ensure that the cold expelled air is not sucked in again. HINWEIS NOTE Among other things, when selecting the installation locations for the indoor and outdoor units, ensure that the required Do not restrict or block the area around the intake or the air length of refrigerant line is as short as possible.
  • Page 12 (Tab. C.3) Both parts must be installed so that maintenance work can be M Flex 0609HBC M 3.80 kg R410A 0.39 kg/m³ 9.7 m³ carried out without hindrance. This can be ensured by main- taining a clearance of approx. 1 m in front of and to the right of M Flex 0916HBC (M) 4.78 kg R410A...
  • Page 13 Air-to-water heat pump M Flex with cooling English Assembly / connection 6.1 Assembly of the refrigerant line heating operation (pos. 1 factory default). Fill the heating sys- tem at the fill and drain cock (pos. 2) until system pressure (ap- and electric wire prox.
  • Page 14 English Air-to-water heat pump M Flex with cooling Frost protection The following points must be observed when filling the system: Untreated filling water and make-up water must be of  A method of manual drainage should be provided for heat drinking water quality pumps which are exposed to frost.
  • Page 15 Air-to-water heat pump M Flex with cooling English 6.5 Temperature sensor connection The following temperature sensors are already installed or must be installed additionally:  Outside temperature (R1) is (NTC-2) Return temperature (R2) installed (NTC-10)  Demand sensor (R2.2) installed (NTC-10) ...
  • Page 16 English Air-to-water heat pump M Flex with cooling 6.6 Electrical connection 6.6.1 Electrical diagram (integration example) Symbol legend see cap. 6.6.2 on page 15 Equipment marking see cap. 6.6.3 on page 15 DOK4x HCIAO FxDEN · FD 0206 www.glendimplex.de...
  • Page 17 Air-to-water heat pump M Flex with cooling English 6.6.2 Symbol legend 6.6.3 Equipment markings +A100 Cooling circuit module Connector +A110 Outdoor unit +A200 Hydraulics /WPM Plug connection +A220 Expansion module WPM +A300 Electrical distribution system +A350 Router Compressor / refrigeration circuit +A400 Hydraulic installation (general) +A411...
  • Page 18 English Air-to-water heat pump M Flex with cooling 6.6.4 Electrical connection general  External sensor The external sensor (-R1) is connected to the adapter All connection cables must be provided on-site. The cable type board via the plug (grey [3]) "U1" in the hydraulic module (cross-section, conductor type, etc.) must be chosen taking switch box (+A200) into account the relevant electrical parameters (e.g.
  • Page 19 Air-to-water heat pump M Flex with cooling English 6.7 Hydraulic integration diagram 6.7.1 Hydraulic integration diagram (integration example) www.glendimplex.de DOK4x HCIAO FxDEN · FD 0206...
  • Page 20 English Air-to-water heat pump M Flex with cooling 6.7.2 Symbol legend Isolating valve Safety valve combination Circulating pump Room-temperature controlled valve Isolating valve with check valve Heat consumer temperature sensor Check valve Three-way mixer Four-way reversing valve Indoors Outdoors Domestic hot water DOK4x HCIAO FxDEN ·...
  • Page 21 M Flex 0609HBC M version. During the brazing process, the pipe system must be flushed 6.8.1 Requirements for the pipe length with an inert gas (e.g.
  • Page 22 English Air-to-water heat pump M Flex with cooling Step 3: Evacuation Connect the vacuum pump on the maintenance valve (with  Schrader). Run the vacuum pump until the relevant vacuum is  reached. An absolute pressure of at least 0.2 mbar must be achieved during evacuation.
  • Page 23 Air-to-water heat pump M Flex with cooling English Commissioning 7.1 General 7.3 Procedure To ensure that commissioning is performed correctly, it should The heat pump is commissioned via the touch display. See the only be carried out by an after-sales service technician author- “Operation”...
  • Page 24 English Air-to-water heat pump M Flex with cooling Cleaning / maintenance 8.1 Maintenance It is then important that the system be thoroughly flushed using appropriate neutralising agents to prevent any damage from To protect the paintwork, avoid leaning anything against the being caused by cleaning agent residue remaining in the sys- device or putting objects on the device.
  • Page 25 Air-to-water heat pump M Flex with cooling English Faults / troubleshooting This heat pump is a quality product and is designed for trouble- ATTENTION! free operation. In the event that a fault should occur, it will be Before opening the device, ensure that all circuits are discon- indicated on the touch display.
  • Page 26 English Air-to-water heat pump M Flex with cooling 11 Device information 11.1 Device information heat pump Type and order code M Flex 0609HBC M M Flex 0916HBC M M Flex 0916HBC Design Heat source Seasonal coefficient of performance (COP) average climate 35 °C / 55 °C...
  • Page 27 Air-to-water heat pump M Flex with cooling English Type and order code M Flex 0609HBC M M Flex 0916HBC M M Flex 0916HBC Electrical connection Supply voltage / fusing / RCD type 1~/N/PE 230 V (50 Hz) / 1~/N/PE 230 V (50 Hz) /...
  • Page 28 English Air-to-water heat pump M Flex with cooling 12 Dimension drawing 12.1 Dimension drawing outdoor unit DOK4x HCIAO FxDEN · FD 0206 www.glendimplex.de...
  • Page 29 Air-to-water heat pump M Flex with cooling English 12.2 Dimension drawing indoor unit www.glendimplex.de DOK4x HCIAO FxDEN · FD 0206...
  • Page 30 English Air-to-water heat pump M Flex with cooling 12.3 Dimension drawing legend Outdoor unit Connection refrigerant line 12 x1 mm outdoor unit Connection refrigerant line 18 x 1 mm outdoor unit Condensate drain Feedthrough refrigerant lines and electric wires; con- densate hose Optional feedthrough refrigerant line 18 mm Optional feedthrough electric wires 12 mm...
  • Page 31 Air-to-water heat pump M Flex with cooling English 13 Diagrams 13.1 Characteristic curve heating M Flex 0609HBC M Heizleistung in [kW] / Heating capacity in [kW] / Puissance de chauffage en [kW] EN 14511 A7 W35...30 0,8 m³/h A7 W45...40 0,8 m³/h max.
  • Page 32 English Air-to-water heat pump M Flex with cooling Heizleistung in [kW] / Heating capacity in [kW] / Puissance de chauffage en [kW] 35°C Heizwasseraustritt / water outlet / sortie del'eau Heizwasserdurchfluss / water flow rate / Débit d'eau de chau age 0,8 m³/h max.
  • Page 33 Air-to-water heat pump M Flex with cooling English 13.2 Operating limits diagram cooling M Flex 0609HBC M Wasserau (+/- 2 K) Water outlet (+/- 2 K) d'eau (+/- 2 K) Die Angaben gelten bei Einhaltung des geforderten Mindestkühlwasserdurchflusses. The values are valid for the specified minimum cooling water flow.
  • Page 34 English Air-to-water heat pump M Flex with cooling 13.3 Characteristic curve heating M Flex 0916HBC/ M Flex 0916HBC M Heizleistung in [kW] / Heating capacity in [kW] / Puissance de chauffage en [kW] EN 14511 A7 W35...30 1,2 m³/h A7 W45...40 1,2 m³/h A7 W55...47 0,8 m³/h max.
  • Page 35 Air-to-water heat pump M Flex with cooling English Heizleistung in [kW] / Heating capacity in [kW] / Puissance de chauffage en [kW] 35°C Heizwasseraustritt / water outlet / sortie del'eau 1,2 m³/h Heizwasserdurchfluss / water flow rate / Débit d'eau de chauffage max.
  • Page 36 English Air-to-water heat pump M Flex with cooling 13.4 Characteristic curves for cooling operation M Flex 0916HBC / M Flex 0916HBC M Kühlleistung in [kW] / Cooling capacity in [kW] / Puissance de refroidissement en [kW] EN 14511 A35 W18...23 1,6 m³/h max.
  • Page 37 Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ).
  • Page 38 Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ).
  • Page 39 Contact details Glen Dimplex Deutschland GmbH, Am Goldenen Feld 18, 95326 Kulmbach (*) For heat pump space heaters and heat pump combination heaters, the rated output Prated is equal to the design load for heating Pdesignh , and the rated heat output of a supplementary capacity for heating sup(Tj ).
  • Page 40 Based on the following conditions, we remedy defects on the unit the online order facility on the Internet (www.dimplex.de/garantiev- due to material and/or manufacturing defects free of charge, pro- erlaengerung).
  • Page 41 16 Information on the use of data IV. Information on products and new developments. It is very important to Glen Dimplex Thermal Solutions (GDTS) that your data is handled correctly. We should therefore like to GDTS will use your contact details on occasion to show you provide you with information on the data collected when oper- new products and innovations relating to smart homes.
  • Page 42 English Air-to-water heat pump M Flex with cooling 17 Declaration of conformity You can find and download the current CE conformity declaration at: https://glendimplex.de/m DOK4x HCIAO FxDEN · FD 0206 www.glendimplex.de...
  • Page 43 Air-to-water heat pump M Flex with cooling English www.glendimplex.de DOK4x HCIAO FxDEN · FD 0206...
  • Page 44 Glen Dimplex Deutschland Service and technical support Head office After-sales service, technical support Glen Dimplex Deutschland GmbH and spare parts Am Goldenen Feld 18 Assistance before and after installation D-95326 Kulmbach of your equipment T +49 9221 709-100 T +49 9221 709-545...
