EWM TIG 17 GD Operating Instructions Manual page 33

Item Order number
1.6 094-011642-00000
1.6 094-011643-00000
1.6 094-011644-00000
1.7 094-012686-00000
2.1 094-000936-00000
2.1 094-000937-00000
2.1 094-000940-00000
2.1 094-001315-00000
2.2 094-001192-00000
2.2 094-001193-00000
2.2 094-001325-00000
2.2 094-001326-00000
2.3 094-000000-00000
2.3 094-003137-00000
2.3 094-003137-00010
2.3 094-011641-00000
3.1 094-001194-00000
3.2 094-003138-00000
4 094-001307-00000
5.1 094-000931-00000
5.1 094-000932-00000
5.1 094-000935-00000
5.1 094-001312-00000
5.1 094-022725-00000
5.1 094-022726-00000
5.1 094-021663-00000
5.1 094-022727-00000
5.1 094-022728-00000
5.2 094-003241-00000
5.2 094-003242-00000
5.2 094-003402-00000
5.2 094-008583-00000
6.1 094-001114-00000
6.2 094-001120-00000
10.8 094-019691-00000
099-011623-EW501
21.03.2023
Type
GNDIFJ TIG 9/17/18/20/26 9.5x48.0mm
GNDIFJ TIG 9/17/18/20/26 12.5x48.0mm
GNDIFJ TIG 9/17/18/20/26 16.0x48.0mm
GNDIFJ TIG 9/17/18/20/26 24.0x34.0mm
COLB TIG 17/18/26 D=1.6MM
COLB TIG 17/18/26 D=2.0-2.4MM
COLB TIG 17/18/26 D=3.2MM
COLB TIG 17/18/26 D=4.0MM
COLB DIF TIG 17/18/26 D=2.0-2.4MM
COLB DIF TIG 17/18/26 D=3.2MM
COLB DIF TIG 17/18/26 D=1.6MM
COLB DIF TIG 17/18/26 D=4.0MM
COLB DIF JUMBO TIG 17/18/26 D=3.2MM Collet body with gas lens,
COLB DIF JUMBO TIG 17/18/26 D=2.4MM Collet body with gas lens,
COLB DIF JUMBO TIG 17/18/26 D=1.6MM Collet body with gas lens,
COLB DIF JUMBO TIG 17/18/26 D=4.0MM Collet body with gas lens,
INS TIG 17/18/26 XL
INS TIG 17/18/26 XXL
INS TIG-SR 17/18/26
COL TIG 17/18/26/18SC D=1.6MM
COL TIG 17/18/26/18SC D=2.4MM
COL TIG 17/18/26/18SC D=3.2MM
COL TIG 17/26/18 D=4.0MM
COL 17/18/26 50 mm Ø 1.0mm
COL 17/18/26 50 mm Ø 1.6 mm
COL 17/18/26 50 mm Ø 2.4mm
COL 17/18/26 50 mm Ø 3.2 mm
COL 17/18/26 50 mm Ø 4.0 mm
COLLET D2.4 L52.0
COLLET D3.2 L52.0
COLLET D1.6 L52.0
COLLET D4.0 L52.0
TCL TIG 17/18/26
TCS TIG 17/18/26
E3; 1,0 x 175 mm
Replaceable parts
TIG 17, TIG 26
Designation
Ceramic gas nozzle for gas
lens, JUMBO
Ceramic gas nozzle for gas
lens, JUMBO
Ceramic gas nozzle for gas
lens, JUMBO
Ceramic gas nozzle for gas
lens, JUMBO
Collet body
Collet body
Collet body
Collet body
Collet body with gas lens
Collet body with gas lens
Collet body with gas lens
Collet body with gas lens
JUMBO
JUMBO
JUMBO
JUMBO
Adapter
Adapter, JUMBO
Insulator
Collet
Collet
Collet
Collet
Collet, long life
Collet, long life
Collet, long life
Collet, long life
Collet, long life
Collet
Collet
Collet
Collet
Back cap, long
Back cap, short
Tungsten electrode, purple
33
