WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Pole Mounted Luminaire
PFL540
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
Advertisement
Related Manuals for WE-EF PFL540
Summary of Contents for WE-EF PFL540
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Pole Mounted Luminaire PFL540 Do not open during installation This product is factory-sealed. Refer to the instructions contained in this document for details. Surge Protection This product features built-in surge protection circuitry in compliance with applicable standards.
- Page 2 * Optional side-entry version for ø 60 x 80 mm spigot, on request IP66, IK08, Class I, ta = 25°C Weight Tools required for PFL540 – 5 mm allen key – 6 mm allen key ø 9 - 14 mm...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation
Installation The product must be installed and maintained by a building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. -
Page 5: Installation Procedure
Installation Procedure 1) Switch off mains electrical supply. 2) Check that rating shown on luminaire label conforms with mains electrical supply. 09/19 IP66 PFL540 220-240V/50 Hz, 1-10 108-XXXX SOE XXXXXXX LED 4000K 48W item no. XXX (example) 3) Loosen screws B and take off cover C. Feed mains cable A into column E while placing luminaire in position. - Page 6 5) Trim mains cable A to the desired length and connect the leads to their respective terminals at the base of the pole (L = Phase, N = Neutral, = Earthing) Supply cable...
- Page 7 WE-EF HELVETICA WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9266W0520 © WE-EF 2020 subject to change.
