Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the
use of matching tools.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Bollard
PSY414 LED
PSY424 LED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF PSY414 LED
Summary of Contents for WE-EF PSY414 LED
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Bollard PSY414 LED PSY424 LED Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards.
- Page 2 Bollard PSY414 PSY424 1000 ø 14.5 ø 14.5 IP66, IK10, Class I, ta = 40°C Weight for PSY414 13.3 for PSY424 16.1 Accessories: Planted root – Galvanised steel. ESV2 for PSY414/424 300-9115 ESV2...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out by a suitably quali ed and trained professional. -
Page 4: Installation
Installation The product must be installed and maintained by a suitably quali ed professional in compliance with latest building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: If the luminaire is modi ed by anybody other than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. -
Page 5: Installation Procedure
Installation Procedure It is recommended to incorporate the optional planted root to ensure maximum stability. 1) Switch off mains electrical supply. 2) Remove sleeve A from post B. 3) Pull cable through center-hole and screw ange 4) Lift tabs H and remove terminal box cover C plate E with M12 bolts/nuts to ground. - Page 6 5) Check that rating shown on luminaire label 6) Pull cable D (and second cable for through wir- conforms with mains electrical supply. ing, if required) through membrane spout(s) F and terminate in terminal block G. Lock cable(s) 08/18 IP66 with strain relief(s).
- Page 7 9) Engage sleeve A into ange plate E 10) Remove countersunk screws J from head K with (good and bad engagement). Torx 25 tool. 11) Hold head K under arm. Grab socket L, connect 12) Place head K over sleeve A and check for and tighten with plug M.
- Page 8 13) Tighten M6 Torx 30 recessed screws N to 6 Nm. 14) Return countersunk screws J into head and tighten.
- Page 9 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com TO9245W0219 © WE-EF 2019 Technical speci cations are subject to change.
- Page 10 WE-EF LEUCHTEN Installation and Maintenance Instructions Planted Root ESV4 ESV2...
- Page 11 Planted Root ESV4 300-0461 ESV4 300-0464 Suitability Suitability 1. KTX234 1. CFY259 2. KTY234-AP 2. GRY234-AP 3. ZFY230-AP 3. RRY234-AP 4. GRY224-AP 4. RRZ324 5. Short post 5. XRY324-AP 6. XRZ234 ESV4 300-0586 ESV4 300-0459 Suitability Suitability 1. XRY334-AP 1. QSI254 2.
- Page 12 Planted Root ESV4 Supply of ESV4 1. M8 x 40 (4x) 2. M8 x 25 (4x) 3. M8 Conical Washer (4x) 4. Mounting Flange 5. ESV4 Planted Root 6. Conduit Entry ESV2 Supply of ESV2 1. M12 x 30 (2x) 2.
-
Page 13: Installation Instruction
Installation Instruction 1) Note: It is the responsibility to installer to 2) Please note, ESV4 must be orientated correctly ensure the suitability of the ESV planted root for different products. In both instances conduit for any local or national structural requirements entry can be rotated to match cable routing. - Page 14 5) Orientate ESV as required and t electrical 6) Place the ESV in the form work for concrete connections/conduit. pad, ensuring orientation, position and levels are correct. Ensure all openings on ESV are blanked off, including mounting plate hole. 7) Fit the nominated bolts through mounting 8) Pour concrete to desired level depending on ange.
- Page 15 9) After concrete has cured for speci ed time, remove blanking and bolts. Install tting (as per luminaire instructions) onto mounting ange.
- Page 16 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com TO9257W0219 © WE-EF 2019 Technical speci cations are subject to change.
