Art. KRV931
Fig. 1
Fig. 3
In order to avoid malfunctions, please do not over tighten the fixing screws shown in Fig. 3.
Art. KRV931 - Mounting instructions
Table desktop kit for 3.5" surface videophones
Fig. 2
Fig. 4
- 1 -
65339810 - V4.0 - 15/07/19
