5.8 QUICK RELEASE WHEELS (SELF-PROPELLED)
The Self-Propelled version of the wheelchair is equipped with quick-release rear wheels.
Removing the Quick-Release Rear Wheels
To remove the rear wheels from the frame, press the button in the middle of the wheel and
pull away from the wheelchair frame as shown.
Attaching the Quick-Release Rear Wheels
To attach the rear wheels, insert the quick release axle into the axle sleeve on the frame.
Push the wheel towards the frame until secured.
P. 14

6. PRODUCT SPECIFICATIONS

6.1 SELF-PROPELLED
Seat Width
Height (mm)
Length (mm)
Width (mm)
Folded Height (mm)
Folded Length (mm)
Folded Width (mm)
Seat Height (mm)
Seat Width (mm)
Seat Depth (mm)
Backrest Height (mm)
Armrest Height (mm)
Front Wheel Size
Rear Wheel Size
Outer Carton Size (mm)
Maximum User Weight (kg)
Frame Material
Wheel Material
Handle Material
Half Folding Back
Quick Release Wheels
Tyre Type
Max slope for parking brakes
Pivot Width (mm)
Total Weight (kg)
Carry Weight (kg)*
Cushion Weight (kg)
Leg rests Weight (kg)
Rear wheels Weight (kg)
*Carry weight excludes cushions, leg rests and rear wheels
18"
940
1100
650
780
810
380
490
460
400
400
700-795
6"
22"
785x310x770
120
Aluminium
PU
Aluminium
Yes
Yes
PU Solid Tyre
7°
780
10.4
8
1.1
1.1
1.3
