Wireless Base Stations and
▫
Client Devices
Surveillance Cameras
▫
Sensor Applications
▫
Lighting Applications
▫
Electronic Gates
▫
Congratulations! on your purchase of the UPSPro
power system. Please take a moment to review this Qwik Install
Guide before assembly or battery installation.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, 5/16" nut driver,
Flat Blade Screwdriver
Please help preserve the environment and return
used batteries to an authorized depot
UPS-PL-120 LG
Backup Power System
DANGER! Avoid Powerlines!
You Can Be Killed!
®
UPSPro
®
backup
Advertisement
Table of Contents
Related Manuals for TYCON Solar UPSPro UPS-PL-120 LG
Summary of Contents for TYCON Solar UPSPro UPS-PL-120 LG
- Page 1 UPS-PL-120 LG ® UPSPro Backup Power System Wireless Base Stations and ▫ Client Devices Surveillance Cameras ▫ Sensor Applications ▫ Lighting Applications ▫ Electronic Gates ▫ ® Congratulations! on your purchase of the UPSPro backup power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
- Page 2 Qwik Install STEP 1: Prepare Enclosure - Attach Battery Brackets Prepare the Velcro strap and the strap brackets #5600066. Orient as shown. Loosen 8 screws holding the mounting plate. Slide the mounting plate towards you and lift up on the top end of the mounting plate while sliding the #5600066 brackets with Velcro Straps over the end of the mounting plate.
- Page 3 STEP 3: Solar Battery Charge Controller Install The system includes an ad- vanced PWM charge controller with LCD display. The control- ler mounts on the backplate using two or four #8 x 3/8” pan head self tapping screws. This controller maintains proper charge parameters over tem- perature to extend battery life and enables the system to be...
- Page 4 12V Battery Configuration 24V Battery Configuration...
- Page 5 using wire nuts. Cutting off the plug will not void the warranty. An- other option is to attach a compact female AC outlet to an AC power cable routed into the bottom of the enclosure. The battery charger can sit loosely in the bottom of the enclosure or can be strapped on top of the batteries, using the battery strap.
- Page 6 SPECIFICATION SUMMARY Subject to change without notice Total Watt Backup Time AGM Battery Battery Battery Hours at 25W Avg Model # Voltage Capacity Storage Load Capacity UPS-PL12-36-120 12VDC 36Ah 9hrs UPS-PL24-36-120 24VDC 36Ah 9hrs Total Watt Backup Time Lithium Battery Battery Battery Hours...
- Page 7 C. I want to add solar panels to extend the backup time. What is the largest solar panel I can use? Max Solar Panel Size 12V 240W , 24V 480W ® 6. ACCESSORIES: Tycon offers a variety of accessories to meet almost any need.
- Page 8 ® 8000116 Rev 1 UPS-PL-120 LG UPSPro Qwik Install Guide...
