Congratulations! on your purchase of the UPSPro
UPS backup power system. Please take a moment to review this
Qwik Install Guide before assembly or battery installation.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, Flat Blade Screw-
driver, 5/16 nut driver
Please help preserve the environment and return
used batteries to an authorized depot
Backup Power System
DANGER! Avoid Powerlines!
You Can Be Killed!
UPS-PL
®
UPSPro
Outdoor
®
Outdoor
Advertisement
Table of Contents
Related Manuals for TYCON Solar UPSPro UPS-PL
Summary of Contents for TYCON Solar UPSPro UPS-PL
- Page 1 UPS-PL ® UPSPro Outdoor Backup Power System Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Mission Critical Backup ▫ Power Remote Sensors ▫ ® Congratulations! on your purchase of the UPSPro Outdoor UPS backup power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
- Page 2 Qwik Install STEP 1: Prepare Enclosure - Attach Battery Brackets Prepare the Velcro strap and the strap brackets, #5600066. Orient as shown. Loosen 8 screws holding the mounting plate. Slide the mounting plate towards you and lift up on the top end of the mounting plate while sliding the #5600066 brackets with Velcro Straps over the end of the mounting plate.
- Page 3 STEP 3: Solar Battery Charge Controller Install The system includes an advanced PWM charge controller with PoE output (SCPOE). Mount the con- troller on the backplate using one or two #8 x 3/8” pan head self tapping screws. The mounting holes in the controller don’t match exactly to the back- plate holes.
- Page 4 STEP 5: Battery Install Insert the batteries by slipping under the Velcro straps and then tighten- ing the straps. The Velcro straps will be on top of the connectors. This is the normal configuration. STEP 6: Power Supply In- stall ®...
- Page 5 SPECIFICATION SUMMARY Subject to change without notice Backup Pas- Time at sive Battery Battery Storage Model # Volts Capacity Capacity Load (30W) UPS-PL1224-36 12VDC 36Ah 432Wh 9hrs UPS-PL1248-36 12VDC 36Ah 432Wh 9hrs UPS-PL2424-36 24VDC 36Ah 432Wh 9hrs UPS-PL2448-36 24VDC 36Ah 432Wh 9hrs 12V Battery Configuration...
- Page 6 FG = Frame Ground (Do Not Connect to GND = V- (There are two V– connec- tions:1 and 2) +12V or +24V = V+ (There are two V+ connections: 1 and 2) Device 2 Device 1 Wire Terminal Connector Pinout TECH CORNER 1.
- Page 7 A. There is no Load Output?—If battery voltage is too low, the charge controller will turn off the load outputs. On a 12V battery system the load will turn off if battery is <11V. On a 24V battery system the load will turn off at <20V. It won’t turn back on until the battery voltage exceeds 12V/24V.
- Page 8 8000117 Rev 1 UPS-PL-LG SCPOE UPSPro® Qwik Install Guide...
