Congratulations! on your purchase of the RemotePro
remote power system. Please take a moment to review this Qwik
Install Guide before assembly or battery installation.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, 1/2" Open End
Wrench, 5/16" nut driver, Flat Blade Screwdriver
Please help preserve the environment and return
used batteries to an authorized depot
Remote Power System
DANGER! Avoid Powerlines!
You Can Be Killed!
RPPL
RemotePro
®
®
off-grid
Advertisement
Table of Contents
Related Manuals for TYCON Solar RemotePro RPPL
Summary of Contents for TYCON Solar RemotePro RPPL
- Page 1 RPPL ® RemotePro Remote Power System Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Remote Sensors ▫ Remote Lighting ▫ Off Grid Electronics ▫ ® Congratulations! on your purchase of the RemotePro off-grid remote power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
- Page 2 Qwik Install STEP 1: Connect included solar panel cable to the solar panel inside wire junction box or to the solar panel MC-4 connectors (if applicable). Install solar panel to the mount so that junction box is at the top or side. Install mount to 2”...
- Page 3 solar controller display will show status. STEP 5: Route wire from solar panel into the enclosure and connect to the controller solar panel input (PV+, PV-). Make sure to maintain cor- rect polarity. STEP 6: Make sure lid gasket is clean and free from any particles, then carefully close the cover, making sure that wires are clear of the seam and hinge area.
- Page 4 SPECIFICATIONS Subject to change without notice RPPL12 RPPL24 Continuous Power Rating Maximum Power Rating Reserve Power @ 8W Load 27 hours Battery Voltage (DC) Battery Capacity (max) 36Ah 18Ah Valve Regulated Sealed Lead Acid / Absor- Battery Type bent Glass Mat (AGM) Battery Life 5 Years PWM, 12V 20A...
- Page 5 12V Configuration Wiring 24V Configuration Wiring...
- Page 6 Wind Turbines are good sources of power, often in times when the sun isn’t shining, like on stormy days. We like to think of a wind tur- bine as uptime insurance. Tycon Solar™ offers small wind turbines ® ®...
- Page 7 ® BreezePro (TPW-400DT-12/24) are compatible wind turbines. To add a wind turbine, it mounts to the top of a 41mm inside diameter pole. ® 10. POE SWITCH: Tycon Power offers a universal voltage 5port and 8port POE switch if more than one device needs to be powered from the battery system.
- Page 8 NOTES ® 8000095 Rev 1 RPPL RemotePro PWM Qwik Install Guide...
