Wireless Base Stations
▫
and Client Devices
Surveillance Cameras
▫
Remote Sensors
▫
Remote Lighting
▫
Off Grid Electronics
▫
Congratulations! on your purchase of the RemotePro™ off-grid
remote power system. Please take a moment to review this Qwik
Install Guide before assembly or battery installation. Other in-
structions come with other components of this kit. Be sure to re-
view all instructions.
When following the instructions in this guide take extreme care
to avoid contact with overhead power lines, lights and power circuits.
Contact with power lines, lights or power circuits may be fatal. We rec-
ommend to install no closer than 20 feet to any power lines.
Safety:
For your own protection, follow these safety rules.
▫
Perform as many functions as possible on the ground
▫
Do not attempt to install on a rainy, windy or snowy day or if
there is ice or snow accumulation at the install site or if the
site is wet.
▫
Make sure there are no people, pets, etc. below when you are
working on a roof or ladder.
Recommended Tools: Phillips Screwdriver, 13mm and 10mm
Wrench, 5/16" nut driver, Flat Blade Screwdriver
Please help preserve the environment and return
used batteries to an authorized depot. Most auto
parts stores will pay you for old batteries.
Remote Power System
DANGER! Avoid Powerlines!
You Can Be Killed!
RPST12M/24M
RemotePro
®
Advertisement
Related Manuals for TYCON Solar RemotePro RPST12M
Summary of Contents for TYCON Solar RemotePro RPST12M
- Page 1 RPST12M/24M ® RemotePro Remote Power System Wireless Base Stations ▫ and Client Devices Surveillance Cameras ▫ Remote Sensors ▫ Remote Lighting ▫ Off Grid Electronics ▫ Congratulations! on your purchase of the RemotePro™ off-grid remote power system. Please take a moment to review this Qwik Install Guide before assembly or battery installation.
- Page 2 Qwik Install STEP 1: Add Grounding Wire Between Door and Enclosure: Remove plastic covers on copper studs on inside of door and inside of enclo- sure. Add jumper wire between 2 copper studs and use copper wash- ers and nuts to secure. STEP 2: Remove the bottom cover and replace it with the PowerVent™...
- Page 3 STEP 6: Insert the battery platform in the bottom of the enclosure. The battery platform has cutouts so wires can be routed under the bat- tery as needed. STEP 7: Attach the DIN Rail adapters to the charge controller using the screws provided. Clip the controller to the DIN rail by putting the bottom of the DIN bracket into the bottom of the DIN rail, then push DIN bracket up and over the top of the...
- Page 4 Panels without pre-installed MC-4 Connectors Configurations MC-4 Connectorized Panels Wiring Configurations 24V Two Panel Configuration 24V Four Panel Config...
- Page 5 CAUTION: Be sure to connect the bat- tery to the controller first and disconnect it last. Connecting so- lar panels to the con- troller without the battery connected could damage the controller.
- Page 6 NOTE When using MPPT controllers, it is best to always wire solar pan- els in series configuration even when batteries are configured for 12V. The MPPT controller will translate the voltage. NOTE: When wiring 2 panels in a 24V configuration you will have two unused wires on the RPST-CABLE-4PANEL cable assembly.
- Page 7 STEP 11: Remove the battery cable fuse before connecting the batter- ies to avoid any accidental shorting. Connect battery cables and PowerVent fan cables to controller BAT connections, then to battery terminals. Be sure to observe proper polarity. Double check wiring and then re-install the battery cable fuse to energize the system, When a fully charged battery is connected, the battery light should light on the controller and the controller should power up.
-
Page 8: Troubleshooting
7. RS232: There is an RS232 port on the controller. This port is a spe- cial port to interface to the Tycon TP-SC-BT1 Bluetooth adapter and the TP-SC-USB-RS232 cable and software. The Bluetooth adapter allows for remote monitoring and control of the controller up to 15m distance. The cable and software are used for connecting to a PC. -
Page 9: Replacement Parts
battery chargers that can be used in parallel with the solar con- troller to charge batteries from AC. Replacement Parts Solar Controller: TP-SC24-20-MPPT, TP-SC24-40-MPPT Batteries: TPBAT12-52 Solar Mount: TPSM-80X4-UNI (2-4panels) Solar Panel: TPS-12-80W SPECIFICATIONS Subject to change without notice RPST12M RPST24M Battery Capacity (12V) 100Ah or 200Ah... - Page 10 Accessories TP-SC-BT1 RS232 to Bluetooth adapter. • Allows for wireless monitoring and control of the MPPT solar charge con- troller up to 15m. • Uses a smartphone app available for Android and IOS devices • Completely weatherproof for outdoor mounting •...
- Page 11 Remote Station Monitor TPDIN-Monitor-WEB2 • Qty 4: Voltmeters and current meters • Web Based: allows station monitoring over the internet. • Qty 4:10A relays for controlling power to devices, starting a generator, etc. • Measures internal and external tem- peratures •...
-
Page 12: Limited Warranty
Limited Warranty ® The RemotePro products are supplied with a limited 36 month warran- ty which covers material and workmanship defects. This warranty does not cover the following: ▫ Parts requiring replacement due to improper installation, misuse, poor site conditions, faulty power, etc. ▫...
