  • Page 1 Assembly and User Manual Thermodynamic Solar System Combi [6 | 12 | 16] Combi 12 CENTRAL HEATING DOMESTIC HOT WATER Directives 2006/95/CE www.energie.pt Review: 1 Version: 0 Date: 06/01/2015...
  • Page 2: Table Of Contents

    5.2.7. Relative position of the panels ....................13 5.2.8. Fixation ............................ 14 5.2.9. Liquid Distributor and Collector, placement and connection ............ 14 5.3. Combi Block ......................... 16 5.3.1. Installation site ......................... 16 5.3.2. Connections at the Combi Block....................17 www.energie.pt...
  • Page 3 8.1. Combi System 220-240 Vac / 1+N / 50 Hz ................28 8.2. Combi System 400-420 Vac / 3+N / 50 Hz ................29 8.3. Glossary ..........................30 Annexes B - Installation ......................31 9.1. Plan ..............................31 9.2. Glossary ............................32 10. Warranty ..........................33 Revisão 1 www.energie.pt...
  • Page 4: Introduction

    Combi [6 | 12 | 16] & Combi 12 HT 1. INTRODUCTION Esteemed Client, Thank you and congratulations for buying an ENERGIE product, the upshot of several years of experience in the sector. We have built products based on specific studies, top quality materials and highly advanced technologies.
  • Page 5: Safety Information

    If damage is identified in the inspection carried out at the time of reception of the unit, describe the damage in the transport reception document. Any transport complaint must be submitted at the act of delivery. If you are in any doubt, get in touch with ENERGIE to obtain information about how to lodge a complaint with the haulage company.
  • Page 6: Transporting The Unit

    ASSEMBLY AND USER MANUAL Combi [6 | 12 | 16] & Combi 12 HT Model Box (H*L*P mm) Pallet (H*L*P mm) Weight (Kg) Combi 6 Combi 12 2020x750x1000 140x750x1000 Combi 16 Combi HT 12 3.4. Transporting the unit The tools recommended for transporting the unit whilst it is still in the pallet may be: forklift truck or pallet rack.
  • Page 7: Technical Specifications

    4.2. Technical Specifications The ENERGIE Combi Systems are presented on the market in a range of 4 models in accordance with the table below: Combi 6...
  • Page 8: Components

    1,5bar). If the heating installation has more than 120 l, a new expansion vessel should be sized. ** It’s mandatory to install the filter (supplied with the system) on the heating line. *** It’s mandatory to install the safety valve (supplied with the system) on the heating line. www.energie.pt...
  • Page 9: Thermodynamic Solar Panels

    The panels must be at ventilated places and preferably not be exposed to any kind of shade. ENERGIE panels must preferably be oriented in a southerly direction (at north hemisphere), but they may also have an orientation towards Northeast and Northwest.
  • Page 10: Inclination

    The maximum distance between the panels and the Combi Block depends on certain factors such as the equipment model, the no. of curves, the piping diameter etc. However, we would recommend that the distance should not exceed the 20m. For Installations with a distance greater than those indicated must contact the Technical Dept. www.energie.pt...
  • Page 11: Unevenness

    Minimum space between the panels on the connections’ side: 200mm (ideal space: 500mm). ✓ Space between the panels on the side opposite the connections: they should preferably not be ✓ completely stuck together (preferably> 20mm) www.energie.pt...
  • Page 12: Direction Of The Panels

    Right: A right-hand panel is installed on the left-hand side (front view). To this end, it has connections on right- hand side. The Solar panel must not be installed on the vertical in accordance with the representation indicated above with a red cross. www.energie.pt...
  • Page 13: Relative Position Of The Panels

    In the diagrams below some of the possible positioning layouts of the panels are represented. However, you may consult in the annex complementary information about the position of the panels in the installation. Combi 6 Combi 12 In the event of some other positioning of the panels, you must contact our Technical Department.
  • Page 14: Fixation

    Only remove the pipe protection cover at the time of connection to the power and aspiration shafts with a view to avoiding the penetration of impurities. Install the distributor (s) vertically, face downwards (never horizontally!), thereby ensuring that the fluid reaches the panels in homogeneous fashion. www.energie.pt...
  • Page 15 It is also recommended for all the piping to have good quality thermal insulation in order to avoid any possible condensation. The piping diameters vary with the system model as can be seen in the table below. Model Aspiration Line Liquid Line Combi 6 3/4’’ 1/2’’ Combi 12 7/8’’ 1/2’’...
  • Page 16: Combi Block

    Also provide for the placement of a tray under the appliance in accordance with legislation to collect any water in the event of an installation rupture. Never grab nor handle the Combi Block by the refrigerant or hydraulic connections. www.energie.pt...
  • Page 17: Connections At The Combi Block

    The Combi Block connections to the panels are supplied with two hermetic valves valves to avoid the penetration of impurities and humidity in the refrigerant circuit wich are already installed according the picture bellow. Location of two hermetic valves www.energie.pt...
  • Page 18: Removing The Covers

    5.3.3. Removing the covers 1. Unscrew M6 screws on the top of the unit; 2. Move up and pull the front panel; 3. Unscrew M6 screws on the lateral as promenor X as picture bellow; 4. Pull the lateral panel. www.energie.pt...
  • Page 19: Electrical Connections

    The power supply cable and the two thermostats should pass on the three electric gland placed on the back of the Combi Block. Electric Gland The power supply cable, the ambiente thermostat (TA) and the external thermostat (TEXT), should enter in the bottom of electric switchboard. www.energie.pt...
  • Page 20: Implementation Of Piping Connections (Welds)

    Welds alongside the Combi Block must also be carried out with due care so as not to burn any component of the Combi Block. You should weld the aspiration and the liquid pipe to the corresponding pipping, at the back of the Combi Block. Be carefull with the welding process. www.energie.pt...
  • Page 21: Leak Test

    ✓ Volume of the system piping. On average, the minimum vacuum time to be carried out at an installation, depending on the system installed, is shown in the table below. Combi 12 / 12 HT Minimum vacuum time (hours) www.energie.pt...
  • Page 22: Refrigerant R-407C (Except Combi 12 Ht)

    12 / 12 HT Minimum load (kg) The two hermetic valves (liquid and aspiration) are closed, so, before charging the system is necessary to open the valves. The direction to open the valves is showned in the picture below. CLOSE OPEN www.energie.pt...
  • Page 23: Hydraulic Connections

    Pressure (ºC) (bar) (ºC) (bar) Combi 6 | 12 | 16 Combi 12 HT You may not achieve exactly the desired pressure as this depends on some factors such as: ✓ Direct solar radiation on the panels; ✓ Ventilation; ✓ Relative humidity of the air;...
  • Page 24 2) all the circuits, ensuring that you eliminate all the air pockets from the installation. As a precaution, you must carry out a leak test. The test must be carried out with pressure 1.5 times the working pressure. www.energie.pt...
  • Page 25: Temperature Probe

    6. CONTROL PANEL The electronic panel of the Energie Combi System takes the form of a console whereby several operating settings can be configured such as: ✓ Water outward and return temperature.
  • Page 26 Combi [6 | 12 | 16] & Combi 12 HT CRONO Date and Time System Status ERROR Code Temp. probes Leds For more information about the electronic panel, please read the “Energie Electronic Panel” manual that is supplied with the equipment. www.energie.pt...
  • Page 27: Error Messages

    Er11 - EVD Carel EVD ✓ Very low evaporation temperature (LOP). ✓ Very high evaporation temperature (MOP). ✓ Low aspiration temperature. ✓ Low aspiration pressure. The intervention at the Combi Block must only be carried out by authorised and specialised professionals. www.energie.pt...
  • Page 28: Annexes A (Wiring Diagram)

    ASSEMBLY AND USER MANUAL Combi [6 | 12 | 16] & Combi 12 HT 8. ANNEXES A (WIRING DIAGRAM) 8.1. Combi System 220-240 Vac / 1+N / 50 Hz www.energie.pt...
  • Page 29: Combi System 400-420 Vac / 3+N / 50 Hz

    ASSEMBLY AND USER MANUAL Combi [6 | 12 | 16] & Combi 12 HT 8.2. Combi System 400-420 Vac / 3+N / 50 Hz www.energie.pt...
  • Page 30: Glossary

    Vanne à Trois Voies EC Válvula de 3 vias AC 3 Way Valve CH Vanne à Trois Voies CS Fase 1; Phase 1 Phase 1 Fase 2; Phase 2 Phase 2 Fase 3 Phase 3 Phase 3 Neutro Neutral Neutre Terra Earth Terre www.energie.pt...
  • Page 31: Annexes B - Installation

    ASSEMBLY AND USER MANUAL Combi [6 | 12 | 16] & Combi 12 HT 9. ANNEXES B - INSTALLATION 9.1. Plan www.energie.pt...
  • Page 32: Glossary

    Vanne à Trois Voies COMP Compressor Compressor Compresseur Válvula de Expansão Eletrónica Electronic Expansion Valve Vanne d'Expansion Électronique Permutador de Calor Heat Exchanger Èchangeur de Chaleur Filtro Secador Dryer Filter Filtre Déshydrateur Depósito de Liquido Liquid Receiver Réservoir de Liquide www.energie.pt...
  • Page 33: Warranty

    ATTENTION: Technical assistance costs even within the warranty period shall be supported by the customer (Km and assistance time). In cases where there is no justifiable breakdown and subsequent need for technical assistance, the client will pay for lost technical assistance time. www.energie.pt...
  • Page 34 ASSEMBLY AND USER MANUAL Combi [6 | 12 | 16] & Combi 12 HT www.energie.pt...
  • Page 35 ASSEMBLY AND USER MANUAL Combi [6 | 12 | 16] & Combi 12 HT ENERGIE EST, LDA Zona Industrial de Laúndos, Lote 48 4570-311 Laúndos – Póvoa de Varzim – Portugal Phone: +351 252 600 230 Fax: +351 252 600 239 E-Mail: energie@energie.pt...
