  • Page 2: Copyright Statement

    Quantum LTO Ultrium 8-Slot Autoloader User’s Guide, P/N50002762, B01, July 2005 Made in USA. Quantum Corporation provides this publication “as is” without warranty of any kind, either express or implied, including but not limited to the implied warranties of merchantability or fitness for a particular purpose.
  • Page 3 All safety and operating instructions should be read before this product is operated, and should be retained for future reference. This unit has been engineered and manufactured to assure your personal safety. Improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards, observe the following basic rules for installation, use and servicing.

  • Page 4: Fcc Notice

    This equipment generates and uses radio frequency energy and, if not installed and used properly that is, in strict accordance with the manufacturer's instructions — may cause interference to radio communications or radio and television reception. It has been tested and found to comply with the limits for a Class B computing device in accordance with the specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.

  • Page 5: Table Of Contents

    Preface Chapter 1 Quick Start Autoloader Components ... 2 Starting the Autoloader... 5 Operator's Panel ... 7 Installing the Data Cartridges ... 8 Chapter 2 Introduction Features ... 10 Accessories ... 11 Optional Accessories ... 12 Chapter 3 Setting Up the Autoloader Choosing a Location ...
  • Page 6 Contents Installation Options...15 Installing the Autoloader into a Rack...16 Requirements ...16 Preparing the Autoloader ...17 Installing the Support Rails ...18 Installing the Rack-Mount Brackets ...19 Securing the Autoloader ...20 Connecting the Cables ...21 Data Cartridges...22 Installing the Data Cartridges ...22 Loading and Unloading a Cartridge ...23 Updating the Cartridge Inventory...24 Chapter 4...
  • Page 7 Error and Event Log ... 41 Log Entry ... 42 Appendix A Specifications Size and Weight... 46 SCSI Interface ... 46 SCSI ID Settings ... 47 Changing the SCSI ID Settings ... 47 SCSI Cable Requirements ... 48 SCSI Terminator Requirements ... 49 Performance Specifications...
  • Page 8 Contents viii LTO Ultrium 8-Slot Autoloader User’s Guide...
  • Page 9 Figure 1 Front Panel Components ... 2 Figure 2 Back Panel Components... 3 Figure 3 Internal Components ... 4 Figure 4 Attaching the Power Cord and a SCSI Terminator ... 5 Figure 5 Pressing the Power Switch... 6 Figure 6 Operator’s Panel ...
  • Page 10 Figures LTO Ultrium 8-Slot Autoloader User’s Guide...
  • Page 11 Table 1 SCSI ID Default Settings... 5 Table 2 Physical Characteristics and Features ... 10 Table 3 Parallel SCSI Communication Interface... 11 Table 4 Inventory Status Characters... 29 Table 5 Oviewview of Error Codes ... 38 Table 6 Robotic Control Errors... 38 Table 7 Function Errors ...
  • Page 12 Tables LTO Ultrium 8-Slot Autoloader User’s Guide...

  • Page 13: Preface

    The Quantum LTO Ultrium 8-Slot Autoloader User’s Guide aprovides automated data storage, archival, backup, and retrieval for a range of systems, from desktop workstations to small office local area networksAudience This document was written for users of the LTO Ultrium 8-Slot Audience Autoloader.
  • Page 14 chapters and appendixes carefully, and keep this Guide handy for future reference. • Chapter 1, Quick Start the autoloader up and running in the shortest possible time. • Chapter 2, Introduction autoloader. • Chapter 3, Setting Up the Autoloader autoloader. •...
  • Page 15 Global Engineering Documents 15 Inverness Way, East Englewood, CO 80112 (800) 854-7179 or (303) 397-2740 Quantum company contacts are listed below. Contacts Quantum Corporate Headquarters To order documentation on the LTO Ultrium 8-Slot Autoloader Guide Quantum Corporation P.O.
  • Page 16 Customer Support The Quantum Customer Support Department provides a 24-hour help desk that can be reached at: North/South America: Asia/Pacific Rim: Europe/Middle East/Africa: Send faxes for the Customer Support Department to: North/South America: Asia/Pacific Rim: Europe/Middle East/Africa: Send e-mail for the Customer Support Department to:...

  • Page 17: Chapter 1 Quick Start

    This chapter provides quick start information for the LTO Ultrium 8-Slot Autoloader, including: • Front Panel Components • Back Panel Components • Internal Components • Starting the Autoloader • Operator's Panel • Installing the Data Cartridges LTO Ultrium 8-Slot Autoloader User’s Guide Chapter 1 Quick Start...

  • Page 18: Quick Start Autoloader Components

    Chapter 1 Quick Start Autoloader Components Autoloader Components The following describes the major components of the autoloader. Figure 1 Front Panel Components Power switch • Cartridge access port autoloader. • Status LEDs about various system functions. See information. • Liquid crystal display (LCD) characters per line.

  • Page 19: Figure 2 Back Panel Components

    Figure 2 Back Panel Components • Bar code reader automatically scans each cartridge in the carousel. The information from each bar code label is stored in memory and available through SCSI to the computer’s operating system or backup application. For more information on the bar code reader, see page 12.

  • Page 20: Figure 3 Internal Components

    Chapter 1 Quick Start Autoloader Components Figure 3 Internal Components • Cartridge loader the cartridge slots and the tape drive. When a cartridge slot is positioned in front of the tape drive, the loader grips the sides of the cartridge and slides it forward or backward, between the slot and tape drive.

  • Page 21: Starting The Autoloader

    Starting the Autoloader To start the autoloader: 1 Attach the power cord to the autoloader, and then to the AC outlet. For more information on power cords, see page 50. Figure 4 Attaching the Power Cord and a SCSI Terminator 2 Connect the SCSI cables and the terminator.

  • Page 22: Figure 5 Pressing The Power Switch

    Chapter 1 Quick Start Starting the Autoloader 3 Use the eraser end of a pencil, or something similar, to press the left side of the power switch. The autoloader powers up. Never use a metal object, such as a screwdriver. Figure 5 Pressing the Power Switch When the autoloader powers up, or resets, it goes through several...

  • Page 23: Operator's Panel

    Operator's Panel The Operator's Panel consists of various status LEDs, an LCD, and keypad buttons that enable you to perform various tasks. The following keypad buttons are used to navigate the menu options: • CANCEL menu item. • PREVIOUS • NEXT •...

  • Page 24: Chapter 1 Quick Start Installing The Data Cartridges

    Chapter 1 Quick Start Installing the Data Cartridges Installing the Data Cartridges Before using the autoloader, the data cartridges must be installed properly. For more information on data cartridges, see on page 22. Caution: To install the data cartridges: 1 Press any button on the Operator’s Panel to change to mode.

  • Page 25: Chapter 2 Introduction

    The autoloader provides automated data storage, archival, backup, and retrieval for a range of systems, from desktop workstations to small office local area networks. This chapter contains general information about the autoloader, including: • Features. • Accessories Figure 7 Autoloader LTO Ultrium 8-Slot Autoloader User’s Guide...

  • Page 26: Chapter 2 Introduction Features

    A robotic cartridge loader moves the cartridges between the cartridge slots and the tape drive. • Storage for up to eight cartridges. Cartridges are stored in cartridge slots mounted on the carousel. One of these cartridge slots can contain a cleaning cartridge.

  • Page 27: Accessories

    Please see the online documentation on the CD for details about installation and operation. LTO Ultrium 8-Slot Autoloader User’s Guide Chapter 2 Introduction Four-button keypad Four-button keypad 3.2TB/1600GB 1.6TB/800GB (Compressed/ (Compressed/ Native) Native) 68/32 32/16 (Compressed/ (Compressed/ Native) Native) www.quantum.com/ Accessories...

  • Page 28: Chapter 2 Introduction Optional Accessories

    Chapter 2 Introduction Optional Accessories Optional Accessories • • LTO Ultrium 8-Slot Autoloader User’s Guide — If you want to mount the autoloader in a rack, Rack-mount kit you can purchase a rack-mount kit. The kit includes all the necessary hardware to mount the autoloader in a standard 19- inch EIA rack.

  • Page 29: Chapter 3 Setting Up The Autoloader

    This chapter describes how to set up the autoloader, and install the autoloader into a rack, if desired. Setting up the autoloader involves the following steps: Choosing a Unpacking the Installation Options Connecting the Cables Data Cartridges Choosing a Location Choose a location that meets the following criteria (see page 45 for more information on autoloader specifications): Setting Up the Autoloader...
  • Page 30 Chapter 3 Setting Up the Autoloader Choosing a Location • Select a location that is flat, sturdy, level, and close to a host server. Do not place the autoloader on the floor or other carpeted surfaces. • Rack requirements — Standard 19-inch rack with 2U of clearance •...

  • Page 31: Checking The Installation Environment

    After choosing a location for the autoloader, consider the following: Checking the Installation • The maximum recommended ambient temperature for the Environment autoloader is in an environment compatible with this temperature. • The fan opening at the rear of the autoloader and the vent openings in the front should be free of cables and other obstructions.

  • Page 32: Chapter 3 Setting Up The Autoloader Installing The Autoloader Into A Rack

    Chapter 3 Setting Up the Autoloader Installing the Autoloader into a Rack Installing the Autoloader into a Rack The autoloader can be installed into a standard 19-inch rack. Requirements To install the autoloader into a rack, you will need the following: •...

  • Page 33: Preparing The Autoloader

    Figure 8 Rack Mount Support rails If the autoloader is currently in operation as a standalone unit, prepare it Preparing the for installation in the rack as follows: Autoloader Warning: 1 Power off the autoloader by pressing the right side of the recessed power switch located on the autoloader’s front panel.

  • Page 34: Installing The Support Rails

    Chapter 3 Setting Up the Autoloader Installing the Autoloader into a Rack Figure 9 Power Switch 2 Remove the power cord and any SCSI cables or terminators attached to the autoloader. Note the configuration of the cables and terminator. You will need to reinstall them after installing the autoloader in the rack.

  • Page 35: Installing The Rack-Mount Brackets

    Figure 10 Attaching the Rails to the Rack 4 Repeat steps 2 and 3 for the second rail. To install the rack-mount brackets on the autoloader: Installing the Rack-Mount 1 Remove the rack-mount brackets from the rack-mount kit and Brackets determine on which side of the autoloader you will attach them, as follows: •...

  • Page 36: Securing The Autoloader

    Chapter 3 Setting Up the Autoloader Installing the Autoloader into a Rack • • 2 Remove the autoloader from the shelf and place it on the work surface. 3 Using a TORX T-10 screwdriver, remove the two screws on each side of the autoloader.

  • Page 37: Connecting The Cables

    2 Place one screw from the rack-mount kit into the hole in the front of each bracket. If your rack has square mounting holes or the holes are larger than the screws provided in the kit, use the clip-nuts to secure the screws.

  • Page 38: Chapter 3 Setting Up The Autoloader Data Cartridges

    Chapter 3 Setting Up the Autoloader Data Cartridges 3 Connect the male end of the power cord to the power outlet. 4 Connect the SCSI cables and the terminator. For more information about the SCSI interface, see • • • 5 Push the power switch on the front of the autoloader to the ON position (press the left side of the switch).

  • Page 39: Loading And Unloading A Cartridge

    To install the data cartridges: 1 Press any button on the Operator’s Panel to change to interaction mode. 2 Choose the 3 Choose 4 Enter the number of the cartridge slot and press 5 Insert the cartridge in the cartridge access port. The cartridge is now placed in the selected slot.

  • Page 40: Updating The Cartridge Inventory

    Chapter 3 Setting Up the Autoloader Data Cartridges After you import or export a data cartridge, you can update the cartridge Updating the inventory using the Cartridge menu. The autoloader checks for the presence of a cartridge in each Inventory cartridge slot.

  • Page 41: Chapter 4 Operating The Autoloader

    This chapter information about using the autoloader, including: • Operator's Panel • Menu Options • Inventory Status Characters • Operating Modes • Autoloader Operations • Maintenance • Shipping the Autoloader Operator's Panel The operator's panel consists of the following: • Status LEDs •...

  • Page 42: Status Leds

    Chapter 4 Operating the Autoloader Operator's Panel Figure 13 Operator’s Clean Drive LED Panel Ready/Activity LED The LEDs are updated during power up and reset sequences. Upon Status LEDs power up or software reset, the autoloader will illuminate all LEDs as soon as the power-on self-test (POST) allows.

  • Page 43: Lcd

    • CLEAN DRIVE The LED will be turned off after the drive is cleaned successfully. • MEDIA ATTENTION that indicates that there is a piece of media that is bad, marginal, or invalid. It will be cleared when all invalid cartridges have been exported from the autoloader.

  • Page 44: Menu Options

    Chapter 4 Operating the Autoloader Menu Options Menu Options Figure 14 Autoloader Menu Options Commands Import Export Load cartridge Unload cartridge Clean drive Re-Inventory The menu options are accessed from the Operator’s Panel by pressing the Enter menu items. Use the the previous menu item.

  • Page 45: Inventory Status Characters

    Inventory Status Characters The inventory status characters represent the status of each slot within the tape drive. They display in the second line of text in the liquid crystal display as an eight-character string, with four blank spaces on each side. Table 4 Inventory Character Status Characters...

  • Page 46: Chapter 4 Operating The Autoloader Operating Modes

    Chapter 4 Operating the Autoloader Operating Modes Operating Modes System Driven the Operator’s Panel displays the status associated with the actions that were caused from commands issued via the drive's SCSI interface. Some of these actions including loading, rewinding, and moving tape display. When an operator’s panel button is pressed and released, the operator’s panel changes to the unit.

  • Page 47: Random Mode

    Random Mode Random application is being used. In into the drive when it receives the appropriate commands from software. To use this mode, your backup software must support autoloaders. This support often requires an autoloader/library software module to be installed. Sequential Mode Sequential Sequential...

  • Page 48: Chapter 4 Operating The Autoloader Autoloader Operations

    Chapter 4 Operating the Autoloader Autoloader Operations If the drive detects a write-protected media, an internal bit is set and the Write-Protected autoloader posts the 'WP' string on the display indicating a write Media protected media is loaded in the drive. The display shows the following status: As soon as the write-protected media is ejected, the drive resets the internal bit and the 'WP' string on the display is cancelled.

  • Page 49: Performing Autoloader And Tape Drive Operations

    Performing Commands cartridges, loading and unloading a cartridge from the tape drive, Autoloader and cleaning the tape drive, and updating the cartridge inventory. For more Tape Drive information on data cartridges, see Operations A reset causes the autoloader to perform its power-on self-test (POST) Resetting the and check for the presence of the data cartridges.

  • Page 50: Chapter 4 Operating The Autoloader Maintenance

    The autoloader warranty does not apply to failures of the autoloader when it is repaired by untrained or unauthorized service personnel. Do not use cleaning cartridges other than a Quantum- approved LTO cleaning cartridge. Carefully follow all instructions and recommendations provided with the cleaning cartridge.

  • Page 51: Shipping The Autoloader

    You have to remember which slot your cleaning cartridge is in. • The autoloader's data storage capacity is reduced by one cartridge. Some software applications may support reserving a slot for a cleaning cartridge and thereby automate the cleaning process. Refer to your software documentation if your software has this capability.

  • Page 52: Chapter 4 Operating The Autoloader Shipping The Autoloader

    Chapter 4 Operating the Autoloader Shipping the Autoloader LTO Ultrium 8-Slot Autoloader User’s Guide...

  • Page 53: Chapter 5 Troubleshooting And Diagnostics

    The autoloader includes features to support troubleshooting and diagnostic operations. If an autoloader error occurs, an error message and error code are displayed on the Operator’s Panel. Additional diagnostic tests are included on the diagnostic software on the Resource CD. Performing a System Test The System Test option cycles the autoloader through the process of loading, calibrating, and unloading all cartridges in the carousel.

  • Page 54: Error Codes

    Chapter 5 Troubleshooting and Diagnostics Error Codes 3 Press load-calibrate-unload cycles that have been completed during the test. 4 Press the Error Codes Table 5 Oviewview of Error Code Hex Notation Error Codes Table 6 Robotic Error Code Hex Notation Control Errors LTO Ultrium 8-Slot Autoloader User’s Guide to begin the test.

  • Page 55: Table 7 Function Errors

    Error Code Hex Notation Table 7 Function Error Code Hex Notation Errors LTO Ultrium 8-Slot Autoloader User’s Guide Chapter 5 Troubleshooting and Diagnostics Description Inventory not valid. The cartridge inventory is not valid, because of manual changes or previous fatal errors. In such case, the inventory must be updated by appropriate commands.

  • Page 56: Table 8 Low Level Axis Errors

    Chapter 5 Troubleshooting and Diagnostics Error Codes Error Code Hex Notation Table 8 Low Level Error Code Hex Notation Axis Errors LTO Ultrium 8-Slot Autoloader User’s Guide Description Cartridge mount error. Movement of cartridge into drive failed. Cartridge dismount error. Failure during cartridge removal and transport back to the slot.

  • Page 57: Table 9 Electronic Harware Errors

    Table 9 Electronic Error Code Hex Notation Harware Errors Table 10 Drive Errors Error-Code Hex Notation Every autoloader provides an internal error and event log with 64 entries. Error and Event This log data is helpful for development and service purposes. The error and event log is accessible through the Operator’s Panel and can be read out entry by entry.

  • Page 58: Log Entry

    Chapter 5 Troubleshooting and Diagnostics Error Codes A negative number in the top line shows the current position in the error Log Entry log. Every log entry consists of a type identifier and two data bytes. This information is shown on the bottom line of the screen. Entry: AA BB CC AA type identifier BB data type 1 CC data byte 2...
  • Page 59 Type Description Represents a motion script information. Data byte 1 points to the current script number, data byte 2 points to the last line executed in the script. The provided information is rather extensive and needs to be verified by the developer of the particular script.
  • Page 60 Chapter 5 Troubleshooting and Diagnostics Error Codes LTO Ultrium 8-Slot Autoloader User’s Guide...

  • Page 61: Appendix A Specifications

    This chapter provides technical specifications for the LTO Ultrium 8-Slot Autoloader. The topics covered in this chapter are: • Size and Weight • SCSI Interface • Performance Specifications • Power Specifications • Environmental Specifications • Acoustic Noise Limits • Shock and Vibration •...

  • Page 62: Appendix A Specifications Size And Weight

    Appendix A Specifications Size and Weight Size and Weight Length Width Height Weight SCSI Interface The autoloader has a standard LVD SCSI interface. One SCSI cable and one SCSI terminator are included with the autoloader. Additional cables and terminators can be ordered from the manufacturer. The LVD SCSI interface is compatible with a single-ended SCSI bus.

  • Page 63: Scsi Id Settings

    The autoloader contains two SCSI ID settings — one for the autoloader’s SCSI ID Settings SCSI controller and one for the tape drive. If there is another device already assigned to these IDs, you will need to change the IDs. For information on how to do this, see Table 13 SCSI ID Autoloader...

  • Page 64: Scsi Cable Requirements

    Appendix A Specifications SCSI Interface The manufacturer recommends using 68-pin SCSI cables that conform to SCSI Cable SCSI-3 specifications. Requirements Caution: Note: SCSI Cable Length The maximum allowable cable length for a low-voltage differential SCSI bus, including all internal and external cables, is specified as follows: •...

  • Page 65: Scsi Terminator Requirements

    The autoloader can accommodate up to eight LTO tape cartridges. The Capacity storage capacity of the autoloader depends on the type of cartridge and the type of data being stored. When installed in the autoloader, the tape drive performs within its Tape Drive specifications.

  • Page 66: Initial Element Status Time

    Appendix A Specifications Power Specifications If the cartridges are properly installed, the autoloader is ready for operation after performing either a POST or a self-test. If the autoloader encounters a problem during a POST or the self-test, it reports an error on the LCD.

  • Page 67: Ac Power Cord

    Table 14 AC Power Input voltage Power consumption: Average while idle Average while operating Maximum while operating Average heat output while operating (based on the AC true power consumption) The autoloader is shipped with a 7-foot (2.1-meter), three-conductor, 18 AC Power Cord AWG power cord for 120 volt use in the United States and Canada, along with an international adapter.

  • Page 68: Environmental Specifications

    (15° C or more). When the autoloader is moved from a cold storage environment to a warm operating environment, it must acclimate in its packaging for at least 12 hours before opening to prevent serious condensation damage from occurring.

  • Page 69: Acoustic Noise Limits

    Specifications much shock the autoloader can withstand while the enclosed tape drive is reading and writing data. The non-operating and storage shock levels indicate how much shock the autoloader can withstand when it is not operating. After experiencing this amount of shock, the autoloader will operate normally.

  • Page 70: Vibration Specifications

    3 g for 5 msec The following table displays the vibration specifications for the Vibration autoloader during operation, non-operation, storage, and transportation. Specifications The operating specifications indicate the amount of vibration the autoloader can withstand while the enclosed tape drive is reading and writing data.

  • Page 71: Disposal Of Electrical And Electronic Equipment

    For more information about where you can drop off your waste equipment for recycling, please visit our website at: http://qcare.quantum.com local government authority, your household waste disposal service or the business from which you purchased the product.
  • Page 72 Appendix A Specifications Disposal of Electrical and Electronic Equipment LTO Ultrium 8-Slot Autoloader User’s Guide...

  • Page 73: Index

    outlet 3 power 50 power cord 51 accessories 11 optional 12 acoustic noise limits 53 back panel components 3 bar code reader 3 buttons 2 cables connecting 21 LTO Ultrium 8-Slot Autoloader User’s Guide Index capacity 49 carousel 4 cartridge access port 2 inventory 24 loader 4...
  • Page 74 unloading 23 depth 46 error codes 41 log 41 event log 41 fan 3 features 10 front panel components 2 humidity 14 initial element status time 50 installing autoloader 13 data cartridges 22 interaction mode 30 internal components 4 inventory status characters 29 keypad 2 LTO Ultrium 8-Slot Autoloader User’s Guide LEDs 2...
  • Page 75 power cord 51 source 14 specifications AC power 50 power cord 51 switch 2 rack mount kit 12 resetting the autoloader 33 room temperature 14 SCSI cables 48 connecting 5 connectors 3 ID settings 47 interface 46 terminator 49 SCSI II specification xv self-test times 49 setting up the autoloader 13 settings...
