Cooper Lighting Metal Halide PAR Lamps MD6X Specification Sheet

D I M E N S I O N S
O R D E R H O U S I N G , T R I M A N D A C C E S S O R I E S S E P A R A T E L Y
Housing Ballast
Housing (2)
Ballast
MD6X=6"
730=70W MH
120/277V
MD6XCP=6"
Chicago
738=70W MH
Plenum
120/347V
Housing
740=100W MH
120/277V
748=100W MH
120/347V
D I M E N S I O N S
O R D E R H O U S I N G , B A L L A S T , T R I M A N D A C C E S S O R I E S S E P A R A T E L Y
Housing Ballast
Housing (2)
Ballast
MD7X=6"
730=70W MH
120/277V
MD7XCP=6"
Chicago
738=70W MH
Plenum
120/347V
Housing
740=100W MH
120/277V
748=100W MH
120/347V
780=150W MH
120/277V
(1)
NOTES: Alzak is a registered trademark of Aluminum Company of America.
your Cooper Lighting Representative for availability and ordering information.
(4)
Cooper Lighting Representative. For White Painted Flange (on self flanged reflectors) add WF to Reflector Finish.
Aperture: 5 11/16" (144mm)
Cutout: 6 3/8" (162mm)
OD: 7" (178mm)
Trim
Trims (4)
Finish
Medium Beam
LI=Low
Iridescent
6600=Reflector with
Polymer Trim
H=Haze
Ring
S=Straw
6600X=Reflector
WH=Wheat
with Polymer
B=Black
Trim Ring (use
WMH=Warm
with ISL and ECL)
Haze
6601=Self Flanged
W=Gloss White
Reflector
BB=Black
6601X=Self Flanged
Baffle (on
Reflector (use
6600, 6600X
with ISL and ECL)
only)
WB=White
Baffle (on
6600, 6600X
only)
Aperture: 7 3/8" (185mm)
Cutout: 8 1/8" (206mm)
OD: 8 7/8" (225mm)
Trim
Trims (4)
Finish
Wide Beam
LI=Low
Iridescent
7600=Reflector with
Polymer Trim
H=Haze
Ring
S=Straw
7600X=Reflector
WH=Wheat
with Polymer
B=Black
Trim Ring (use
WMH=Warm
with ISL and ECL)
Haze
7601=Self Flanged
W=Gloss White
Reflector
BB=Black Baffle
7601X=Self Flanged
(on 7600,
Reflector (use
7600X only)
with ISL and ECL)
WB=White Baffle
(on 7600,
7600X only)
(2)
Products also available in non-US voltages and 50Hz for international markets. Consult
(3)
Accessories should be ordered separately. For additional options please consult your
D E S C R I P T I O N
6
Aperture Size:
Lamp: 70W MH PAR38
100W MH PAR38
Accessories
(3) Internal Standby Lamps
Accessories
Trim Rings ISL50-150MH= Relay with
(not for use with self 100W Quartz Lamp
flanged reflectors)
Emergency Circuit Lamp
TRM6P=White Metal
Option
TRM6MB=Black Metal
ECL
TRR6=Rimless Trim Ring
Ceramic Metal Halide
Lamps
Decorative Trim Rings
Z169=70PAR38/SP
For use with 6600 only
Z170=70PAR38/FL
See Pages 681-683
Z171=70PAR38/WFL
Sloped Ceiling Adapter
Z172=100PAR38/SP
HSA6XX=Specify Slope
Z173=100PAR38/FL
Z174=100PAR38/WFL
Field Installable Fuse Kits
FK3=3 Amp
FK5=5 Amp
FK10=10 Amp
D E S C R I P T I O N
7 3 /
Aperture Size:
8
Lamp: 70W MH PAR38
100W MH PAR38
150W MH PAR38
Accessories
(3) Internal Standby Lamps
Accessories
Trim Rings (not for use ISL50-150MH= 50-150W
with self flanged MH
reflectors)
Emergency Circuit Lamp
TRM7P=White Metal
Option
TRM7MB=Black Metal
ECL
TRR7=Rimless Trim Ring
Ceramic Metal Halide
Lamps
Decorative Trim Rings
Z169=70PAR38/SP
For use with 6600 only
Z170=70PAR38/FL
See Pages 681-683
Z171=70PAR38/WFL
Z172=100PAR38/SP
Sloped Ceiling Adapter
Z173=100PAR38/FL
HSA7XX=Specify Slope
Z174=100PAR38/WFL
Field Installable Fuse Kits
FK3=3 Amp
FK5=5 Amp
FK10=10 Amp
PORTFOLIO ™
MD6X
MD7X
M e t a l H a l i d e PA R L a m p s
D O W N L I G H T
• Precisely formed non-
imaging reflector ensures
45° or 65° cutoff to lamp
and lamp image
• For use with metal halide
PAR38 lamps approved for
use in open fixtures.
• Positive reflector mounting
• Thermally protected
magnetic ballast or
electronic ballast
• Ballast mounts to housing
without tools and is
plugged into connector in
junction box
• Die cast aluminum 1 1/2"
deep collar
• Pre-installed telescoping
mounting bars are suitable
for T-bar ceilings or wood
joists
• Junction box with 1/2" and
3/4" pryouts, listed for eight
#12g 90°C conductors
• Self resetting insulation
detector opens circuit if
insulation is improperly
installed
• Luminaire Efficacy Rating
MD6X-6600-43.96
MD7X-7600-42.64
• UL and CUL listed, feed
through junction box, UL
damp location
COOPER LIGHTING
659
