Cooper Lighting SURE-LITES UN Series Specifications
Cooper Lighting SURE-LITES UN Series Specifications

Cooper Lighting SURE-LITES UN Series Specifications

Incandescent, fluorescent, led lamping

Advertisement

Quick Links

D E S C R I P T I O N
The Sure-Lites Self-powered
Standard Steel Exit Series is the
ideal exit for general purpose
applications. With an extensive
range of field installed accessories,
choice of faces and a variety of
mounting configurations, the basic
exit can be tailored to fit almost any
application. This exit features
durable steel construction,
attractive styling and high
efficiency illumination.
S T E E L E X I T S – S E L F - P O W E R E D I N C A N D E S C E N T
Type
Mounting
(1)
Universal
Wall/Ceiling/End UN1SRW
(2)
Universal Open Face
Wall/Ceiling/End UN1OFW (specify lens)
S T E E L E X I T S – S E L F - P O W E R E D I N C A N D E S C E N T W I T H A D D I T I O N A L O U T P U T T O P O W E R R E M O T E S
Universal
(1)
Wall/Ceiling/End UNH1SRW
Universal Open Face
(2)
Wall/Ceiling/End UNH1OFW (specify lens)
S T E E L E X I T S – S E L F - P O W E R E D F L U O R E S C E N T
Universal
(1)
Wall/Ceiling/End PLX6200RP
Universal Open Face
(2)
Wall/Ceiling/End PLX6200OP (specify lens)
S T E E L E X I T S – S E L F P O W E R E D F L U O R E S C E N T W I T H A D D I T I O N A L O U T P U T T O P O W E R R E M O T E S
Universal
(1)
Wall/Ceiling/End PLX7200RP
Universal Open Face
(2)
Wall/Ceiling/End PLX7200OP (specify lens)
S T E E L E X I T S – S E L F - P O W E R E D L E D
Type
Mounting
Universal
(1)
Wall/Ceiling/End
S T E E L E X I T S – S E L F P O W E R E D L E D W I T H A D D I T I O N A L O U T P U T T O P O W E R R E M O T E S
Universal
(1)
Wall/Ceiling/End
W AT TA G E R AT I N G S
UN
Lead Calcium=10.8W for 1 1/2 hrs., 7.2W for 2 hrs.
UNH
Lead Calcium=27W for 1 1/2 hrs.; 24W for 2 hrs.
PLX-6200
Lead Calcium = 10.8W for 1 1/2 hrs.
PLX-7200
Lead Calcium = 27W for 1 1/2 hrs.; 24W for 2 hrs.
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : U N H 1 7 0 S R W S D
Model
Factory Options
Number
(For ordering with incandescent, add option numbers in
See chart
order listed after series; e.g. UNH170200FW. For ordering
with fluorescent, replace "00" with option numbers in
order listed; e.g. PLX6230RP. For ordering with LED, add
option numbers in order listed after series;
e.g.UN1702090SRWLED)
70=Nickel Cadmium Batteries
20=DC Flasher
30=DC Flasher/Buzzer
90=DC Fire Alarm Interface (Incandescent and LED Only)
SD=Self-Diagnostics (Add to end of catalog number:
e.g. UN130SRWSD)
E n e r g y D a t a
Incandescent Exits 20W Lamps
Fluorescent Exits 5W lamps
Standby Mode (Fully Charged Battery) Sealed Nickel Cadmium Battery Input Power consumption is reduced by approximately 7.5 Watts
in the standby operating mode
Incandescent Exits 20W Lamps
Fluorescent Exits 5W lamps
LED Exits Red Letters (UN)
LED Exits Red Letters (UNH)
LED Exits Green Letters (UN)
LED Exits Green Letters (UNH)
Standby Mode (Fully Charged Battery) Sealed Lead Calcium Battery Input Power consumption is reduced by approximately 7.5 Watts
in the standby operating mode
LED Exits Red Letters (UN)
LED Exits Red Letters (UNH)
LED Exits Green Letters (UN)
LED Exits Green Letters (UNH)
(1)
Universal Face Exits include two stencil faces, canopy and backplate.
004347SP - green letters, white background; 004340SP - white letters, red background; 004341SP-white letters, green background; Special wording, consult your
Cooper Lighting Representative. Order Separately.
COOPER LIGHTING - SURE-LITES
D I M E N S I O N S
6 7/8"
(175mm)
4 5/8"
(117mm)
7 1/2"
(191mm)
12 1/4" (311mm)
Stencil Face, White Finish
Stencil Face, Black Finish
Red Letters
Green Letters Red Letters
UN1SGW
UN1SRB
UN1OFB (specify lens)
UNH1SGW
UNH1SRB
UNH1OFB (specify lens)
PLX6200GP
PLX6200RB
PLX6200OB (specify lens)
PLX7200GP
PLX7200RB
PLX7200OB (specify lens)
Stencil Face, White
Stencil Face, White
Finish, Red Letters
Finish, Green Letters
UN1SRWLED
UN1SGWLED
UNH1SRWLED
UNH1SGWBLED
Nickel Cadmium=15W for 1 1/2 hrs; 12W for 2 hrs.
Nickel Cadmium=24W for 1 1/2 hrs.; 18W for 2 hrs.
Nickel Cadmium = 15W for 1 1/2 hrs.; 12W for 2 hrs.
Nickel Cadmium = 24W for 1 1/2 hrs.; 18W for 2 hrs.
Accessories
(Order Separately)
FL1=Flasher Kit
BZ1=Buzzer Kit
Pendant Kit:
PK18BK=Black, 18" long
PK18WH=White, 18" long
Canopy Kit:
CAN571=White
CAN578=Black
Charged Mode (Fully Discharged Battery) Sealed Lead Calcium Battery
Input Power:
Input Current (Max.): Power Factor:
120V
277V
120V
277V
53W
51W
.45A
.19A
33W
33W
.44A
.18A
Sealed Lead Calcium Battery
47W
44W
.40A
.16A
26W
26W
.41A
.16A
Charged Mode (Fully Discharged Battery) Sealed Lead Calcium Battery
10.4W
10.8W
.10A
.04A
12.6W
13.2W
.10A
.05A
11.9W
12.3W
.10A
.05A
15.8W
15.4W
.14A
.06A
Sealed Nickel Cadmium Battery
4.8W
4.7W
.05A
.02A
9.1W
9.1W
.08A
.04A
6.1W
6.0W
.06A
.03A
10.3W
10.3W
.09A
.04A
(2)
For Open Face Exits, specify lens desired: 004346SP-red letters, white background;
2 1/4" (57mm)
1 1/4" (32mm)
12 1/4"
(311mm)
Stencil Face, Black/Silver Finish
Green Letters Red Letters
Green Letters
UN1SGB
UN1SRBS
UN1SGBS
UN1OFBS (specify lens)
UNH1SGB
UNH1SRBS
UNH1SGBS
UNH1OFBS (specify lens)
PLX6200GB
PLX6200RBS
PLX6200GBS
PLX6200OBS (specify lens)
PLX7200GB
PLX7200RBS
PLX7200GBS
PLX7200OBS (specify lens)
Stencil Face, Black
Stencil Face, Black
Finish, Red Letters
Finish, Green Letters
UN1SRWBLED
UN1SGWBLED
UNH1SRWBLED
UNH1SGWBLEDL
Tamperproof Accessories:
TPK1CP=Tamperproof
Screws
0590A638SP=Screwdriver
bit for TPK1CP Screws
Wire Guard
WG10=Surface Wire Guard
WGS11=Ceiling, End Wire
Guard
VS2=Polycarbonate
Vandal Shield
VS2WP=Polycarbonate
Vandal Shield -
Weatherproof
T.H.D.:
120V
277V
120V
277V
>.99
>.98
<9%
<10%
>.62
>.65
<10%
<8%
>.98
>.98
<8%
<8%
>.52
>.57
<11%
<10%
>.89
>.88
<45%
<48%
>.91
>.91
<39%
<42%
>.96
>.94
<29%
<33%
>.97
>.96
<25%
<29%
>.76
>.73
<63%
<68%
>.90
>.89
<36%
<40%
>.88
>.85
<47%
<52%
>.96
>.95
<24%
<29%
®
UN/UNH/PLX
SERIES
S t e e l
S e l f - P o w e r e d
I n c a n d e s c e n t ,
Fluorescent, LED Lamping
E X I T L I G H T I N G
• Dual-voltage input
120/277VAC, 60Hz
• 20 gauge (white/black) steel
housing
• AC incandescent: two 20W
T6 1/2 intermediate base
lamps-DC: two 6V, 3.6W DC
Lamps
• AC fluorescent: two 5W
F5TT lamps-DC: three 6V,
3.6W DC lamps
• AC LED: long life LED lamp
modules-DC: two 6V, 3.6W
DC lamps
• Lead Calcium or Premium
Nickel Cadmium battery
• Universal: both single and
double face; ceiling, wall
and end mountable
• Knockouts for chevron
directional indicators
• Universal styles offer
complete installation
flexibility with canopy,
backplate, and 2 stencil
faces
• Louvered downlight
• Suitable for floor proximity
installation
• Line-latching, Solid-State
voltage limited charger,
Solid-State switching, low-
voltage disconnect,
brownout circuit,
overload/short-circuit
protection, test
switch/power indicator light
• UL 924 Listed, Life Safety
NFPA 101, NEC/OSHA, most
state and local codes
COOPER LIGHTING
653
