ACCESSORIES AND RECOMMENDED MATERIALS
The use of materials or complementary accessories of the lift is not allowed and not mentioned in this manual may
result in major damage
REPAIRS
In case of failure, don't perform the repairs personally. All service must be performed
by competent personnel.
VOLTAGE
Use the lift with electric current, single-phase 220 V. - 50 Hz

FAN MOTOR

Always keep the vents open for proper ventilation of the engine.
OPERATING INSTRUCTIONS
1 2
3
1. Remove the strap from the top of the telescopic pole.
2. Unscrew the screws holding the feet.
3. Tighten the locking screw of the tripod.
4. Press down on the handle at the end of each foot in order to bring down the sliding part of the foot.
5. Level the foot with the integrated level situated on the top of the telescopic pole.
6. Adjust, if necessary, the feet in case you're working on the stairs
7. Secure the platform at the head of the telescopic pole with the screw.

PRELIMINARY CHECKS

1. Before attaching the hoist to the current, check the wiring and make sure that the voltage is correct.
2. Before you begin to lift the weight, perform a visual inspection to check that the belt has been removed the telescopic
pole.
3. Also make sure that the emergency stop button is pulled towards you.
In case you are not able to pull towards you the red emergency button with one hand, lightly press
the trigger button of the joystick and with the other hand slightly turn the emergency button and
pull. This maneuver does not cause any damage to the unit, but allows you to attach the gearbox.
4
5
6 7
11
