OPERATING AND MAINTENANCE
CONTENTS
1.0.
2.0.
TECHNICAL DATA TABLE
3.0.
DEFINITION OF DIAPHRAGM PUMP
4.0.
5.0.
6.0.
INSTRUCTIONS AND MANUAL OF DIAPHRAGM PUMP
7.0.
8.0.
9.0.
Attachment-1 Pump Performance Charts
Attachment-2 Gisan Warranty
Gisan Machinery Industry and Trade Co. Ltd.
RAN 2" F50-AX MODEL
DIAPHRAGM PUMP
MANUAL
www.ranpump.com
Advertisement
Table of Contents
Related Manuals for Ranpump F50-AX
Summary of Contents for Ranpump F50-AX
-
Page 1: Table Of Contents
RAN 2” F50-AX MODEL DIAPHRAGM PUMP OPERATING AND MAINTENANCE MANUAL CONTENTS 1.0. IMPORTANT SAFETY REQUIREMENTS 2.0. TECHNICAL DATA TABLE 3.0. DEFINITION OF DIAPHRAGM PUMP 4.0. HANDLING, MOVING, OPENING THE PACKAGE OF DIAPHRAGM PUMP 5.0. MOUNTING AND CONNECTING OF DIAPHRAGM PUMP 6.0. -
Page 2: Important Safety Requirements
1.0. IMPORTANT SAFETY REQUIREMENTS a- This equipment is for professional use only. Observe all warnings. Read and understand all instruction manuals, warning labels, and tags before you operate the equipment. b- CAUTION: This manual contains important instructions and safety cautions on diaphragm pumps. - Page 3 WARNING ! Always wear appropriate clothing and equipment, such as eye protection and breathing apparatus, to protect yourself. WARNING ! Improper handling, splashing in the eyes, ingestion, or bodily contamination of hazardous fluids or inhaling toxic vapors can cause extremely serious injury or death. Observe all the following precautions when handling known or potentially hazardous fluids.
- Page 4 1.2. Conformity to eu directives and standards All the diaphragm pumps produced comply with the below listed EC directives and standards. 2006/42/EC Safety of Machinery EN ISO 12100 Safety of machinery -- General principles for design- Risk assessment and risk reduction DIN EN 809 Pumps and pump units for liquids - Common safety requirements EN ISO 4414 Pneumatic fluid power -- General rules and safety requirements for systems and their components...
- Page 5 3.0. DIAPHRAGM PUMP DEFINITION A diaphragm pump works with compressed air coming from a compressor. Pump working principle is shown in the illustration below. There are two valves distributing air in the pump. Outer valve is distributing the air to the diaphragms.
- Page 6 .1.Diaphragm pump has the name plate shown on diagram 1 Figure 1- Pump Name Plate 3.2. Diaphragm pump coding system X X - X INLET BODY DIAPHRAGM OUTLET MATERIAL MATERIAL A = 1/4” A = Aluminium 0 = Buna- N DIAPHRAGM B = 1/2”...
-
Page 7: Handling, Moving, Opening The Package Of Diaphragm Pump
3.4. Diaphragm pump main dimensions Figure 3 – Diaphragm pump main dimensions. 4.0. HANDLING, MOVING, OPENING THE PACKAGE OF DIAPHRAGM PUMP Handle the pump from manifolds to move. 2 and 3 inch pumps must be handled by at least two persons. -
Page 8: Mounting And Connecting Of Diaphragm Pump
5.0. MOUNTING AND CONNECTION OF DIAPHRAGM PUMP A typical setup configuration is shown in figure 8a. Further information and consultation on pump setup can be provided by your Ran Pump distributor. ALWAYS USE ORIGINAL RAN PUMP PARTS AND ACCESSORIES. FAILURE TO DO SO WILL INVALIDATE THE GUARANTEE Pump should be fixed firmly to the ground or platform and should be fitted in a perpendicular position as shown in Figure 5. - Page 9 5.2. Tightening the bolts before first use After you unpack the pump, and before you use it for the first time, check and tighten external fasteners. Tighten the fluid cover screws first, then the manifold screws. (Refer to Figure 7 for torque figures).
- Page 10 Figure 8a - Typical installation scheme 5.5. Fluıd lıne 5.5.1. Fluid suction line 1- Use a conductive hose or pipe. 2- Screw fluid fitting into the pump inlet tightly. 3- If the inlet fluid pressure is more than 25% of the outlet working pressure, ball check valves will not close fast enough, result will be inefficient pump operation.
- Page 11 CAUTION ! It is advisable to install a pressure relief system (bypass line)to relieve high levels of pressure that may occur if the pump is pressurised for a long period when not operating. On some uncontrolled systems the back pressure generated from a closed outlet hose can cause the pump to stop or even reverse operation.
- Page 12 5.6 Ground the pump as shown below 5.6.1 For the pump: Use a conductor (for grounding) with a cross-section of at least 1.5 mm . Connect the conductor to the pump’s leg as shown on Fig. 7, and the other end to the grounding line.
- Page 13 IMPORTANT NOTE : If the diaphragm pump is submerged in water it is important that the fluid will not enter the air exhaust system. To ensure this please use the special exhaust cover with suitable attached hose with hose exit not submerged in fluid.
- Page 14 6.2 Starting and adjusting the pump 1- Check pump grounding before use. 2- Check fittings to be sure they are tight. Use a compatible liquid thread sealant (teflon, etc.) on male threads. Tighten fluid inlet and outlet fittings securely. 3- Submerge the suction hose in the fluid. Note: If the inlet fluid pressure is more than 25% of the outlet working pressure, ball check valves will not close fast enough, result will be inefficient pump operation.
-
Page 15: Assembly And Dismantling Of Parts
7.0. ASSEMBLY AND DISMANTLING OF PARTS WARNING: Before service and maintenance always relieve the air and fluid pressure. This explanation refers to figures defined in part (7.0) line (12) fig. 14a. 7.1. Ball check valve repair Tools required - Torque wrench - 17 mm wrench - 15 mm wrench 7.1.1 Dismantling... - Page 16 7.2. Changing diaphragm Tools Required - Lithium-base grease (non-freezing silicone grease) - 17 mm wrench - 15 mm wrench - 32 mm wrench - torque wrench - Philips-head screwdriver WARNING! Transferred liquid enters air chamber of pump when the diaphragm ruptures.
- Page 17 7.3 Air valve repair Tools Required - Torque wrench - 5 mm allen key - Z-ring pick - Lithium-base grease (non-freezing silicone grease) NOTE: Hold the air valve vertical position if the core is sliding with its own weight in the valve body, valve z-rings need to be changed.
-
Page 18: Periodic Maintenance
Figure 13b - Pilot valve repair. 8.0 PERIODIC MAINTENANCE 8.1 Cleaning and storage of the pump Do not let your fluid dry in the pump or in the hoses. It may harm the pump. Clean the pump regularly by pumping a suitable solvent for your fluid until the pump is cleaned. Make sure the fluids you are using are compatible with your diaphragm material. - Page 19 8.6 Troubleshooting PROBLEM CAUSE SOLUTION 1- Pump cycles at stall or fails to hold Worn check valve balls, seats or o-rings. Replace. pressure at stall. Disassamble and clean air valve. Air valve is stuck or dirty. Use ONLY filtered air. Check valve ball severely worn and Replace ball and seat.
-
Page 20: Storage Of Diaphragm Pump
Tel: 00 90 212 875 03 17 Fax: 00 90 212 875 03 18. Address: Birlik Sanayi sitesi 3. Cadde No: 83 Beylikdüzü Istanbul Turkey E-mail / Web : info@ranpump.com / www.ranpump.com CAUTION: PUMPS RETURNED TO GISAN FOR SERVICING. THE PUMP SHOULD BE THOROUGHLY CLEANED AND EMPTY AND PACKAGED SECURELY AND SAFELY TO PROTECT PEOPLE AND THE ENVIRONMENT. -
Page 21: Ordering Spare Parts
12.0 ORDERING SPARE PARTS No spare parts supplied with the diaphragm pump. Contact us using above method to order. NO CODE PARTS NO CODE PARTS F1051 Center section F3052 Valve gasket Valve + Muffler fixing bolt F1251 Shaft seat F1152 Shaft seat O-ring F3354 Cover exhaust F1151 Shaft O-ring... - Page 22 Figure 14b: Pump assembly scheme for RAN 2”...
- Page 23 ATTACHMENT-1 2” ALUMINIUM DIAPHRAGM PUMP PERFORMANCE CHARTS *Reduce the flow rate by 20% if using Teflon diaphragms on your pump.
- Page 24 Gisan Makine San. Tic. Ltd. Şti. Birlik Sanayi Sitesi 3. Cadde No: 83 Beylikdüzü İstanbul Turkey Tel. : 00 90 212 875 03 17 (pbx) Faks: 00 90 212 875 03 18 E-mail / Web : info@ranpump.com / www.ranpump...
