Gisan Machinery Industry and Trade Co. Ltd.
RAN 1" D25-PX MODEL
DIAPHRAGM PUMP
OPERATING AND MAINTENANCE
MANUAL
www.ranpump.com
Advertisement
Table of Contents
Related Manuals for Ranpump D25-PX
Summary of Contents for Ranpump D25-PX
-
Page 1: Table Of Contents
RAN 1” D25-PX MODEL DIAPHRAGM PUMP OPERATING AND MAINTENANCE MANUAL CONTENTS 1.0. IMPORTANT SAFETY REQUIREMENTS 2.0. TECHNICAL DATA TABLE 3.0. DEFINITION OF DIAPHRAGM PUMP 4.0. HANDLING, MOVING, OPENING PACKAGE OF DIAPHRAGM PUMP 5.0. MOUNTING AND CONNECTING OF DIAPHRAGM PUMP 6.0. -
Page 2: Important Safety Requirements
1.0. IMPORTANT SAFETY REQUIREMENTS a- This equipment is for professional use only. Observe all warnings. Read and understand all instruction manuals, warning labels, and tags before you operate the equipment. b- CAUTION: This manual contains important instructions and safety cautions on diaphragm pumps. - Page 3 WARNING ! Always wear appropriate clothing and equipment, such as eye protection and breathing apparatus, to protect yourself. WARNING ! Improper handling, splashing in the eyes, ingestion, or bodily contamination of hazardous fluids or inhaling toxic vapors can cause extremely serious injury or death. Observe all the following precautions when handling known or potentially hazardous fluids.
- Page 4 2.0. DIAPHRAGM PUMP TECHNICAL DATA 1’’ POLYPROPYLENE PUMP Description Unit Value 1” Polypropylene Pump Type Inch Bar, Psi 7 (0.7Mpa, 105 Psi) Max. fluid working pressure Air feeding pressure range 1 - 7 Max. Air consumption /minute Fluid per cycle lt/cycle 0,65 Max.
- Page 5 RIGHT STROKE MIDDLE STROKE LEFT STROKE Compressed air is directed to When the pressurized At completion of the stroke, the back side of diaphragm B diaphragm, diaphragm B, the air valve again redirects by the air valve. The reaches the limit of its air to the back side of compressed air moves the discharge stroke, the air valve...
- Page 6 3.1.Diaphragm pump has the name plate shown on diagram 1 Figure 1- Pump Name Plate 3.2. Diaphragm pump coding system INLET BODY DIAPHRAGM X X - X OUTLET MATERIAL MATERIAL B = 1/2” A = Aluminium 0 = Buna- N DIAPHRAGM C = 3/4”...
-
Page 7: Handling, Moving, Opening Package Of Diaphragm Pump
3.4. Diaphragm pump main dimensions Figure 3 – Diaphragm pump main dimensions. 4.0. HANDLING, MOVING, OPENING THE PACKAGE OF DIAPHRAGM PUMP Handle the pump from manifolds to move. Pumps are packed into carton boxes. Figure 4 – Pump package. Pump package must be at least 130 grams and produced from the kraft carton. It must be fully covered with packaging separators. -
Page 8: Mounting And Connecting Of Diaphragm Pump
5.0. MOUNTING AND CONNECTION OF DIAPHRAGM PUMP A typical setup configuration is shown in figure 7. Further information and consultation on pump setup can be provided by your Ran Pump distributor. ALWAYS USE ORIGINAL RAN PUMP PARTS AND ACCESSORIES. FAILURE TO DO SO WILL INVALIDATE THE GUARANTEE Pump should fixed firmly to the ground or platform and should be fitted in a perpendicular position as shown in Figure 5. - Page 9 5.2. Tightening the bolts before first use After you unpack the pump, and before you use it for the first time, check and tighten external fasteners. Tighten the fluid cover screws first, then the manifold screws. (Refer to Figure 7 for torque figures).
- Page 10 Figure 8a - Typical installation scheme 5.5. Fluıd lıne 5.5.1. Fluid suction line 1- Use a conductive hose or pipe. 2- Screw fluid fitting into the pump inlet tightly. 3- If the inlet fluid pressure is more than 25% of the outlet working pressure, ball check valves will not close fast enough, result will be inefficient pump operation.
- Page 11 CAUTION! Do not over tighten fittings that are used for connection to the pump. Overtightening may damage the pump. Caution. It is advisable to install a pressure relief system (bypass line)to relieve high levels of pressure that may occur if the pump is pressurised for a long period when not operating.
- Page 12 5.6. Ventilating exhaust air You must vent the exhaust to a safe place, away from people, animals, food, and all sources of ignition when pumping flammable or hazardous fluids. Note that when there is a tear on the diaphragm, the media in the pump will be exhausted together with the air. To avoid this exhaust the gas away from the operation environment.
- Page 13 WARNING ! Diaphragm pumps are sold as pump unit only. Installing a control device (if needed) is responsibility of the operator. If the power supply of the pump (compressor) is stopped, the air inlet to the pump must be cut off immediately. Otherwise when compressor restarts, pump may start unexpectedly.
-
Page 14: Assembly And Dismantling Of Parts
6.3. Stopping the pump Cut off the air when the pump is not working. WARNING ! PRESSURIZED EQUIPMENT HAZARD The equipment stays pressurized until pressure is manually relieved. To reduce the risk of serious injury from pressurized fluid, accidental spray from the gun or splashing fluid, follow Pressure Relief Procedure whenever you ... - Page 15 7.2. Changing diaphragm Tools Required - Lithium-base grease (non-freezing silicone grease) - 13 mm wrench - 24 mm wrench - Torque wrench WARNING! Transferred liquid goes into air chamberof pump when the diaphragm ruptures. Liquid can damage the pilot valve o-rings and the air valve o-rings due to its chemical behaviour.
- Page 16 7.3 Air valve repair Tools Required - 5 mm allen key - 10 mm wrench - Philips-head screwdriver - Lithium-base grease (non-freezing silicone grease) NOTE: Hold the air valve in vertical position. If the core is sliding with its own weight in the valve body, valve z-rings need to be changed.
-
Page 17: Periodic Maintenance
8.0 PERIODIC MAINTENANCE 8.1 Cleaning and storage of the pump Do not let your fluid dry in the pump or in the hoses. It may harm the pump. Clean the pump regularly by pumping a suitable solvent for your fluid until the pump is cleaned. Make sure the fluids you are using are compatible with your diaphragm material. - Page 18 8.6 Troubleshooting PROBLEM CAUSE SOLUTION 1- Pump cycles at stall or fails to hold Worn check valve balls, seats or o-rings. Replace. pressure at stall. Disassamble and clean air valve. Air valve is stuck or dirty. Use ONLY filtered air. Check valve ball severely worn and 2- Pump will not Replace ball and seat.
-
Page 19: Storage Of Diaphragm Pump
Fax: 00 90 212 875 03 18. Address: Birlik Sanayi sit. 3. Cad. No:83 Beylikdüzü Istanbul Turkey E-mail / Web : info@ranpump.com / www.ranpump.com CAUTION: PUMPS RETURNED TO GISAN FOR SERVICING. THE PUMP SHOULD BE THOROUGHLY CLEANED AND EMPTY AND PACKAGED SECURELY AND SAFELY TO PROTECT PEOPLE AND THE ENVIRONMENT. -
Page 20: Ordering Spare Parts
12.0 ORDERING SPARE PARTS No spare parts supplied with the diaphragm pump. Contact us using above method to order. CODE PARTS CODE PARTS D1033 Center section Valve +Muffler cover bolt B1111 Shaft O-ring D3331 Cover exhaust B1211 Shaft seat D1432 Diaphragm shaft D1332 Shaft cover... - Page 21 Figure 13b: Pump assembly scheme for RAN 1”.
- Page 22 ATTACHMENT-1 1" DIAPHRAGM PUMP PERFORMANCE CHARTS *Reduce the flow by 20% at the charts above, if there are Teflon diaphragms in your pump.
- Page 23 Gisan Makine San. Tic. Ltd. Şti. Birlik Sanayi Sitesi 3. Cadde No: 83 Beylikdüzü İstanbul Turkey Tel. : 00 90 212 875 03 17 (pbx) Faks: 00 90 212 875 03 18 E-mail / Web : info@ranpump.com / www.ranpump...
- Page 24 Gisan Makine San. Tic. Ltd. Şti. Birlik Sanayi Sitesi 3. Cadde No: 83 Beylikdüzü İstanbul Turkey Tel. : 00 90 212 875 03 17 (pbx) Faks: 00 90 212 875 03 18 E-mail / Web : info@ranpump.com / www.ranpump 25082012...
