RSA Lighting LYNX LX3001TRMH Specification Sheet

DESCRIPTION
Miniature cylindrical recessed housing and round trimless fixture with
regressed black baffle. Includes enclosure with integral electronic metal
halide ballast and wiring compartment.
For new construction or remodel applications. Insulation must be kept 3"
from all sides and at least 1" above the housing.
SPECIFICATION FEATURES
A ...Housing
All aluminum construction with 18" of
flexible conduit attached to a cylindrical
ballast/wiring enclosure. Perforated
metal plasterframe adjusts for trimless
mounting in 1/2" - 3/4" drywall.
B ...Trimless Fixture:
3.2" o.d. round trimless fixture with
regressed black baffle. Perforated metal
plasterframe allows ceiling compound
to be applied directly to the edge of the
fixture. Finished in white, black, industrial
silver, stainless steel (painted), and primer
for matching to existing ceiling color.
8.90"
2.00"
ORDERING INFORMATION
LX3001TRMH
__
Fixture Finish
WH = White
LX3001TRMH
Regressed Black Baffle Lynx BK = Black
Trimless Fixture with Housing & S = Industrial Silver
Ballast Enclosure SS = Stainless Steel (painted)
PM = Primer
www.cooperlighting.com
C ...System Protection:
Thermal protection inside housing.
Vent holes in housing provide cooler
operation. All aluminum construction
provides overall reduced temperatures.
D ...Electrical
Electronic metal halide ballast housed
in a separate metal enclosure.
Enclosure includes a separated wiring
compartment and entry for primary
leads.
18.00"
Flexible Conduit
A
D
20
Lamp/Ballast Wattage
20 = 20 watts
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031
Catalog #
Project
Comments
Prepared by
E ...Lamp
CMHMR16 Metal Halide in 20 watts.
. GX10 twist-lock lamp socket for
included)
firm, mechanical lamp connection. Can
accept up to two (2) optical accessories.
Ceiling Cut-Out: 3.50" dia.
3.20" dia.
1.75" dia.
__
Voltage
120 = 120 volts
277 = 277 volts
Type
Date
(not
LX3001TRMH
Miniature Round
Trimless Fixture w/
Regress Black Baffle
Cylindrical Housing
Ballast/Wiring
C
5.50"
E CMHMR16 Metal Halide 20 watts
B
U.L. Listed. Suitable for use in
combustible ceilings.
LYNX
Enclosure
rev. 011007
