Datavan S-615E User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Saturn Series
S-615E/ S-715E
User Manual
Version 1.0

Advertisement

Table of Contents
loading

Related Manuals for Datavan S-615E

Summary of Contents for Datavan S-615E

  • Page 1 Saturn Series S-615E/ S-715E User Manual Version 1.0...
  • Page 2 About this Manual Thank you for purchasing Saturn Series Touch Terminal. This terminal offers highly enhanced features, with easy connection to various optional devices for optimal performance. This user manual describes how to setup and connect your terminal. Copyright © Copyright 2019 All rights reserved.
  • Page 3 ◊ The power cord or plug is damaged. ◊ The equipment has been dropped and damaged. ◊ The equipment does not function normally. • Do not leave the equipment in a non air-conditioned environment where the storage temperature may go above 70°C (158°F), as this can cause damage to the equipment. Maintenance •...
  • Page 4 • Reorient or relocate the interference receiving antenna. • Increase the distance of separation between the equipment and interference receiver. • Connect the equipment to a power outlet on a circuit different from that to which the interference receiver is connected. •...
  • Page 5 WEEE Notice The WEEE logo (shown at the left) on the product or on its box indicates that this product must not be disposed of or dumped with your other household waste. You are liable to dispose of all your electronic or electrical waste equipment by relocating over to the specified collection point for recycling of such hazardous waste.

  • Page 6: Table Of Contents

    Bottom Side ....................22 System Default Settings ................ 28 Chapter 3: System Memory ........... 29 Chapter 4: BIOS Setup ............30 4-1 S-615E ....................30 4-2 S-715E ....................35 Chapter 5: Hardware Installation .......... 40 Replacing the Rear Covers ..............40 Adjusting the System Stand ..............41 Installing / Replacing the HDD ..............
  • Page 7 Chapter 6: Frequently Asked Questions (FAQ) ....48 How do I clear CMOS? ................48...

  • Page 8: Chapter 1: Introduction

    INTRODUCTION Chapter 1 Introduction Congratulations on your purchase of this Touch Terminal. Your easy-to-use POS terminal is designed to help you enhance your business flexibility by offering superior customer experience. Chapter 1: Introduction Package Contents Before setting up your Touch Terminal, check that the package contains the following items. If any of the items is missing or damaged, contact your vendor immediately.

  • Page 9: Overview Of Saturn Series

    INTRODUCTION Overview of Saturn Series The figures in this section illustrate the components (including input and output ports) located at the front and rear of your Touch Terminal. Front View Standard Type Rear View Standard Type...
  • Page 10 INTRODUCTION I/O Ports S-615E USB3.0 USB2.0 COM3 COM2 COM1 USB2 USB1 Item Connector Definition DC 12V Output DC 12V Input RJ12 Cash Drawer COM3 RJ50 COM 3 Serial Ports COM2 RJ50 COM 2 Serial Ports COM1 RJ50 COM 1 Serial Ports USB2 USB 3.0 + USB 2.0...

  • Page 11: Powering On/Off Saturn Pos

    INTRODUCTION Powering ON/OFF Saturn POS Power ON Saturn POS The power button is located at the bottom side of the back cover. Press down the power button to power on the POS. Power OFF Saturn POS In most cases, press the power button of the POS to power the system off. If the terminal fails to turn off the machine for unknown reasons, please be advised to hold the power button more than 4 seconds to force a shutdown of the system.

  • Page 12: Physical Dimensions

    INTRODUCTION Physical Dimensions Standard Display...
  • Page 13 INTRODUCTION LCM (Liquid Crystal Module) VFD Customer Display...
  • Page 14 INTRODUCTION 10” Secondary LCD Display...
  • Page 15 INTRODUCTION 15” Secondary LCD Display...

  • Page 16: Touch Terminal Specifications

    INTRODUCTION Specifications Touch Terminal Specifications S-615E S-715E Model number LCD & Touch Panel LCD Panel 15” LED-backlit display Resolution 1024 x 768 (default) Brightness 300 cd/m Touch Screen Flat Projected Capacitive Touch (USB) System Configuration Intel® Celeron® J1900 up to Core™...
  • Page 17 INTRODUCTION S-615E S-715E Model number Physical Dimensions 537 (L) x 440 (W) x 220 (H) mm(flat package) for S-415E/ 615E/ Packing 715E only (P/N: ZKIPK-00108) Net Weight 5.09Kg 5.36 Kg Gross Weight 7.09Kg 7.36 Kg Safety & Environment Product Certification CE / FCC certificated Operation Temperature 0°C to 40°C...

  • Page 18: Peripherals Specifications

    INTRODUCTION Peripherals Specifications LCD display Model No. MN-0810 MN-1090U MN-1510 LCD Panel 8” 10.4” 15” Resolution 800 x 600 1024 x 768 1024 x 768 Viewing Angle 140° (H) / 125° (V) 85° (H) / 85° (V) 160° (H) / 140° (V) Response Time 25ms (typical) 25ms (typical)

  • Page 19: Chapter 2: Preparing For The Installation

    PREPARING FOR THE INSTALLATION Chapter 2 Preparing For the Installation Before you start installing Touch Terminal, read the following instructions. • Saturn Series do not support PCI slot. • Do not insert or remove any device or component from the Saturn Series while the power is turned on.

  • Page 20: Main Board Jumper Setting And Connector Definition

    PREPARING FOR THE INSTALLATION Main Board Jumper Setting and Connector Definition Top Side S-615E SATA1 LED1 Battery LAN1 USB1 USB2 COM1 COM2 COM3 Cash Drawer1 VGA1 TOP and Bottom Side Layout Content List Top Side Connector Information Item Connector Definition...
  • Page 21 PREPARING FOR THE INSTALLATION S-715E TOP and Bottom Side Layout Content List Top Side Connector Information Item Connector Definition Power Trigger SATA1 7+15 SATA Port...

  • Page 22: Bottom Side

    PREPARING FOR THE INSTALLATION Bottom Side S-615E JUSB3 COM4 LVDS1 CONVERTER1 JUSB1 JUSB2 SO DIMM1 Bottom Side Layout Content List Bottom Side Connector Information Item Connector Definition JUSB1/JUSB2 USB 2.0 JUSB3 USB 2.0 LVDS1 LVDS Single/Dual Channel CONVERTER1 LCD Backlight Converter...
  • Page 23 PREPARING FOR THE INSTALLATION S-715E Bottom Side Layout Content List Bottom Side Connector Information Item Connector Definition JUSB1 USB 2.0 JUSB2/JUSB3/JUSB4/JUSB5/JUSB6 USB 2.0 LVDS1 LVDS Single/Dual Channel CONVERTER1 LCD Backlight Converter LED1 System Power LED FAN1 CPU FAN FAN2 System FAN SPK_R1 Speaker SPK_L1...
  • Page 24 PREPARING FOR THE INSTALLATION Jumpers Content List S-615E Battery PIN Header / Jumper List Item Connector Definition SPI BIOS Flash LCD Panel Voltage Select Clear CMOS Cash Drawer Voltage Select COM 1 Port Voltage Select COM 2 Port Voltage Select...
  • Page 25 PREPARING FOR THE INSTALLATION JP1: SPI BIOS Flash Definition Definition 2 4 6 VCC_SPI SPICS SPICLC 1 3 5 SPISO SPISI JP2: LCD Panel Voltage Select Definition Definition 1 2 3 3.3V JP3: Clear CMOS Definition Definition 1 2 3 Normal Clear CMOS JP4: Cash Drawer Voltage Select...
  • Page 26 PREPARING FOR THE INSTALLATION S-715E PIN Header / Jumper List Item Connector Definition SPI BIOS Flash JRTC1 Clear CMOS LCD Panel Voltage Select Cash Drawer Voltage Select COM 1 Port Voltage Select COM 2 Port Voltage Select COM 3 Port Voltage Select...
  • Page 27 PREPARING FOR THE INSTALLATION J2: SPI BIOS Flash connector Definition Definition 2 4 6 VCC_SPI SPICS SPICLC 1 3 5 SPISO SPISI JRTC1: Clear CMOS Definition Definition 1 2 3 Normal Clear CMOS JP2: LCD Panel Voltage Select Definition Definition 1 2 3 3.3V JP3: Cash Drawer Voltage Select...

  • Page 28: System Default Settings

    PREPARING FOR THE INSTALLATION System Default Settings The following is the information on default settings for Touch Terminal serial ports. Voltage Output Definition S-615E/ S-715E Voltage Output Connector Item Power Support COM 1 for extension 5V / 12V Select by jumper...

  • Page 29: Chapter 3: System Memory

    Chapter 3 System Memory Overview The mainboard comes with one 204-pin Double Data Rate 3 Low voltage (DDR3L) Dual Inline Memory Modules (SODIMM) sockets. A DDR3L module has the same physical dimensions as a DDR SODIMM but has a 204-pin footprint compared to the 240-pin DDR2 DIMM.

  • Page 30: Chapter 4: Bios Setup

    BIOS SETUP Chapter 4 BIOS Setup 4-1 S-615E Entering BIOS Setup 1. Connect an alphanumeric USB keyboard to the motherboard. 2. Apply power to the motherboard. 3. When the motherboard boots, press [F2] to display the BIOS Setup. 4. When the motherboard boots, press [F10] to display the Boot Menu.
  • Page 31 BIOS SETUP Main Tab Under <Main>, select < System Time > or <System Date> to change the system date and time. Advanced Tab for setting the LCD Brightness 1. Select <Advanced> and then select <Video Configuration>.
  • Page 32 BIOS SETUP 2. Select <Brightness Control Level>. Default setting is [Level 3]. Security Tab for setting Supervisor Password 1. Select <Security> and then Set <Supervisor Password>.
  • Page 33 BIOS SETUP 2. Enter New Password and then Enter New Password Again and then select [YES]. Power Tab...
  • Page 34 BIOS SETUP Boot Tab for setting Boot Type 1. Select <Boot> and then Set <Boot Type>. 2. Select <Legacy Boot Type> or <UEFI Boot Type>. Default setting is [Legacy Boot Type]. Save & Exit Tab 1. Select [Load Optimal Default], and then press [Enter]. 2.

  • Page 35: 4-2 S-715E

    BIOS SETUP 4-2 S-715E Entering BIOS Setup 1. Connect an alphanumeric USB keyboard to the motherboard. 2. Apply power to the motherboard. 3. When the motherboard boots, press [F2] to display the BIOS Setup. 4. When the motherboard boots, press [F10] to display the Boot Menu. Selecting Menu Options ●To select (highlight) options and menu screens, use the arrow keys.
  • Page 36 BIOS SETUP Advanced Tab for setting the LCD Brightness 1. Select <Advanced> and then select <Video Configuration>. 2. Select <Brightness Control Level>. Default setting is [Level 3].
  • Page 37 BIOS SETUP Security Tab for setting Supervisor Password 1. Select <Security> and then Set <Supervisor Password>. 2. Enter New Password and then Enter New Password Again and then select [YES].
  • Page 38 BIOS SETUP Power Tab Boot Tab for setting Boot Type 1. Select <Boot> and then Set <Boot Type>. 2. Select <Legacy Boot Type> or <UEFI Boot Type>. Default setting is [Legacy Boot Type].
  • Page 39 BIOS SETUP Save & Exit Tab 1. Select [Load Optimal Default], and then press [Enter]. 2. Select [Exit Saving Changes], and then press [Enter].

  • Page 40: Chapter 5: Hardware Installation

    HARDWARE INSTALLATION Chapter 5 Hardware Installation Replacing the Rear Covers 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. 2. Slide the top rear cover off the Touch Terminal. 3. Replace the top rear cover on the Touch Terminal. 4.

  • Page 41: Adjusting The System Stand

    HARDWARE INSTALLATION Adjusting the System Stand CAUTION: Never open the unit unless it is in the lowest horizontal position. Otherwise, system components may be damaged. 1. Support the stand firmly with one hand while pushing the back of the LCD panel backwards with the other hand.

  • Page 42: Installing / Replacing The Hdd

    HARDWARE INSTALLATION Installing / Replacing the HDD WARNINN: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Remove the screw from the HDD/identification reader compartment cover. 2. Detach the HDD/identification reader compartment cover. 3.
  • Page 43 HARDWARE INSTALLATION 11. Align and install the customer display into its slot on the panel stand. 12. Secure the customer display to the Touch Terminal using the two screws. 13. Replace the customer display compartment cover. 14. Connect the customer display’s interface cable to the corresponding port on the Touch Terminal. 15.

  • Page 44: Installing The Secondary Lcd Display (Optional)

    HARDWARE INSTALLATION Installing the Secondary LCD Display (Optional) WARNINN: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. 2.

  • Page 45: Installing The Identification Reader(Msr/Ibutton/Fingerprint/Rfid/M+I) (Optional)

    HARDWARE INSTALLATION Installing the Identification Reader (MSR/iButton/Fingerprint/RFID/M+i) (Optional) WARNINN: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. NOTE: • The identification reader can be installed on either side of the Touch Terminal. 1.
  • Page 46 HARDWARE INSTALLATION Identification Reader Item Name Magnetic Stripe Reader (MSR) MSR + iButton Reader Radio-Frequency Identification Reader (RFID) Fingerprint Reader iButton Reader...

  • Page 47: Installing The Vesa Mount (Optional)

    HARDWARE INSTALLATION Installing the VESA Mount (Optional) NOTE: • Use only wall mount kits approved by the manufacturer. Wall mount kits are sold separately. • The Touch Terminal device is compatible with a VESA mounting hole pattern of 75x75mm. 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. 2.
  • Page 48 Chapter 6 Frequently Asked Questions (FAQ) How do I clear CMOS? S-615E To clear CMOS, do the following: 1. Turn off power and pull out the power cord. 2. Insert the JP3 jumper cap to clear CMOS PIN and remove the jumper cap from clear CMOS PIN.
  • Page 49 FREQUENTLY ASKED QUESTIONS (FAQ) S-715E To clear CMOS, do the following: 1. Turn off power and pull out the power cord. 2. Insert the JRTC1 jumper cap to clear CMOS PIN and remove the jumper cap from clear CMOS PIN. 3.
