HiFive Series
User Manual
Version 2.0

Advertisement

Table of Contents
loading

Related Manuals for Datavan HiFive Series

Summary of Contents for Datavan HiFive Series

  • Page 1 HiFive Series User Manual Version 2.0...
  • Page 2 © Copyright 2019 All rights reserved. This product and related documentation are protected by copyright and are distributed under licenses restricting their use, copying, and distribution. No part of this documentation may be reproduced in any form by any means without prior written authorization of the manufacturer and its licensors, if any.
  • Page 3 • If there is any of the following situation arise, notify a qualified service technician immediately: ◊ The power cord or plug is damaged. ◊ Liquid has been spilt on to the equipment. ◊ The equipment has been dropped and damaged. ◊...
  • Page 4 Federal Communications (FCC Statement) This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesirable operation.
  • Page 5 CB/LVD Statement • A Class III equipment with an enclosure made of HB material and using a non-special connector for the A.C./D.C. input has to have a marking stating the following: “Use only power supplies listed in the user instructions” or “For applicable power supplies see user instructions”.

  • Page 6: Table Of Contents

    Contents Chapter 1: Introduction ............8 Package Contents ..................8 Overview of HiFive Series ............... 9 Front View ....................9 Rear View ....................10 I/O Ports ....................11 Physical Dimensions .................12 Specifications ..................26 Touch Terminal Specifications ..............26 Peripherals Specifications .................27 Chapter 2: Preparing For the Installation ......29 System Default Settings ................
  • Page 7 Chapter 4: Frequently Asked Questions (FAQ) ....44 Question 1: How do I clear CMOS? ............44...

  • Page 8: Chapter 1: Introduction

    INTRODUCTION Chapter 1 Introduction Congratulations on your purchase of this Touch Terminal. Your easy-to-use POS terminal is designed to help you enhance your business flexibility by offering superior customer experience. Package Contents Before setting up your Touch Terminal, check that the package contains the following items. If any of the items is missing or damaged, contact your vendor immediately.

  • Page 9: Overview Of Hifive Series

    INTRODUCTION Overview of HiFive Series The figures in this section illustrate the components (including input and output ports) located at the front and rear of your Touch Terminal. Front View NANO Stand Type / Wall Mounting Type H-610 H-614 H-615...

  • Page 10: Rear View

    INTRODUCTION Rear View NANO Stand Type H-610 H-614 LITE Stand Type H-610 H-614 FLEX Stand Type H-610 H-614 H-615...

  • Page 11: I/O Ports

    INTRODUCTION I/O Ports USB 2.0 ON/OFF LINE OUT USB 2.0 COM 2 COM 1 USB 2.0 DC IN USB 2.0 Side Bottom Item Description DK port Cash Drawer output COM 1/2 ports COM connectors USB2.0 ports USB2.0 connectors Line Out port Audio line output connector DC IN jack 24V DC power input...

  • Page 12: Physical Dimensions

    INTRODUCTION Physical Dimensions VESA Mount H-610...
  • Page 13 INTRODUCTION H-614 H-615...
  • Page 14 INTRODUCTION Standard Display NANO Stand Type (H-610) NANO Stand Type (H-614)
  • Page 15 INTRODUCTION LITE Stand Type (H-610) LITE Stand Type (H-614)
  • Page 16 INTRODUCTION FLEX Stand Type (H-610)
  • Page 17 INTRODUCTION FLEX Stand Type (H-614)
  • Page 18 INTRODUCTION FLEX Stand Type (H-615)
  • Page 19 INTRODUCTION VFD Customer Display LITE Stand Type (H-610)
  • Page 20 INTRODUCTION LITE Stand Type (H-614) FLEX Stand Type (H-610)
  • Page 21 INTRODUCTION FLEX Stand Type (H-614)
  • Page 22 INTRODUCTION FLEX Stand Type (H-615)
  • Page 23 INTRODUCTION Secondary LCD Display FLEX Stand Type (H-610)
  • Page 24 INTRODUCTION FLEX Stand Type (H-614)
  • Page 25 INTRODUCTION FLEX Stand Type (H-615)

  • Page 26: Specifications

    INTRODUCTION Specifications Touch Terminal Specifications HiFive Series Model number H-610 H-614 H-615 LCD & Touch Panel 10.1” LED-backlit 14.0” LED-backlit 15.6” LED-backlit LCD Panel display display display Resolution 1280 x 800 (LVDS) 1366 x 768 (EDP) 1366 x 768 (EDP)

  • Page 27: Peripherals Specifications

    INTRODUCTION HiFive Series Model number H-610 H-614 H-615 Windows 7 / POSReady 7 / Window 8.1 Industry / Windows 10 / O/S Compatibility Linux Kernel 3.0 or above NOTE: Specifications are subject to change without notice. Peripherals Specifications Secondary LCD Display Model no.
  • Page 28 INTRODUCTION Vacuum Fluorescent Display (VFD) Model no. KMOTK-0091A Display Method Vacuum Fluorescent Display (VFD) Brightness 500-1000 cd/m Number of 40 (20 columns x 2 lines) Characters Character Size 6.75 (H) x 3.75 (W) mm Character Format 5 x 7 dot matrix, cursor Character Type 95 Alphanumeric, 32 International characters Dot Size...

  • Page 29: Chapter 2: Preparing For The Installation

    • HiFive Series do not support PCI slot. • Do not insert or remove any device or component from the HiFive Series while the power is turned on. • If using HiFive Series in a dusty environment, clean the Touch Terminal regularly.

  • Page 30: System Default Settings

    PREPARING FOR THE INSTALLATION System Default Settings The following is the information on default settings for Touch Terminal serial ports. U-615 COM1 COM2 COM3 COM4 IRQ4 IRQ3 IRQ5 IRQ10...

  • Page 31: Main Board Jumper Setting And Connector Definition

    PREPARING FOR THE INSTALLATION Main Board Jumper Setting and Connector Definition U-615 Top View Connector/Jumper Description LED2 Power status light LOUT1 Audio line output connector 12V DC power input LAN1 LAN connector (RJ45) USB2 USB2.0 x2 connector USB1 USB3.0 x1 connector CASHDRAW1 Cash Drawer output (RJ12) COM1...
  • Page 32 PREPARING FOR THE INSTALLATION Bottom View Connector/Jumper Description Power button connector SPK1 Speaker connector COM3 COM3 connector for RS-232 POS input device (JST2.0 1x9) JUSB1 USB port for POS input device JUSB2 USB port for USB Touch EDP1 eDP LED Panel LVDS1 LVDS LED Panel SATA1...

  • Page 33: Voltage Output Definition

    PREPARING FOR THE INSTALLATION JCOM2: COM2 D-SUB PIN9 VOLTAGE SELECT 1-2=0V Default = 0V 1 3 5 3-4=+5V 5-6=+12V 2 4 6 Voltage Output Definition U-615 Connector with Voltage Output Location Power Support DC5V/DC12V COM 1 for extension interface (9 PIN of DB-9) Main Board Select by jumper...

  • Page 34: Setting The Lcd Brightness

    PREPARING FOR THE INSTALLATION Setting the LCD Brightness U-615 LVDS Panel 1. When the system boots up, press F2 to enter the BIOS Setup Utility. Select the Advanced tab, then select Video Configuration. 2. Select LVDS Brightness Control Level and set the desired LCD brightness level setting.

  • Page 35: U-615 Edp Panel

    PREPARING FOR THE INSTALLATION U-615 eDP Panel 1. When the system boots up, press F2 to enter the BIOS Setup Utility. Select the Advanced tab, then select Video Configuration. 2. Select eDP Brightness Control Level and set the desired LCD brightness level setting.

  • Page 36: Chapter 3: Hardware Installation

    HARDWARE INSTALLATION Chapter 3 Hardware Installation Adjusting the System Stand (FLEX Type) CAUTION: Never open the unit unless it is in the lowest horizontal position. Otherwise, system components may be damaged. 1. Place the Touch Terminal on a stable surface and carefully lift the LCD panel. 2.

  • Page 37: Adjusting The System Stand (Nano Type)

    HARDWARE INSTALLATION 3. Flip the LCD panel around to face outward. Upper hinge Lower hinge NOTE: • Because the stand joints are tight, you might need to exert someforce to maneuver the Terminal. • Make sure always rotate around the head to the position "a" before adjusting the upper hinge.

  • Page 38: Installing The Power Cord, Power Adapter, And Network Cable

    HARDWARE INSTALLATION Installing the Power Cord, Power Adapter, and Network Cable 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. Then push the stand upwards for easy access to the cable compartment cover. 2.

  • Page 39: Installing The Customer Display (Optional)

    HARDWARE INSTALLATION Installing the Customer Display (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. To configure the COM port voltage setting to +5V, refer to "Main Board Jumper Setting and Connector Definition" on page 31 ~ 33. NOTE: The customer display can only be installed on the Touch Terminal that is equipped with FLEX or LITE stand type.
  • Page 40 HARDWARE INSTALLATION LITE Stand Type 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. 2. Remove the four screws securing the stand to the Touch Terminal. 3. Remove the stand. 4. Detach the I/O port cover. 5.

  • Page 41: Installing The Secondary Lcd Display (Optional)

    HARDWARE INSTALLATION Installing the Secondary LCD Display (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. Then push the stand upwards to access the screws securing the stand to the Touch Terminal.

  • Page 42: Installing The Magnetic Stripe Reader (Msr) (Optional)

    HARDWARE INSTALLATION Installing the Magnetic Stripe Reader (MSR) (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Remove the MSR module compartment cover. 2. Firmly connect the MSR connector into the slot inside the compartment. 3.

  • Page 43: Installing The Vesa Mount (Optional)

    HARDWARE INSTALLATION Installing the VESA Mount (Optional) 1. Align and install the mount bracket on the back of the Touch Terminal. 2. Secure the mount bracket to the Touch Terminal with the four screws. 3. Drill four small holes on the mounting location and insert the plastic washers into the holes. 4.
  • Page 44 FREQUENTLY ASKED QUESTIONS (FAQ) Chapter 4 Frequently Asked Questions (FAQ) Question 1: How do I clear CMOS? U-615 Answer: To clear CMOS, do the following: 1. Turn off the power and pull out the power cord. 2. Remove the battery from the BAT1 connector about 15 seconds and then restore.
