Datavan Glamor Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Glamor Series
G-615S / G-715S / G-715SR
User's Manual V2.0

Advertisement

Table of Contents
loading

Related Manuals for Datavan Glamor Series

Summary of Contents for Datavan Glamor Series

  • Page 1 Glamor Series G-615S / G-715S / G-715SR User’s Manual V2.0...
  • Page 2 About this Manual Thank you for purchasing Glamor Series Touch Terminal. This terminal offers highly enhanced features, with easy connection to various optional devices for optimal performance. This user manual describes how to setup and connect your terminal. Copyright © Copyright 2017 All rights reserved.
  • Page 3 • If there is any of the following situation arise, notify a qualified service technician immediately: ◊ The power cord or plug is damaged. ◊ Liquid has been spilt on to the equipment. ◊ The equipment has been dropped and damaged. ◊...
  • Page 4 Federal Communications (FCC Statement) This device complies with FCC Rules Part 15. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesirable operation.
  • Page 5 CB/LVD Statement • A Class III equipment with an enclosure made of HB material and using a non-special connector for the a.c./d.c. input has to have a marking stating the following: “Use only power supplies listed in the user instructions” or “For applicable power supplies see user instructions”.

  • Page 6: Table Of Contents

    Contents Chapter Introduction ............8 Package Contents ..................8 Overview of Glamor Series ..............9 Front View ....................9 Rear View ....................9 Physical Dimensions ................. 11 Specifications ..................14 Touch Terminal Specifications ..............14 Peripherals Specifications .................17 Chapter Preparing For the Installation ......21 System Default Settings ................
  • Page 7 Chapter Hardware Installation .......... 38 Adjusting the System Stand ..............38 Installing the Power Cord, Power Adapter, and Network Cable ..40 Installing the Customer Display (Optional) ......... 42 Installing the Secondary LCD Display (Optional) ....... 45 Installing the IG-20L MSR (Optional) ............ 49 Installing the IG-20L 2-in-1 Identification Reader (Optional) ....

  • Page 8: Chapter 1: Introduction

    INTRODUCTION Chapter 1 Introduction Congratulations on your purchase of this Touch Terminal. Your easy-to-use POS terminal is designed to help you enhance your business flexibility by offering superior customer experience. Package Contents Before setting up your Touch Terminal, check that the package contains the following items. If any of the items is missing or damaged, contact your vendor immediately.

  • Page 9: Overview Of Glamor Series

    INTRODUCTION Overview of Glamor Series The figures in this section illustrate the components (including input and output ports) located at the front and rear of your Touch Terminal. Front View *with IG-10 identification reader *with IG-20 identification reader Standard Type NOTE: •...
  • Page 10 INTRODUCTION I/O Ports COM 4 G-615S G-715S USB 12V USB 12V USB 24V USB COM G-715SR Item Description DC OUT jack 12V DC power output DC IN jack DC power input COM ports COM connectors K/B port PS/2 keyboard connector DK port Cash Drawer output E-SATAp port...

  • Page 11: Physical Dimensions

    INTRODUCTION Physical Dimensions Standard Display 360.867 414.95 249.833 414.95 249.833...
  • Page 12 INTRODUCTION LCM/VFD Customer Display 290.747...
  • Page 13 INTRODUCTION 8” Secondary LCD Display 349.876 209.954...

  • Page 14: Specifications

    INTRODUCTION Specifications Touch Terminal Specifications Glamor Series Model number G-615S G-715S G-715SR LCD & Touch Panel LCD Panel 15” LED-backlit display Resolution 1024 x 768 (default) Brightness 300 cd/m Touch Screen flat Resistive (USB) / flat Projected Capacitive Touch (USB) System Configuration Celeron®...
  • Page 15 INTRODUCTION Glamor Series Model number G-615S G-715S G-715SR I/O Ports Parallel (option) by cable output USB2.0 USB3.0 eSATAp/USB2.0 combo RJ45 COM Gigabit Ethernet Line out PS/2 keyboard HDMI Reserved onboard RJ12 cash 1 (Dual cash drawer 1(Dual cash drawer support)
  • Page 16 INTRODUCTION Glamor Series Model number G-615S G-715S G-715SR Safety & Environment Product CE / FCC / CB / LVD certificated Certification Operation 0°C to 40°C Temperature Storage -25°C to 70°C Temperature Windows 7/ POSReady 7 / Windows 8.1 Industry / Windows 10/ Linux Kernel 3.0 or above...

  • Page 17: Peripherals Specifications

    INTRODUCTION Peripherals Specifications Vacuum Fluorescent Display (VFD) Model no. CM-7100 Display Method Vacuum Fluorescent Display (VFD) Polarizer color Black Backlight color Yellow green Brightness 500-1000 cd/m2 Display capacity 20 characters x 2 lines Character format 5 x 7 dot matrix, cursor Character type 95 Alphanumeric, 32 International characters Dot size...
  • Page 18 INTRODUCTION 2nd LCD Display Model no. MN-0810 MN-1010 LCD Panel 8” TFT LED backlight 10.4” TFT LED backlight Resolution 800 x 600 Color 262,144 Viewing Angle 140° (H) / 125° (V) 110° (H) / 150° (V) Response Time 25ms (typical) 30ms (typical) Contrast Ratio 500:1 (typical)
  • Page 19 INTRODUCTION Fingerprint Identification Reader RFID Identification Reader iButton Identification Reader Model no. IG-10 Dallas DS1990A compliment / With leading / ending programming iButton Detector function. USB HID Keyboard mode interface Biometric Digital Personal U. are .U 4500B (Optical Type / Blue Light) Module Fingerprint Size: Approx.
  • Page 20 INTRODUCTION Input Data Nominal input voltage DC24V Input voltage range DC22V~DC26V Buffer time 0.5Hr~1Hr (Depending on POS system and configuration.) Output Data in Normal Operation Nominal output voltage DC 21.09V ~ 23.31V Output current 2.7A Current limit Charging Charge characteristic Liner mode curve End-of-charge voltage...

  • Page 21: Chapter 2: Preparing For The Installation

    • Glamor Series do not support PCI slot. • Do not insert or remove any device or component from the Glamor Series while the power is turned on. • If using Glamor Series in a dusty environment, clean the Touch Terminal regularly.

  • Page 22: System Default Settings

    PREPARING FOR THE INSTALLATION System Default Settings The following is the information on default settings for Touch Terminal serial ports. G-615S COM1 COM2 COM3 COM4 COM5 COM6 IRQ4 IRQ3 IRQ5 IRQ10 IRQ5 IRQ10 G-715S/ G-715SR COM1 COM2 COM3 COM4 COM5 COM6 IRQ4 IRQ3...

  • Page 23: Main Board Jumper Setting And Connector Definition

    PREPARING FOR THE INSTALLATION Main Board Jumper Setting and Connector Definition G-615S Connector/Jumper Description LAN connector COM1 connector COM2 connector COM3 connector COM4 connector USB3.0 *1 connector USB2.0 *1 connector USB2.0 *2 connector Cash Drawer output PS/2 keyboard connector CON10 12V DC power output CON11 E-SATA + USB connector...
  • Page 24 PREPARING FOR THE INSTALLATION Connector/Jumper Description M/B Signal convergence connector System Function Connector SATA3.0 2.5” HDD/SSD 7+15PIN Dock DDR3L SO-DIMM (channel 1) DDR3L SO-DIMM (channel 2) Power Button Connector Mini PCIE V1.2 Connector SPI Flash Tool Connector (Factory use only) JP1: LCD Panel Power Selection Setting Function...

  • Page 25: G-715S/G-715Sr

    PREPARING FOR THE INSTALLATION G-715S/G-715SR Top View...
  • Page 26 PREPARING FOR THE INSTALLATION Bottom View Connector/Jumper Description Audio line output connector VGA output connector Gigabit LAN connector USB3.0 *2 connector USB2.0 *2 connector USB2.0 Vertical connector E-SATA + USB connector Cash Drawer output PS/2 keyboard connector CON10 HDMI Vertical connector CON11 COM1 connector CON12...
  • Page 27 PREPARING FOR THE INSTALLATION Connector/Jumper Description SATA Connector (J8 Pin7 Setting by JP8 for SATA DOM) M/B Signal convergence connector SPI Flash Tool Connector (Factory use only) SATA3.0 2.5” HDD/SSD 7+15PIN Dock Mini PCIE V1.2 Connector System Function Connector J14 / J15 DDR3/DDR3L SO-DIMM Fan2 Power Connector JP2 CMOS CLEAR JUMPER...

  • Page 28: Signal Convergence Board Connector

    PREPARING FOR THE INSTALLATION JP9 COM 1 D-SUB PIN9 VOLTAGE SELECT 1-2 = 0V / RI Default = 0V 1 3 5 3-4 = +5V 5-6 = +12V 2 4 6 JP12 Keyboard VOLTAGE SETTING 1-2 = 5VSB Default = Normal 1 2 3 2-3 = +5V JP13 CASH DRAWER VOLTAGE SETTING...

  • Page 29: Extension I/O Brick Board Connector (For G-715Sr Only)

    PREPARING FOR THE INSTALLATION Extension I/O Brick Board Connector (For G-715SR only) Connector/Jumper Description USB signal input COM4 signal input COM 4 D-SUB PIN9 VOLTAGE SELECT COM4 connector 24V Powered USB connector 12V Powered USB connector 12V Powered USB connector USB 2.0 Vertical connector JP1 COM 4 D-SUB PIN9 VOLTAGE SELECT 1-2 = 0V...

  • Page 30: Voltage Output Definition

    PREPARING FOR THE INSTALLATION Voltage Output Definition G-615S Connector with Voltage Output Location Power Support DC5V/DC12V COM 1 for extension interface (9 PIN of DB-9) Main Board Select by BIOS DC5V/DC12V COM 2 for extension interface (9 PIN of DB-9) Main Board Select by BIOS DC5V/DC12V...

  • Page 31: Calibrating The Touch Screen In Windows

    PREPARING FOR THE INSTALLATION Calibrating the Touch Screen in Windows Setting 1. Beep ◊ Configure the Touch sound ◊ Frequency: Set the sound type ◊ Duration: Audio sound length 2. Linearization style Set 9-point or 25-point calibration...
  • Page 32 PREPARING FOR THE INSTALLATION Tools 1. 4 points calibration The device needs to be calibrated for the touch screen to work accurately. Whenever the touch screen seems inaccurate, recalibrate the screen again. Press this button to display a new window to guide you to do the 4 points calibration. On the calibration window, follow the guide and touch and hold the blinking symbol as it moves around the screen.
  • Page 33 PREPARING FOR THE INSTALLATION 4. Draw Test This function is used to check the screen for touch accuracy. Press this button to display a new window to guide you to do the draw test.

  • Page 34: Setting The Lcd Brightness

    PREPARING FOR THE INSTALLATION Setting the LCD Brightness G-615S 1. Press <F2> when system boot. Select <Advanced> tab, then select <Video configuration>. 2. Select <Brightness Control Level> to adjust LCD brightess level.

  • Page 35: G-715S/G-715Sr

    PREPARING FOR THE INSTALLATION G-715S/G-715SR 1. Press <F2> when system boot. Select <Advanced> tab, then select <F81866 Super IO Configuration>. Main Advanced Chipset Boot Security Save & Exit ► PCI Subsystem Settings ► ACPI Settings → ← Select Screen ► Wakeup event Configuration ↑↓...

  • Page 36: Setting The Serial P Ort Voltage (For G-615S Only)

    PREPARING FOR THE INSTALLATION Setting the Serial P ort Voltage (for G-615S only) 1. Press <F2> when system boot. Select <Advanced> tab, then select <S10 FINTEK F81866A>. 2. Select <Voltage Selector>, then click <OK> to change the Serial Port voltage.
  • Page 37 PREPARING FOR THE INSTALLATION...

  • Page 38: Chapter 3: Hardware Installation

    HARDWARE INSTALLATION Chapter 3 Hardware Installation Adjusting the System Stand CAUTION: Never open the unit unless it is in the lowest horizontal position. Otherwise, system components may be damaged. 1. Place the Touch Terminal on a stable surface and carefully lift the LCD panel. NOTE: When handling the LCD panel, do not grab the identification reader devices (on the both sides) to avoid damage to devices.
  • Page 39 HARDWARE INSTALLATION 3. Flip the LCD panel around to face outward. Upper hinge Lower hinge NOTE: • Because the stand joints are tight, you might need to exert someforce to maneuver the Terminal. • Make sure always rotate around the head to the position "a" before adjusting the upper hinge.

  • Page 40: Installing The Power Cord, Power Adapter, And Network Cable

    HARDWARE INSTALLATION Installing the Power Cord, Power Adapter, and Network Cable 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. Remove the cable compartment and the connectors covers. 2. Route the power adapter and the network cable through the cable compartment. Then connect the network cable to the LAN port, and connect the power adapter to the 24V DC IN jack.
  • Page 41 HARDWARE INSTALLATION 3. Align and install the cable compartment and the connectors covers. 4. Connect the power adapter to the power cord. Then plug the other end of the power cord to an electrical outlet. 5. Connect the network cable to connect to a hub or switch. WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection.

  • Page 42: Installing The Customer Display (Optional)

    HARDWARE INSTALLATION Installing the Customer Display (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. Before intallation, make sure to set up the Serial Port voltage to DC 5V, either by jumper (G-715S/G-715SR) or by BIOS (G-615S).
  • Page 43 HARDWARE INSTALLATION 3. Route the customer display’s interface cable on the left side of the cable compartment of the customer display's bracket, as shown in the illustration below. 4. Install the customer display bracket into its slot on the back of the LCD panel. Make sure the bracket is properly aligned with the hinge.
  • Page 44 HARDWARE INSTALLATION Connect the customer display’s interface cable to the RJ-45 COM port on Touch Terminal. 6. Align and install the connectors cover.

  • Page 45: Installing The Secondary Lcd Display (Optional)

    HARDWARE INSTALLATION Installing the Secondary LCD Display (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. Remove the connectors cover.
  • Page 46 HARDWARE INSTALLATION 3. Remove the secondary LCD display compartment. 4. Install the secondary LCD display into its slot on the bracket. Then secure the customer display to the bracket with the two screws (F⊕M4x6.5) and replace the secondary LCD display compartment.
  • Page 47 HARDWARE INSTALLATION 5. Route the secondary LCD display’s power cable, VGA cable, and Touch USB cable (optional) on the cable compartment of the bracket, as shown in the illustration below. 6. Install the secondary LCD display bracket into its slot on the back of the LCD panel. Make sure the bracket is properly aligned with the hinge.
  • Page 48 HARDWARE INSTALLATION 7. Connect the secondary LCD display’s power cable and VGA cable to the corresponding ports on Touch Terminal. 8. Align and install the connectors cover.

  • Page 49: Installing The Ig-20L Msr (Optional)

    HARDWARE INSTALLATION Installing the IG-20L MSR (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Remove the MSR module compartment. 2. Press the latch down to disengage the MSR module cover from its main unit. Then remove the MSR module cover.
  • Page 50 HARDWARE INSTALLATION 4. Secure the MSR module to the Touch Terminal, using the two screws (M3x8). 5. Install the MSR module cover.

  • Page 51: Installing The Ig-20L 2-In-1 Identification Reader (Optional)

    HARDWARE INSTALLATION Installing the IG-20L 2-in-1 Identification Reader (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Remove the reader compartment. 2. Firmly connect the reader connector into the slot inside the compartment. 3.
  • Page 52 HARDWARE INSTALLATION WARNING: The IG-20L cable is connected. Make caution when removing the cover. 4. Secure the reader to the Touch Terminal, using the two screws (M3x8). NOTE: To avoid accidental pulling off the cable, be sure to hold the cover firmly when securing the screws.

  • Page 53: Installing The Secondary Hard Disk Drive (Optional)

    HARDWARE INSTALLATION 5. Install the reader cover. Installing the Secondary Hard Disk Drive (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Install the secondary hard disk drive onto the HDD bracket. Then secure it with the four screws (F⊕M3x4).
  • Page 54 HARDWARE INSTALLATION 2. Connect one end of the eSATAp to SATA 22pin cable into its connector on the secondary hard disk drive. 3. Support the stand firmly with one hand while detaching the stand cover from the stand with the other hand. 4.
  • Page 55 HARDWARE INSTALLATION 5. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. Install the stand cover onto the stand. 6. Remove the cable compartment and the connectors covers. 7. Route the eSATAp to SATA 22pin cable through the cable compartment. Then connect the other end of the eSATAp to SATA 22pin cable to the E-SATAp port.

  • Page 56: Installing The Wireless Module (Optional)

    HARDWARE INSTALLATION 8. Align and install the cable compartment and the connectors covers. Installing the Wireless Module (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Support the stand firmly with one hand while detaching the stand cover from the stand with the other hand.
  • Page 57 HARDWARE INSTALLATION 3. Place the Touch Terminal on a soft and flat surface, with the LCD panel facing down. Install the stand cover onto the stand. 4. Remove the cable compartment and the connectors covers.
  • Page 58 HARDWARE INSTALLATION 5. Route the wireless module cable through the cable compartment. Then connect the wireless module cable to the USB port. 6. Align and install the cable compartment and the connectors covers. 7. Plug the Wi-Fi dongle onto the USB port of the wireless module.

  • Page 59: Installing The Ups Kit (Optional)

    HARDWARE INSTALLATION Installing the UPS Kit (Optional) WARNING: Be sure to turn off the power of the Touch Terminal before making any connection or disconnection. 1. Support the stand firmly with one hand while detaching the stand cover from the stand with the other hand.
  • Page 60 HARDWARE INSTALLATION 3. Connect the one end of the power cable to the 4-pin DC IN jack of the Touch Terminal. Then route the other end of the of the power cable and one end of the power adapter through the cable compartment as shown in the illustration. 4.

  • Page 61: Installing The Vesa Mount (Optional)

    HARDWARE INSTALLATION 6. Align and install the cable compartment and the connectors covers. Installing the VESA Mount (Optional) NOTE: • Use only wall mount kits approved by the manufacturer. Wall mount kits are sold separately. • The Touch Terminal device is compatible with a VESA mounting hole pattern of 75x75mm.
  • Page 62 HARDWARE INSTALLATION 2. Remove the four screws (M4x12) on the hinge. Then remove the stand. 3. Align and install the VESA plate on the back of the Touch Panel using four screws (F⊕M4x10). 4. Attach the mount bracket onto the VESA plate using four screws (M4x10).
  • Page 63 HARDWARE INSTALLATION 5. Drill four small holes on the mounting location and insert the plastic washers into the holes. Then place the four supplied screws into the four holes at the wall bracket, and secure them into the holes on the wall. 6.

  • Page 64: Chapter 4: Frequently Asked Questions (Faq)

    FREQUENTLY ASKED QUESTIONS (FAQ) Chapter 4 Frequently Asked Questions (FAQ) Question 1: Why does the system appear unstable after updating BIOS? G-615S Answer: Load optimized defaults after flashing BIOS. If the system remains unstable, clear CMOS to solve the problem. 1.
  • Page 65 FREQUENTLY ASKED QUESTIONS (FAQ) G-715S /G-715SR Answer: Load optimized defaults (or load SETUP Default) after flashing BIOS. If the system remains unstable, clear CMOS to solve the problem. Steps: On the <Save & Exit> page, select <Restore Defaults>, then select <Yes>.

  • Page 66: Question 2:How Do I Clear Cmos

    FREQUENTLY ASKED QUESTIONS (FAQ) Question 2: How do I clear CMOS? G-615S Answer: To clear CMOS, do the following: 1. Turn off power and pull out the power cord. 2. Insert the jumper cap to clear CMOS PIN and remove the jumper cap from clear CMOS PIN.

  • Page 67: Question 3:How To Use Boot Menu

    FREQUENTLY ASKED QUESTIONS (FAQ) 3. Switch on the power again. 4. Press F2 to enter CMOS setting and load optimized defaults. 5. Save changes and reboot the system. Question 3: How to use Boot Menu? Answer: To use the Boot Menu, do the following: 1.
