- Page 1 HGB 3045 / 55 HBG 3045 / 55 TGB 3045 / 55 TGB 4045 / 100 TGB 4055 / 100 TGB 4055 / 100T S C R U B B E R D RY E R Owner Instructions Warning! Read instructions before using the machine...
-
Page 2: Table Of Contents
S C R U B B E R D RY E R HGB 3045/55, HBG 3045/55, TGB 3045/55, TGB 4045/100, TGB 4055/100, TGB 4055/100T. Index PLEASE READ Machine Overview ........ Pages 2-3 BEFORE COMMENCING Control Panel Overview ........ Page 4 OPERATION Machine Set up Guide ........ -
Page 3: Machine Overview
Machine Overview TGB 4045/100 TGB 4055/100 TGB4055/100T HGB 3045/55 HBG 3045/55 TGB 3045/55 TGB 4045/100 TGB 4055/100 HGB 3045/55 HBG 3045/55 TGB 3045/55 Fuses TGB 4045/100 TGB 4045/100 TGB 4055/100 TGB 4055/100... -
Page 4: Control Panel Overview
Battery Charge Level Indicator Vacuum Pick Up On / Off Water Flow On / Off In the event of a breakdown contact Hours Meter your Numatic dealer or the Handle Position Lever Numatic Technical Triggers help line +44 (0)1460 269268... -
Page 5: Machine Set Up Guide
NOTE: Wear suitable gloves when inserting fuses. Less Battery Models - Numatic International Ltd recommends using Sonnenschein batteries for 3045 machines and MK Batteries for 4045 and 4055 in the machines mentioned in this manual. For full battery spscifications see page 22. -
Page 6: Fitting The Brush / Pad
Push waste collection pipe onto the floor tool; ensure a tight fit. Raise the floor tool for transit or lower for cleaning operation using the lifting handle fitted to the back of the machine. For fitting the floor tool blades (See Page 12). www.numatic.co.uk... -
Page 7: Fitting The Hose Guide
Machine Set-up Guide Fitting the Hose Guide The vacuum hose has a U-bend clip which creates a U-bend in the hose preventing water spillage when the vacuum is switched off. If you need to remove the U-bend clip for any reason always ensure it is refitted correctly before you resume operation. NOTE: DO NOT push the vacuum hose onto the floor tool with the floor tool in the raised position. -
Page 8: Handle Height Adjustment
Do not operate machine unless the Operator Manual has been read and fully understood. The machine is now ready to be moved to the cleaning site. Before performing the cleaning operation, place out appropriate warning signs and sweep or dust-mop the floor. www.numatic.co.uk... -
Page 9: Lowering The Floor Tool
Machine Operation Raising/Lowering the Floor Tool After preparing the floor (see previous section), we are now ready to set the controls to suit the cleaning conditions. Before any settings can be applied, ensure the brush deck is lowered. Move the floor tool lever to its lower position. -
Page 10: Breakaway Floor Tool
First pre-scrub the floor with the floor tool in the raised position, allow the chemical time to work then scrub the area a second time with the floor tool lowered. If streaking occurs wipe floor tool blades clean. NOTE: Care must be taken to reduce speed when cornering or when manoeuvring around obstacles www.numatic.co.uk... -
Page 11: Machine Maintenance
Regular Maintenance ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF PRIOR TO ANY MAINTENANCE USING THE MASTER CONTROL ON/OFF KEY. REMOVE THE KEY PRIOR TO ANY MAINTENANCE OPERATION. After use, empty waste water tank using emptying hose and flush out with clean water. -
Page 12: Changing Floor Tool Blades
Replacement is a reversal of the removal process. Floor Tool Overview 1. Retaining pins x 4 2. Front blade (slotted) 3. Blade carrier 4. Rear blade 5. Floor tool main body NOTE: The blades are designed to be reversible, thus extending their useful working life. www.numatic.co.uk... -
Page 13: Machine Charging
Remove Isolator Plug and connect your external charger. Refit Isolator Plug before operating the machine. Note: Only use the recommended charger and leads. Contact Numatic International Ltd for recommended charger and leads. T 01460 68600... -
Page 14: Battery Care
If the machine will be standing unused for a period of 30 days or more, then batteries must be fully charged and battery fuses removed using the maxi fuse-puller provided, prior to this period. Batteries should be re-charged every three months. Charge fully the day before you start using the machine again. www.numatic.co.uk... -
Page 15: Traction Tgb 4055T
B AT T E RY S C R U B B E R D RY E R , T R A C T I O N D R I V E TGB 4055/100T Control Panel Overview Battery Charge Level Indicator On / Off Switch Vacuum Pick Up On / Off Anti Crush Switch... - Page 16 To disengage the brake / drive mechanism, push the lever down. This allows the machine to be moved in free wheel mode. Note: When the machine is in free wheel mode the brake has been disengaged, avoid slopes. www.numatic.co.uk www.numatic.co.uk...
-
Page 17: Specifications
Specifications HGB 3045/55, HBG 3045/55, TGB 3045/55 BRUSH WEIGHT 29.0 kg GROSS WEIGHT ( i.e. with liquid) 120 kg BRUSH PRESSURE 21.7 g/cm² NETT WEIGHT ( i.e. NO liquid) 90 kg PAD PRESSURE 23.1 g/cm² POWER SOURCE GELL BATTERY 24 VOLT (2 x 12V) 55Ah CLEANING AREA 800m²/HOUR @ 2 kph RUN TIME (BATTERY LIFE) -
Page 18: Rating Label / Personal Protective Equipment / Recycling
NOTE: A risk assessment should be conducted to determine which PPE should be worn. In the event of a breakdown contact Safety Critical Component: your Numatic dealer or the Charging Leads: H05VV-F x 1.0 mm x 3 Core Numatic Technical... -
Page 19: Safety Precautions
Operators shall be adequately instructed as to the correct use of the machine. If this product does not have a factory installed Numatic battery charger, then it is the responsibility of the owner and user of the product to ensure that the charging system and battery combination are compatible, fit for purpose and safe to use. -
Page 20: Schematic Diagram
The batteries are to be disposed of safely and in accordance with the battery directive. 10. Only use genuine Numatic replacement batteries. 11. Do not allow the batteries to become fully discharged; it may not be possible to re-charge them. -
Page 21: Recommended Spare Parts
Too much load on the brush system Decrease the brush load to best suit the operating floor type. Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or Numatic Technical helpline +44 (0)1460 269268 T 01460 68600... - Page 22 TGB 4055T Fault Codes Contact Service Agent www.numatic.co.uk...
-
Page 23: Battery Wiring
Battery Wiring Diagram For optimum performance Numatic International Ltd recomend the use of the following batteries in the Twintec machines. Numatic Machine Numatic Recommended Battery Number TGB 3045 Less Battery Sonnenschein Battery - 55A/h Stud Terminal Gel Type - Suppliers Ref: GF 12 050V... -
Page 24: Company Address
EU Declaration of Conformity www.numatic.co.uk... -
Page 25: Warranty
Warranty T 01460 68600... - Page 26 Notes www.numatic.co.uk...
- Page 27 Notes T 01460 68600...
- Page 28 Tel.: 01460 68600 www.numatic.co.uk This Product has been comprehensively inspected and checked during every stage of its manufacture. Including an in-depth electrical safety and functionality test. Specification subject to change without prior notice www.numatic.co.uk © Numatic International Limited 904581 01/18 (A07)
