OPERATION MANUAL
MODEL AR13H
RIDE-ON TANDEM DRUM ROLLER
PARALLEL DRIVE SYSTEM
(HONDA GX610K1QZB2 GASOLINE ENGINE)
Revision #16 (06/22/21)
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AR13H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MQ Multiquip AR13H

Summary of Contents for MQ Multiquip AR13H

  • Page 1 OPERATION MANUAL MODEL AR13H RIDE-ON TANDEM DRUM ROLLER PARALLEL DRIVE SYSTEM (HONDA GX610K1QZB2 GASOLINE ENGINE) Revision #16 (06/22/21) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...

  • Page 3: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21)

  • Page 4: Table Of Contents

    TABLE OF CONTENTS MULTIQUIP AR-13H RIDE-ON TANDEM DRUM ROLLER Proposition 65 Warning ..........2 Table Of Contents ............. 3 Safety Message Alert Symbols ......4-5 Rules For Safe Operation ........6-8 Operation and Safety Decals ....... 9-10 Specifications (Roller) ..........11 Specifications (Engine) ...........

  • Page 5: Safety Message Alert Symbols

    AR-13H RIDE-ON ROLLER — SAFETY MESSAGE ALERT SYMBOLS HAZARD SYMBOLS FOR YOUR SAFETY AND THE SAFETY OF OTHERS! Potential hazards associated with operation of the pump will be Safety precautions should be followed at all times when operating referenced with Hazard Symbols which appear throughout this this equipment.
  • Page 6 AR-13H RIDE-ON ROLLER — SAFETY MESSAGE ALERT SYMBOLS WARNING - ROTATING PARTS CAUTION - RESPIRATORY HAZARDS NEVER operate equipment with covers, or guards removed. Keep fingers , hands , ALWAYS wear approved respiratory hair and clothing away from all moving protection.

  • Page 7: Rules For Safe Operation

    RULES FOR SAFE OPERATION ■ NEVER touch the hot exhaust manifold, muffler or cylinder. DANGER - Read This Manual! Allow these parts to cool before servicing engine or pump. Failure to follow instructions in this manual may lead to serious injury or even DEATH ! This equipment is to be operated by ■...
  • Page 8 RULES FOR SAFE OPERATION ■ NEVER Run engine without air cleaner. Severe engine MAINTENANCE SAFETY damage may occur. ■ NEVER lubricate components or attempt service on a running ■ ALWAYS read, understand, and follow procedures in machine. Operator’s Manual before attempting to operate equipment. ■...
  • Page 9 RULES FOR SAFE OPERATION LOADING AND TRANSPORTING SAFETY EMERGENCIES ■ ALWAYS know the location of the DANGER - Loading & Unloading the Roller nearest fire extinguisher . DANGER! ALWAYS load and unload the roller on Level, Hard Ground, or Pavement. Serious injury or death can result from improper loading, lifting or unloading.

  • Page 10: Operation And Safety Decals

    OPERATION AND SAFETY DECALS Machine Safety Decals The AR-13H Ride-on Tandem Drum Roller is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustration below and on the next page shows these decals as they appear on the machine. Should any of these decals become unreadable, replacements can be obtained from your dealer.
  • Page 11 OPERATION AND SAFETY DECALS PAGE 10 — AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21)

  • Page 12: Specifications (Roller)

    AR-13H RIDE-ON ROLLER — SPECIFICATIONS (ROLLER) l l o c i f ) . g ) . g i t a ) . g i t a a l l ) . g l l a . n i l l a .

  • Page 13: Specifications (Engine)

    AR-13H RIDE-ON ROLLER — SPECIFICATIONS (ENGINE) i f i o i t - r i r t S e v l i l y , ) n i l o t s i p s i . n i r t S .

  • Page 14: Dimensions

    AR-13H RIDE-ON ROLLER — DIMENSIONS (Side View) (Rear View) Figure 1. AR-13H Roller Dimensions . n i r e t . n i . n i , t f . n i . n i l l a h t i .

  • Page 15: General Information

    AR-13H RIDE-ON ROLLER — GENERAL INFORMATION The roller nominally has an operating weight of 3,088 lbs (1,400 The AR-13H roller has been designed for asphalt application Kg.), but can be increased to 3,309 lbs (1,500 Kg.) by adding and compaction of granular soils used in site preparation. Use water ballast to the rear drum.
  • Page 16 AR-13H RIDE-ON ROLLER — GENERAL INFORMATION Tipping (Rollovers) DANGER - Transporting Safety NEVER! operate the roller on side slopes (Figure 3). The DO NOT allow personnel to stand under or near any possibility exist that the roller could tip over (roll over), thus suspended machine.

  • Page 17: Roller Components

    AR-13H RIDE-ON ROLLER — ROLLER COMPONENTS 12 13 Figure 4. Roller Components 1 PAGE 16 — AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21)
  • Page 18 AR-13H RIDE-ON ROLLER — ROLLER COMPONENTS Figure 4 shows the location of the components and basic 12. Rear Spray Control Valve – This valve controls the components for the AR-13H compaction roller. The function of flow of water to the rear spray bar .Turn the water valve each component or control is described below: to the open position (counterclockwise) to let water flow, Battery –...
  • Page 19 AR-13H RIDE-ON ROLLER — ROLLER COMPONENTS Figure 5. Roller Components 2 Figure 5 shows the location of additional components for the 34. Steering Cylinder – Controls direction of roller. AR-13H compaction roller. The function of each component or 35. Engine – This unit incorporates a HONDA GX-610, air control is described below: cooled engine rated at 18 hp at 3,500 rpm.

  • Page 20: Engine Components

    AR-13H RIDE-ON ROLLER — ENGINE COMPONENTS Figure 6. Honda GX610 Engine Controls and Components INITIAL SERVICING Oil Filler Cap – Remove to add engine oil. The engine (Figure 6) must be checked for proper lubrication and filled with fuel prior to operation. Refer to the manufacturer's engine Oil Dip Stick –...

  • Page 21: Inspection

    AR-13H RIDE-ON ROLLER — INSPECTION Before Starting 3. Check the oil level shown on the dipstick (Figure 8). 1. Read safety instructions at begining of manual. 2. Clean the ROLLER , removing dirt and dust, particularly the engine cooling air inlet, carburetor and air cleaner. 3.
  • Page 22 AR-13H RIDE-ON ROLLER — INSPECTION 4. If the fuel level is low, remove the fuel fillercap/guage and fill Fuel Check with unleaded gasoline. Wipe up any spilled fuel immedi- ately. DANGER - EXPLOSIVE FUEL 5. Pay attention to the fuel tank capacity when replenishing NEVER fill the fuel tank while the engine is running or in fuel (Figure 12).
  • Page 23 AR-13H RIDE-ON ROLLER — INSPECTION Battery Check A 12-volt DC battery (Figure 16) is shipped dry, and will require a proper electrolyte level for operation. ALWAYS be sure that the battery cables are properly connected to the battery terminals as shown below. Generally the RED cable will be connected to the positive terminal of the battery, and the BLACK cable will be connected to the negative terminal of the battery.

  • Page 24: Initial Start-Up

    AR-13H RIDE-ON ROLLER — INITIAL START-UP Initial Start-up Instructions PUSH-IN, THEN PULL Starting TO SET THROTTLE (RPM’s) CAUTION - General Operation Safety DO NOT attempt to operate the roller until the Safety, General Information and Inspection sections have been read and understood.

  • Page 25: Operation

    AR-13H RIDE-ON ROLLER — OPERATION OPERATION 3. Try manuvering the roller a few times to get familar with the handling. Also place the travel lever in the oposite direction Parking Brake to get acquainted with driving in reverse. 1. To release the parking brake, press and hold the release 4.

  • Page 26: Maintenance

    AR-13H RIDE-ON ROLLER — MAINTENANCE Maintenance Perform roller maintenance as indicated by Figure 25 and Table 5. Figure 25. Roller Maintenance Schedule y l i c i l c i l i r p r e l t l i .
  • Page 27 AR-13H RIDE-ON ROLLER — MAINTENANCE HYDRAULIC OIL HYDRAULIC OIL Hydraulic Oil System CAP/FILLER PORT SUCTION FILTER The hydraulic system consists of a two pump stack directly coupled to the engine. A hydraulic valve block (manifold)is provided for quick and easy testing and troubleshooting. Hydraulic oil is filtered by a screen filter located in the tank filler neck, a 40 micron suction filter located in the tank, and a 10 micron return filter , with cold oil bypass valve located in the...
  • Page 28 AR-13H RIDE-ON ROLLER — MAINTENANCE The vibration circuit is controlled by an electric control valve CAUTION - Freewheel Engagement Valve located on the valve block (manifold). This valve is controlled by the “ ON/OFF ” pushbutton switch mounted on top of the travel The freewheel engagement valve (towing) is only for lever.
  • Page 29 AR-13H RIDE-ON ROLLER — MAINTENANCE Forward/Reverse Hydraulic Pressure Test On the manifold block install a 5,000 psi pressure gauge to quick disconnect test port 1. Park the machine on a solid flat surface and stop the engine. Set the parking brake and block the front drum securely . Start the engine and run at full throttle.
  • Page 30 AR-13H RIDE-ON ROLLER — MAINTENANCE Forward/Reverse Relief Valves Drive Adjustment Steering Relief Valve Pressure Adjustment The forward and reverse relief valves (Figure 35) are shim To adjust the relief valve steering pressure perform the following: type cartridge type and are located in the hydrostatic pump (not Insert an 8 mm allen wrench into steering relief port 4 on the manifold block) under plugs 1 and 2 .
  • Page 31 AR-13H RIDE-ON ROLLER — MAINTENANCE Removing and Replacing Hydrostatic Pump Drums and Main Frame Set the parking brake. The front drum is designed to apply vibration and compaction force to the operating surface for compaction. This vibration and Disconnect the battery. compaction force is produced when the vibrator shaft is rotated.
  • Page 32 AR-13H RIDE-ON ROLLER — MAINTENANCE STEP 1 STEP 4 STEP 3 STEP 2 1. JACK FRAME UP SLIGHTLY AT 3. MARK AND DISCONNECT ARTICULATION JOINT. HOSES FROM MOTOR AND MANIFOLD. 2. REMOVE THE FOUR ALLEN HEAD SCREWS HOLDING THE SIDE 4.
  • Page 33 AR-13H RIDE-ON ROLLER — MAINTENANCE STEP 1 STEP 4 STEP 3 STEP 2 1. JACK FRAME UP SLIGHTLY AT 3. MARK AND DISCONNECT ARTICULATION JOINT. HOSES FROM MOTOR. 2. REMOVE THE EIGHT ALLEN HEAD 4. REMOVE FOUR ALLEN HEAD SCREWS HOLDING THE SIDE SCREWS FROM DRUM SUPPORT COVER OF THE DRUM SUPPORT PLATE.
  • Page 34 AR-13H RIDE-ON ROLLER — MAINTENANCE STEP 6 STEP 4 STEP 2 STEP 5 STEP 1 STEP 3 STEP 4 1. JACK FRAME UP SLIGHTLY AT REMOVE ALLEN HEAD SCREWS ARTICULATION JOINT. HOLDING THE SIDE COVER OF THE DRUM SUPPORT PLATE. 2.
  • Page 35 AR-13H RIDE-ON ROLLER — MAINTENANCE Alternator/Regulator The AR-13H is equipped with a 20 amp charging system. This system uses three charge coils connected in parallel. The windings of each coil are wound with heave-duty insulated wire and are further protected by insulating material for long life. A voltage regulator is provided to control the amount of charge voltage being delivered to the 12 volt electrical system.

  • Page 36: Preparation For Long-Term Storage

    AR-13H RIDE-ON ROLLER — PREPARATION FOR LONG-TERM STORAGE Roller Storage For storage of the roller for over 30 days, the following is recommended:  Drain the fuel tank completely, or add STA-BIL to the fuel.  Run the engine until the fuel in the injection system is completely consumed.

  • Page 37: Manifold Test Ports

    AR-13H RIDE-ON ROLLER — MANIFOLD TEST PORTS Figure 29. Manifold Test Ports PAGE 36 — AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21)

  • Page 38: Hydraulic System Diagram

    AR-13H RIDE-ON ROLLER — HYDRAULIC SYSTEM DIAGRAM Figure 30. Hydraulic System Diagram AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21) — PAGE 37...

  • Page 39: Electric Wiring Diagram (S/N 241001 And Below)

    AR-13H ROLLER — ELECTRIC WIRING DIAGRAM (S/N 241001 AND BELOW S/N 241001 AND BELOW Figure 31. Electrical Diagram PAGE 38 — AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21)

  • Page 40: Electric Wiring Diagram (S/N 241002 And Above)

    AR-13H ROLLER — ELECTRIC WIRING DIAGRAM (S/N 241002 AND ABOVE S/N 241002 AND ABOVE AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21) — PAGE 39...

  • Page 41: Hydraulic Hose Connections

    AR-13H RIDE-ON ROLLER — HYDRAULIC HOSE CONNECTIONS MANIFOLD FROM OPERATOR’S FRONT RIGHT SIDE POSITION FRONT LEFT SIDE FROM OPERATOR’S POSITION NOTES HOSES SHADED FOR VISUAL CLARITY. Figure 32. Hydraulic Hose Connections 1 PAGE 40 — AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21)
  • Page 42 AR-13H RIDE-ON ROLLER — HYDRAULIC HOSE CONNECTIONS FRONT RIGHT MOTOR STEERING COLUMN MANIFOLD REAR LEFT MOTOR FROM OPERATOR’S POSITION NOTES FRONT LEFT MOTOR HOSES SHADED FOR VISUAL CLARITY. Figure 33. Hydraulic Hose Connections 2 AR-13H RIDE-ON TANDEM DRUM ROLLER — OPERATION MANUAL — REV. #16 (06/22/21) — PAGE 41...

  • Page 43: Troubleshooting (Roller)

    AR-13H RIDE-ON ROLLER — TROUBLESHOOTING (ROLLER) r b i i t a c i l c i l . e r a t l t l o l o s r b i i t a t i w l i o r o f i t n .

  • Page 44: Troubleshooting (Engine)

    AR-13H RIDE-ON ROLLER — TROUBLESHOOTING (ENGINE) g n i j n i t c e n o i l e u r i t l e u e t s c e f v i t l e u c a l l e u e t l i g o l...
  • Page 45 AR-13H RIDE-ON ROLLER — TROUBLESHOOTING (ENGINE) t l i f . r e l i f r e t t l i f . r e n i t y l e g i t e r i l o r v e l r o f e r r...
  • Page 46 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
