OPERATION AND PARTS MANUAL
SERIES
MODEL MRH800DS
VIBRATION ROLLER
(YANMAR L100EE-DEVMK2 ENGINE)
Revision #4 (11/07/18)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mikasa MRH800DS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MQ Multiquip Mikasa MRH800DS

Summary of Contents for MQ Multiquip Mikasa MRH800DS

  • Page 1 OPERATION AND PARTS MANUAL SERIES MODEL MRH800DS VIBRATION ROLLER (YANMAR L100EE-DEVMK2 ENGINE) Revision #4 (11/07/18) To find the latest revision of this publication, visit our website at: www.multiquip.com...

  • Page 2: Proposition 65 Warning

    PROPOSITION 65 WARNING Diesel engine exhaust and some of PAGE 2 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)

  • Page 3: Table Of Contents

    TABLE OF CONTENTS MRH800DS VIBRATION Yanmar L100EE-DEVMK2 Engine ROLLER Cylinder Block Assembly ........72-73 Cylinder Head and Cover Assembly ....74-75 Proposition 65 Warning ..........2 Muffler Assembly ..........76-77 Here's How To Get Help ..........3 Air Cleaner Assembly......... 78-79 Table Of Contents .............

  • Page 4: Table Of Contents

    PARTS ORDERING PROCEDURES Ordering parts has never been easier! Choose from three easy options: Effective: January 1 , 2006 Order via Internet (Dealers Only) Best Deal! If you have an MQ Account, to obtain a Username Order parts on-line using Multiquip’s SmartEquip website! and Password, E-mail us at: parts@multiquip.

  • Page 5: Parts Orderirocedures

    SAFETY INFORMATION Do not operate or service the equipment before reading The following table shows the potential hazards associated the entire manual. Safety precautions should be followed with the operation of this equipment. at all times when operating this equipment. Failure to read and understand the safety Symbol Safety Hazard...

  • Page 6: Safety Message Alert Symbols

    SAFETY INFORMATION GENERAL SAFETY NOTICE CAUTION  This equipment should only be operated by trained and qualifi ed personnel 18 years of age and older.  NEVER operate this equipment without proper protective  Whenever necessary, replace nameplate, operation and clothing, shatterproof glasses, respiratory protection, hearing protection, steel-toed boots and other protective safety decals when they become diffi...
  • Page 7 SAFETY INFORMATION ROLLER SAFETY  DO NOT use worn-out hoses or couplings. Inspect daily.  ALWAYS store equipment properly when it is not being DANGER used. Equipment should be stored in a clean, dry location  NEVER operate the equipment in an explosive out of the reach of children and unauthorized personnel.

  • Page 8: Rules For Safe Operation

    SAFETY INFORMATION  DO NOT overfi ll tank, since spilled fuel could ignite if it NOTICE comes into contact with hot engine parts or sparks from  NEVER run engine without an air fi lter or with a dirty air the ignition system.
  • Page 9 SAFETY INFORMATION ENVIRONMENTAL SAFETY  If the battery liquid (dilute sulfuric acid) comes into contact with eyes, rinse eyes immediately with plenty NOTICE of water and contact the nearest doctor or hospital to seek medical attention.  Dispose of hazardous waste properly. Examples of potentially hazardous waste CAUTION are used motor oil, fuel and fuel fi...

  • Page 10: Operation And Safety Decals

    OPERATION AND SAFETY DECALS Figure 1 displays the operation and safety decals as they appear on the vibration roller. Should any of these decals become damaged or unreadable, contact the Multiquip Parts Department for a replacement set. Figure 1. Operation and Safety Decals PAGE 10 —...
  • Page 11 OPERATION AND SAFETY DECALS Figure 1. Operation and Safety Decals (Continued) MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18) — PAGE 11...

  • Page 12: Roller Specifications

    SPECIFICATIONS PAGE 12 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)

  • Page 13: Engine Specifications

    SPECIFICATIONS - r i l e s i l y o r t p s i y t i s t r e t i l ) s r l i O y t i s t r . 1 ( e t i l ) s r s b l...

  • Page 14: Dimensions

    DIMENSIONS . n i . n i . n i . n i . n i . n i . n i . n i . n i . n i . n i . n i Figure 2. MRH-800DS Vibration Roller Dimensions PAGE 14 —...

  • Page 15: Features

    GENERAL INFORMATION The Mikasa Model MRH-800DS is a powerful compacting tool capable of applying a tremendous force in consecutive impacts to a soil surface. Its applications include soil compacting for backfilling for gas pipelines, water pipelines and cable installation work. The impact force of the MRH-800DS levels and uniformly compacts voids between soil particles to increase dry density.

  • Page 16: Vibration Roller Components

    COMPONENTS Figure 3. MRH-800DS Vibration Roller Components PAGE 16 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 17 COMPONENTS Figure 3 illustrates the location of the major components for the MRH-800DS Vibration Roller. The function of each component is described below: Fuel Tank/Cap – Fill with diesel fuel. Fuel tank holds approximately 2 gallons (7.5 liters). DO NOT top off fuel. Wipe up any spilled fuel immediately.

  • Page 18: Handle Bar/Lever Components

    HANDLE BAR/LEVER COMPONENTS Figure 4. MRH-800DS Lever Components PAGE 18 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 19 HANDLE BAR/LEVER COMPONENTS HANDLE BAR/LEVER COMPONENTS Figure 4 illustrates the location of the major lever components on the handle bar of the machine. Each component is described below: Travel Lever – Controls the direction of travel of the machine (forward and reverse). Horn Button –...

  • Page 20: Engine Components

    BASIC ENGINE Figure 5. MVH-402DSB Engine Components ENGINE COMPONENTS Figure 5 illustrates the location of the major engine Recoil Starter – Housing for pull rope and starter. components of the machine. Each component is described Oil Filler Cap/Dipstick – Remove this cap to add oil to the below: oil tank.
  • Page 21 NOTES MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18) — PAGE 21...

  • Page 22: Inspection

    INSPECTION DANGER 3. Insert and remove the dipstick without screwing it into the filler neck. Check the oil level shown on the dipstick. NEVER operate the compactorin a confined 4. If the oil level is low, fill to the edge of the oil filler hole with the area or enclosed area recommended oil type (Table 3).
  • Page 23 INSPECTION Checking Levers and Horn Checking The Vibrator Oil Level Check travel, vibration, and throttle levers to make sure Check vibrator casing for any oil leakage. they are functioning properly (Figure 4). If any leakage is noticed, remove the level plug on the side With travel lever placed in reverse, push the deadman of the plate (Figure 9).

  • Page 24: Initial Startup

    STARTUP CAUTION : Insert the starter key into the key switch and turn it to the RUN position (Figure 14). The buzzer should sound at this time. DO NOT attempt to operate the roller until the Safety, General Information and Inspection sections of this manual have been read and thoroughly understood .
  • Page 25 STARTUP Recoil Start Pull the starting handle hard and fast to start engine Move the throttle lever to the RUN position. (Figure 19). Open the fuel cock by turning it clockwise to the down position (Figure 16). Fuel Cock (Open Position) Figure 19.

  • Page 26: Operation

    OPERATION VIBRATING TRAVELING Shift the vibration lever AWAY from its OFF position. The Before starting to travel, make sure to release parking brake vibration lever will automatically spring forward and the located on the left side of the rear roller. If the parking brake roller will start vibrating (Figure 21).
  • Page 27 OPERATION SAFETY FEATURES A horn is provided to warn of approach. Bypass Valve The dead man device prevents accidental traveling Bolt in reverse. It automatically makes the travel lever return to neutral position by stopping the machine when an object comes in contact with the dead man device.

  • Page 28: Maintenance

    MAINTENANCE CAUTION: CAUTION: Inspection and other services should ALWAYS Fuel piping and connections should be replaced be carried out on hard and level ground with the every 2 years. engine shutdown. Inspection and Maintenance Service Tables. 1. To make sure your plate compactor is always in good working condition before using, carry out the maintenance inspection in accordance with Tables 5 through 7.

  • Page 29: Maintenance

    MAINTENANCE CAUTION: Engine Oil Replacement: 1. Replace engine oil in the first 25 hours of operation and NEVER attempt to check the V-belt with the en- every 50 to 100 hours afterwards. gine running. Severe injury can occur if your hand gets caught between the V-belt and the clutch 2.
  • Page 30 MAINTENANCE      DO NOT close the exhaust outlet of battery. The gas pressure MACHINE MAINTENANCE building up in the battery may cause explosion. At the end of each day’s operation, wash down dust and      Before using a battery charger, read and understand the dirt off the machine.
  • Page 31 MAINTENANCE FORWARD AND REVERSE TRAVEL ADJUSTMENT If neutral position for forward and reverse travel has been displaced, conduct the neutral adjustment. If roller travels forward with the ball of ball plunger remaining in V slot of the guide, loosen M8 bolt and slide the slide plate slightly toward the engine.
  • Page 32 MAINTENANCE r o t l i O l i O e t i l ) s r i t a n i r ) r e t i n l l a i r e t i t a l i O l i O e t f - l l...
  • Page 33 MAINTENANCE Handle Bar Release Pin Grease Fitting Figure 32. Handle Bar Maintenance Vibrator Oil Vibrator Oil Drain Plug Level Plug Figure 29. Vibrator Oil Maintenance Clutch Box Grease Fitting FIgure 30. Bearing Cover Grease Fitting Figure 33. Clutch Box Maintenance Bearing Cover Grease Fitting Figure 31.

  • Page 34: Roller Troubleshooting

    NOTES PAGE 34 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 35 TROUBLESHOOTING (ROLLER) t i n r t t . l e i k r l l i t i k r v e l . r e e v i f i r t u l c u l c i l p a l f c a l...

  • Page 36: Engine Troubleshooting

    TROUBLESHOOTING (ENGINE) l o r " n p " o i t i l o r v e l S " p " o i t i i h c i t c . l e r i t e v i l i f r e t c a l...
  • Page 37 TROUBLESHOOTING (ENGINE) t l i f . r e l i f r e t t l i f . r e n i t y l e l o r v e l r o f e r r e v i o i t o i t i...

  • Page 38: Component Dra Component Drawings Wings Explanation Of Code In Remarks Column

    EXPLANATION OF CODES IN THE REMARKS COLUMN The following section explains the different symbols and QTY. Column remarks used in the Parts section of this manual. Use the Numbers Used — Item quantity can be indicated by a help numbers found on the back page of the manual if there number, a blank entry, or A/R.

  • Page 39: Suggested Spare Parts

    SUGGESTED SPARE PARTS MRH-800DS VIBRATION ROLLER 1 TO 3 UNITS WITH YANMAR L100EE-DEVMK2 DIESEL ENGINE Qty. Description 1 .... 954401890 ..FILTER, WATER TANK 2 .... 954001380 ..FILTER, HYDRAULIC OIL 2 .... 070503000 ..V-BELT, ENGINE 1 .... 956100022 ..THROTTLE WIRE 1 ....

  • Page 40: Decal Placement

    NAMEPLATE AND DECALS PAGE 40 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 41 NAMEPLATE AND DECALS PART NO. PART NAME QTY. REMARKS 920205690 DECAL, BRAKE LEVER ........1 ..NPA-569 920209660 DECAL, CAUTION - ENG. SPEED, NPA-966 ...1 ..S/N D1294 AND BELOW 920222080 DECAL, CAUTION - ENG. SPEED NPA-2208 ..1 ..S/N D1295 AND ABOVE 920206280 DECAL, DANGER - PINCH POINT ....1 ..

  • Page 42: Axle Assembly

    AXLE ASSY. PAGE 42 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 43 AXLE ASSY. PART NO. PART NAME QTY. REMARKS 515112960 DRUM 515112970 DRUM 515333990 GEAR PLATE 515334000 GEAR (39) 509429660 COLLAR 405510 001121630 BOLT 16X30 T 515117050 DRUM BRACKET (R) 506425980 FELT (DRUM) 5X5X1200 060605020 OIL SEAL VC-55727 042006308 BEARING 6308DU 020130240 NUT M30, P2.0 031130450...

  • Page 44: Base Assembly

    BASE ASSY. PAGE 44 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 45 BASE ASSY. PART NO. PART NAME QTY. REMARKS 515114460 BASE (YANMAR-L100) 939010010 SHOCK ABSORBER, STOPPER 45 030210250 WASHER, LOCK M10 020310080 NUT M10 930710031 SHOCK ABSORBER RV1-100 020316130 NUT M16 030216400 WASHER, LOCK M16 001221625 BOLT 16X25 T 001221440 BOLT 14X40 T 030214350 WASHER, LOCK M14 515447010...

  • Page 46: Front Guard Assembly

    FRONT GUARD ASSY. PAGE 46 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 47 FRONT GUARD ASSY. PART NO. PART NAME QTY. REMARKS 031110160 FLAT WASHER, M10 030210250 LOCK WASHER, M10 001221035 BOLT 10x35 mm 515336200 FRONT GUARD 515336210 BUMPER 515449720 SPACER, BUMPER 001221040 BOLT 10X40 T 031110160 WASHER, FLAT M10 953405940 PIPE INSERT PZ-7 MRH800DS ROLLER —...

  • Page 48: Side Cover Assembly

    SIDE COVER ASSY. PAGE 48 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 49 SIDE COVER ASSY. PART NO. PART NAME QTY. REMARKS 030210250 WASHER, LOCK M10 515336250 SUPPORT, COVER 515449890 ROD HOLDER 515334600 RUBBER HINGE 515010090 RIVET 515010100 RIVET 092004008 SCREW 4X8 515113080 COVER, E/G 515447030 STAY, COVER (R) 012210020 BOLT 10X20 T ..........5 ..REPLACES 001221020 031110160 WASHER, FLAT M10 0105050616...

  • Page 50: Water Tank Assembly

    WATER TANK ASSY. PAGE 50 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 51 WATER TANK ASSY. PART NO. PART NAME QTY. REMARKS 515114200 WATER TANK 954300340 CAP, WATER TANK /MR 001241030 BOLT 10X30 U 033910010 WASHER 10.5X21X2 SUS 022910180 NYLON NUT M10 (SUS) 954404910 HOSE JOINT 17D 954404890 FILTER, TANK /MR 953404900 PACKING 26X36X3 959404880 NUT 3/4 506403990...

  • Page 52: Hydraulic System Assembly

    HYDRAULIC SYSTEM ASSY. PAGE 52 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 53 HYDRAULIC SYSTEM ASSY. PART NO. PART NAME QTY. REMARKS 954001350 OIL FILTER CPO 3-80 ..... 1 ..INCLUDES ITEMS W/ 954001390 FILTER HEAD 954001380 OIL ELEMENT 954001530 ELBOW LIN-1/2-PT3/8 954001501 TUBE 9.6-12.7 - 300 959020011 SPIRAL TUBE 11D-350L 954001511 TUBE 9.6-12.7-360 955404275 SPIRAL TUBE 11D-400L 515010050...
  • Page 54 HYDRAULIC SYSTEM ASSY. PAGE 54 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 55 HYDRAULIC SYSTEM ASSY. PART NO. PART NAME QTY. REMARKS 515447160 HOLDER, UPPER 515447170 HOLDER, LOWER 001520820 SOCKET HEAD BOLT 8X20 T 515447140 COVER, PIPE 012210020 BOLT 10X20 T ......4 ..REPLACES 001221020 031110160 WASHER, FLAT M10 515447150 PIPE, OM-B--OM-A 515447300 STAY, PIPE 607010040...

  • Page 56: Hydraulic Oil Tank Assembly

    HYDRAULIC OIL TANK ASSY. PAGE 56 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 57 HYDRAULIC OIL TANK ASSY. PART NO. PART NAME QTY. REMARKS 515114221 OIL TANK , (GREEN) 515010140 OIL TANK , (ORANGE) 953405840 DRAIN PLUG M18 ......1 ..REPLACES 953102781 953402930 COPPER PACKING 19X30X1 953400270 PLUG 1/4X14 10L 953405260 PACKING 1/4 (CU) 959010120 LEVEL GAUGE/L =60 030210250...

  • Page 58: Engine Assembly

    ENGINE ASSY. PAGE 58 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 59 ENGINE ASSY. PART NO. PART NAME QTY. REMARKS 914410004 ENGINE ASSY. L100EE-DEVMK2 515447020 COUPLING PIN 952400690 WASHER 9X35X4.5 011208025 BOLT 8X25 T ............ 1 ..REPLACES 001220825 030210250 WASHER M10 012010030 BOLT 10X30 T ..........2 ..REPLACES 001221030 070503000 V-BELT 3V- 300 515447050 TIGHTENER PULLEY 046006004...

  • Page 60: Electric Device Assembly

    ELECTRIC DEVICE PAGE 60 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 61 ELECTRIC DEVICE PART NO. PART NAME QTY. REMARKS 457333310 KEY SWITCH INCLUDES ITEMS W/ 955000010 KEY, PAIR 515449680 WIRE HARNESS (L100) 955300400 BUZZER (EBL) 515449860 HARNESS (L1200) 515448210 ROD, BATTERY 607010080 COTTER PIN 6 515447370 HOLDER, BATTERY 952404470 WASHER M6 ............ 2 ..REPLACES 031106100 0037806000 WING NUT M6 ..........

  • Page 62: Clutch (Vibration) Assembly

    CLUTCH (VIBRATION) ASSY. PAGE 62 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 63 CLUTCH (VIBRATION) ASSY. PART NO. PART NAME QTY. REMARKS 515910010 CLUTCH AY (VIB.) ........... 1 ..INCLUDES ITEMS W/ 515447070 COUNTER PULLEY 130D-3V1 515212980 COUNTER BRACKET 951403020 KEY 7X7X26 043006206 BEARING 6206V 080100620 STOP RING R-62 952402470 WASHER 11366 012010030 BOLT 10X30 T ..........2 ..REPLACES 001221030 030210250 WASHER M10 509434770...

  • Page 64: Vibrator Assembly

    VIBRATOR ASSY. PAGE 64 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 65 VIBRATOR ASSY. PART NO. PART NAME QTY. REMARKS 515113090 VIBRATING CASE 515334110 ROTARY SHAFT, DRIVE ........ 1..- 215 #2 515334111 ROTARY SHAFT, DRIVE ........ 1..F2116- *2 515334120 ROTARY SHAFT, DRIVEN ......1..- 2115 #2 515334121 ROTARY SHAFT, DRIVEN ......1..F2116-*2 515334130 ECCENTRIC ROTATOR ........

  • Page 66: Upper Control Arm Assembly

    UPPER CONTROL ARM ASSY. PAGE 66 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 67 UPPER CONTROL ARM ASSY. PART NO. PART NAME QTY. REMARKS 959403840 BAR GRIP, I.D. 12MM 953402930 COPPER PACKING 19X30X1 509010130 BUSHING MB1825DU 952405700 WASHER 19X49X0.6 952403690 CONICAL SPRING WASHER M18 020418110 NUT M18, H=11 515447410 LEVER JOINT, TRAVELLING 011208030 BOLT 8X30 T ........... 3 ..REPLACES 001220830 030208200 WASHER, LOCK M8 02108060...
  • Page 68 UPPER CONTROL ARM ASSY. PAGE 68 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 69 UPPER CONTROL ARM ASSY. PART NO. PART NAME QTY. REMARKS 951401431 KEY 5X5X8 952404790 WASHER 13306 032212250 CONICAL SPRING WASHER M12 0039312000 NUT M12 ............3 ..REPLACES 020312100 515334820 509010140 BUSHING MB1625DU 515447720 DISC PLATE, DEAD-MAN 030212300 WASHER, LOCK M12 509436980 SPRING, DEAD-MAN 509436990...

  • Page 70: Lower Control Arm Assembly

    LOWER CONTROL ARM ASSY. PAGE 70 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 71 LOWER CONTROL ARM ASSY. PART NO. PART NAME QTY. REMARKS 001222055 BOLT 20X75 T 031120320 WASHER, FLAT M20 032220450 CONICAL SPRING WASHER M20 020320160 NUT M20 022522017 LOCK NUT U-M20 030208200 WASHER, LOCK M8 501011162 ROD END PR6-209 952404470 WASHER 6.5X15X1.6 030206150 WASHER, LOCK M6 515334230...

  • Page 72: Yanmar L100Ee-Devmk2 Engine Cylinder Block Assembly

    YANMAR L100EEDEVMK2 — CYLINDER BLOCK ASSY. PAGE 72 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 73 YANMAR L100EEDEVMK2 — CYLINDER BLOCK ASSY. PART NO PART NAME QTY. REMARKS 71497001560 BLOCK ASSY. CYLINDER ......1 ....INCLUDES ITEMS W/ 11435001700 COVER, STARTER 26106100122 BOLT M10X 12 PLATED 10502501220 NUT 10 11465001230 STUD, CYLINDER HEAD 11465001240 STUD, CYLINDER HEAD 11465001250 NUT 10 11465001260...

  • Page 74: Cylinder Head And Cover Assembly

    YANMAR L100EEDEVMK2 — CYLINDER HEAD AND COVER ASSY. PAGE 74 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 75 YANMAR L100EEDEVMK2 — CYLINDER HEAD AND COVER ASSY. PART NO PART NAME QTY. REMARKS 11465111020 CYLINDER HEAD 11465111100 VALVE, SUCTION 11465111110 VALVE, EXHAUST 11465011121 SPRING, VALVE 11962011180 RETAINER, SPRING 11465111250 SUPPORT CMP, ARM....... 1 ....INCLUDES ITEMS W/ 11465111260 SUPPORT, ROCKER ARM 11465111650 ARM ASSY.

  • Page 76: Muffler Assembly

    YANMAR L100EEDEVMK2 — MUFFLER ASSY. PAGE 76 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 77 YANMAR L100EEDEVMK2 — MUFFLER ASSY. PART NO PART NAME QTY. REMARKS 11465013201 GASKET, NON-ASB. 11497013551 MUFFLER ASSY........1 ....INCLUDES ITEMS W/ 16026001580 BOLT M 6 X 6 11497013561 MUFFLER 11497013700 COVER A, MUFFLER 11497013710 COVER, MUFFLER 26106080182 BOLT, M 8 X 16 PLATED 26216080182 STUD, M 8 X 18 PLATED 26366080002...

  • Page 78: Air Cleaner Assembly

    YANMAR L100EEDEVMK2 — AIR CLEANER ASSY. PAGE 78 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 79 YANMAR L100EEDEVMK2 — AIR CLEANER ASSY. PART NO PART NAME QTY. REMARKS 11465012211 GASKET, AIR CLEANER 71465012560 CLEANER ASSY. AIR ....... 1 ....INCLUDES ITEMS W/ 11465012520 COVER, AIR CLEANER 11465012530 CASE, AIR CLEANER 11425212560 WASHER M 8, SEAL 11465012590 ELEMENT W/PRE-FILTER 11425212550 WING, NUT M 8...

  • Page 80: Crankshaft, Piston And Camshaft Assembly

    L100EEDEVMK2 — CRANKSHAFT/PISTON/CAMSHAFT ASSY. PAGE 80 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 81 L100EEDEVMK2 — CRANKSHAFT/PISTON/CAMSHAFT ASSY. PART NO PART NAME QTY. REMARKS 71466014100 CAMSHAFT ASSY., D 11465014200 TAPPET 11477114260 TAPPET, F.O. 11465014401 ROD, PUSH 71465421730 CRANKSHAFT ASSY. 12271001220 NUT, M18 11465021551 WASHER, FLYWHEEL 11466221593 FLYWHEEL, DEJ., W/GEAR ..... 1 ....INCLUDES ITEMS W/ 11466221601 GEAR, RING 22512050140...

  • Page 82: Lub. Oil Pump And Governor Assembly

    L100EEDEVMK2 — LUB. OIL PUMP AND GOVERNOR ASSY. PAGE 82 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 83 L100EEDEVMK2 — LUB. OIL PUMP AND GOVERNOR ASSY. PART NO PART NAME QTY. REMARKS 11465032010 PUMP ASSY. LUB. OIL 11425032070 COVER, LUB. OIL PUMP 10333832570 O-RING 22312030160 PARALLEL PIN 3 X 16 26476060142 BOLT, M 6 X14, TAPPING 11425035110 STRAINER, LUB. OIL ASSY....1....INCLUDES ITEMS W/ 11425035070 STRAINER, LUB.

  • Page 84: Cooling And Starting Device Assembly

    L100EEDEVMK2 — COOLING AND STARTING DEVICE ASSY. PAGE 84 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 85 L100EEDEVMK2 — COOLING AND STARTING DEVICE ASSY. PART NO PART NAME QTY. REMARKS 11465045201 COVER 11435045320 RUBBER, SEAL 11435045340 COLLAR 18372055210 GROMMET 26106060202 BOLT M 6 X 20 PLATED 11466845102 CASE, FAN SILVER 17 11425045301 RUBBER, CUSHION 11425045310 COLLAR 11465045330 SEAL, FAN CASE 11437045351 BOLT, FAN CASE...

  • Page 86: Fuel Injection Pumpassembly

    L100EEDEVMK2 — FUEL INJECTION PUMP ASSY. PAGE 86 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 87 L100EEDEVMK2 — FUEL INJECTION PUMP ASSY. PART NO PART NAME QTY. REMARKS 71465651110 PUMP ASSY., FUEL INJECTORS ..1....INCLUDES ITEMS W/ 10554651020 GASKET 11425051080 PLATE 11497051100 BODY, F.I. PUMP 11425051160 SPRING 11465051300 VALVE ASSY., DELIVERY 10554651330 SPRING, DELIVERY VALVE 11425051340 HOLDER, F.

  • Page 88: Fuel Tank And Fuel Line Assembly

    L100EEDEVMK2 — FUEL TANK AND FUEL PIPE ASSY. PAGE 88 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 89 L100EEDEVMK2 — FUEL TANK AND FUEL PIPE ASSY. PART NO PART NAME QTY. REMARKS 71465055130 TANK ASSY., FUEL ........ 1 ....INCLUDES ITEMS W/ 11428855041 CAP ASSY., FUEL TANK ......1 ....INCLUDES ITEMS W/ 11428855081 VALVE 11425055100 FILTER, FUEL 11465055150 PIPE, GAUGE 10385455220...

  • Page 90: Starting Motor And Dynamo Assembly

    L100EEDEVMK2 — STARTING MOTOR AND DYNAMO ASSY. PAGE 90 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 91 L100EEDEVMK2 — STARTING MOTOR AND DYNAMO ASSY. PART NO PART NAME QTY. REMARKS 11436277011 STARTER, S114-651A ......1 ....INCLUDES ITEMS W/ 11438177110 ARMATURE X2114811000 WASHER KIT, THRUST X2114715500 STOPPER SET, PINION 11438177130 COIL ASSY., FIELD 11438177140 COVER, REAR 11437177160 HOLDER ASSY., BRUSH ......

  • Page 92: Tool Label And Gasket Set Assembly

    L100EEDEVMK2 — TOOL LABEL AND GASKET SET PAGE 92 — MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18)
  • Page 93 L100EEDEVMK2 — TOOL LABEL AND GASKET SET PART NO PART NAME QTY. REMARKS 11425007090 LABEL, AIR COOLED 11425007111 LABEL, YANMAR 11426807240 LABEL, CAUTION 11426107350 LABEL 71465192620 GASKET SET ......... 1....INCLUDES ITEMS W/ 11465101330 GASKET, CYLINDER HEAD CMP. 11465001380 O-RING 11465001412 GASKET, CRANKCASE 11429901950...

  • Page 94: Terms And Conditions Of Sale

    TERMS AND CONDITION OF SALE — PARTS PAYMENT TERMS Parts must be in new and resalable Multiquip reserves the right to quote and condition, in the original Multiquip sell direct to Government agencies, and to Terms of payment for parts are net 30 days. package (if any), and with Multiquip part Original Equipment Manufacturer accounts numbers clearly marked.
  • Page 95 NOTES MRH800DS ROLLER — OPERATION AND PARTS MANUAL — REV. #4 (11/07/18) — PAGE 95...
  • Page 96 OPERATION AND PARTS MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Corporate Offi ce MQ Parts Department 18910 Wilmington Ave. Tel. (800) 421-1244 800-427-1244 Fax: 800-672-7877 Carson, CA 90746 Fax (310) 537-3927 310-537-3700 Contact : mq@multiquip.com...
