OPERATION MANUAL
SERIES
MODEL MVB150H
PLATE COMPACTOR
(HONDA GX160UT2SMXE GASOLINE ENGINE)
Revision #1 (06/03/20)
To find the latest revision of this publication or
associated parts manual, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MVB150H and is the answer not in the manual?

Questions and answers

Related Manuals for MQ Multiquip MVB150H

Summary of Contents for MQ Multiquip MVB150H

  • Page 1 OPERATION MANUAL SERIES MODEL MVB150H PLATE COMPACTOR (HONDA GX160UT2SMXE GASOLINE ENGINE) Revision #1 (06/03/20) To find the latest revision of this publication or associated parts manual, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...

  • Page 3: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 4: Table Of Contents

    Startup ............. 17–18 Operation ............... 19 Maintenance ............ 20–24 Troubleshooting (Compactor) ........ 25 Troubleshooting (Engine) ......... 26–27 NOTICE Specifications and part numbers are subject to change without notice. PAGE 4 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 5: Safety Information

    COULD result in DEATH or SERIOUS INJURY. CAUTION Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE INJURY. NOTICE Addresses practices not related to personal injury. MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 5...
  • Page 6  ALWAYS clear the work area of any debris, tools, etc. that would constitute a hazard while the equipment is in operation. PAGE 6 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)
  • Page 7 MV H-3 06 MV H-3 06 the engine start diffi cult. and serious damage to the equipment or engine. MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 7...
  • Page 8  ALWAYS keep battery cables in good working condition. hot engine. Repair or replace all worn cables. PAGE 8 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)
  • Page 9  Contact your country's Department of Public Works or recycling agency in your area and arrange for proper disposal of any electrical components, waste or oil associated with this equipment. MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 9...

  • Page 10: Specifications

    Fuel Type Unleaded Automobile Gasoline Oil Capacity 0.16 gallons (0.6 liters) Oil Type SAE 10W-30 Starting Method Recoil Start Cooling System Forced-air cooling Spark Pug NGK BPR6ES PAGE 10 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 11: Dimensions

    DIMENSIONS Figure 1. Dimensions Table 3. Dimensions REFERENCE IN. (MM) 42.72 (1085) 21.89 (556) 25.28 (642) 32.09 (815) 35.63 (905) MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 11...

  • Page 12: General Information

    (interlocking blocks) from being damaged. function of all the controls and components. The appropriate type of interlocking block for this compactor is one having a surface area for two rolls. PAGE 12 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 13: Components

    4. Rubber Rolls — Four hard rubber rolls used in the flattening of surfaces (interlocking blocks). MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 13...

  • Page 14: Basic Engine

    See the engine is dry. maintenance section in this manual for servicing. PAGE 14 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 15: Inspection

    Table 4. Oil Type Season Temperature Oil Type Summer 25°C or Higher SAE 10W-30 Figure 7. V-Belt Location Spring/Fall 25°C~10°C SAE 10W-30/20 Winter 0°C or Lower SAE 10W-10 MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 15...
  • Page 16 (Figure 9) when depressed with finger at midway between the clutch and vibrator pulleys. CORRECT V-BELT TENSION 10-15 MM CLUTCH WHEN DEPRESSED PULLEY AS SHOWN. V-BELT VIBRATOR PULLEY Figure 9. V-Belt Tension PAGE 16 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 17: Startup

    2. Move the throttle lever (Figure 12) to the idle position. Figure 14. Engine ON/OFF Switch (ON Position) THROTTLE LEVER IDLE Figure 12. Throttle Lever (Idle Position) MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 17...
  • Page 18 DO NOT release the starter rope after pulling. Allow it to rewind as soon as possible. 6. When engine starts, release the starter grip and allow the rope to recoil. PAGE 18 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 19: Operation

    Figure 20. Fuel Valve Lever (OFF) Emergency Shutdown 1. Move the throttle lever quickly to the IDLE position, and place the engine ON/OFF switch in the OFF position. MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 19...

  • Page 20: Maintenance

    Ensure that the maintenance area is well ventilated. Gasoline engine exhaust contains poisonous carbon monoxide gas that can cause unconsciousness and may result in DEATH. PAGE 20 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)
  • Page 21 2. These items should be serviced by your service dealer, unless you have the proper tools and are mechanically proficient. Refer to the HONDA Shop Manual for service procedures. 3. For commercial use, log hours of operation to determine proper maintenance intervals. MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 21...
  • Page 22 Bolt threads used with this machine are all right handed Material and quality of material is marked on each bolt, and screw. Figure 21. Engine Air Filter PAGE 22 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)
  • Page 23 OIL SOAKED DRAIN BOLT SEALING WASHER CORD FAILURE GLAZED WORN BACK COVER Figure 22. Draining Engine Oil BROKEN MISSING RUBBER CRACKS SIDEWALL WEAR Figure 24. V-Belt Inspection MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 23...
  • Page 24 5. If the spark arrester is damaged and has breaks or holes, replace with a new one. 6. Reinstall the spark arrester and muffler protector in reverse order of disassembly. PAGE 24 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)

  • Page 25: Troubleshooting (Compactor)

    Push-Pull of compactor is diffi cult Strings or other obstructions coiled (heavy). Remove obstructions and clean. around rotary parts? Seal of both ends come in contact Adjust. with frames? MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 25...

  • Page 26: Troubleshooting (Engine)

    Fuel fi lter/lines clogged? Replace fuel fi lter. Fuel tank cap breather hole clogged? Clean or replace fuel tank cap. Air in fuel line? Bleed fuel line. PAGE 26 — MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20)
  • Page 27 Check cable connections. Charge or replace Will not start, no power with key ON. Battery disconnected or discharged? (if applicable) battery. Ignition switch/wiring defective? Replace ignition switch. Check wiring. MVB150H PLATE COMPACTOR • OPERATION MANUAL — REV. #1 (06/03/20) — PAGE 27...
  • Page 28 TO PURCHASE THIS PRODUCT PLEASE CONTACT US Equipment Financing and Extended Warranties Available Discount-Equipment.com is your online resource for commercial and industrial quality parts and equipment sales. 561-964-4949 visit us on line @ www.discount-equipment.com Select an option below to find your Equipment We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,...
  • Page 29 OPERATION MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND © COPYRIGHT 2020, MULTIQUIP INC. Multiquip Inc , the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
