OPERATION AND PARTS MANUAL
SERIES
MODEL MVC-88GE/GEW
ONE-WAY PLATE COMPACTOR
(ROBIN GASOLINE ENGINE)
Revision #1 (1/10/11)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mikasa MVC-88GE and is the answer not in the manual?

Questions and answers

Related Manuals for MQ Multiquip Mikasa MVC-88GE

Summary of Contents for MQ Multiquip Mikasa MVC-88GE

  • Page 1 OPERATION AND PARTS MANUAL SERIES MODEL MVC-88GE/GEW ONE-WAY PLATE COMPACTOR (ROBIN GASOLINE ENGINE) Revision #1 (1/10/11) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 PAGE 2 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 3 NOTE PAGE MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11) — PAGE 3...

  • Page 4: Table Of Contents

    TABLE OF CONTENTS ROBIN EX170D40050 Multiquip —MVC-88GE/GEW Engine Plate Compactor Table Of Contents .............4 Air Cleaner Assembly ..........38-39 Parts Ordering Procedures ..........5 Camshaft Assembly ..........40-41 Safety Information ............6--10 Carburetor Assembly ..........42-43 Specifications (Compactor/Engine) ........ 12 Crankcase Assembly ..........44-45 General Information ............

  • Page 5: Parts Ordering Procedures

    PARTS ORDERING PROCEDURES Ordering parts has never been easier! Choose from three easy options: Effective: January 1 , 2006 Order via Internet (Dealers Only) Best Deal! If you have an MQ Account, to obtain a Username Order parts on-line using Multiquip’s SmartEquip website! and Password, E-mail us at: parts@multiquip.

  • Page 6: Safety Information

    MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
  • Page 7 MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION GENERAL SAFETY NOTICE CAUTION This equipment should only be operated by trained and qualified personnel 18 years of age and older. NEVER operate this equipment without proper protective clothing, shatterproof glasses, respiratory protection, Whenever necessary, replace nameplate, operation and hearing protection, steel-toed boots and other protective safety decals when they become difficult read.
  • Page 8 MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION COMPACTOR SAFETY WARNING DANGER DO NOT place hands or fingers inside engine compartment when engine is running. NEVER operate the equipment in an explosive atmosphere or near combustible materials. An NEVER operate the engine with heat shields or explosion or fire could result causing severe guards removed.
  • Page 9 MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION FUEL SAFETY BATTERY SAFETY (ELECTRIC START ONLY) DANGER DANGER DO NOT add fuel to equipment if it is placed inside truck DO NOT drop the battery. There is a possibility that the bed with plastic liner. Possibility exists of explosion or battery will explode.
  • Page 10 MVC-88GE/GEW PLATE COMPACTOR — SAFETY INFORMATION TRANSPORTING SAFETY CAUTION NEVER allow any person or animal to stand underneath the equipment while lifting. NOTICE Before lifting, make sure that the equipment parts (hook and vibration insulator) are not damaged and screws are not loose or missing.
  • Page 11 NOTES MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11) — PAGE 11...

  • Page 12: Specifications (Compactor/Engine)

    MVC-88GE/GEW PLATE COMPACTOR — SPECIFICATIONS c i f i t a ) r o s l e r t n u f i . s b o i t b i v o i t a r T l e v g n i .

  • Page 13: General Information

    MVC-88GE/GEW PLATE COMPACTOR — GENERAL INFORMATION Definition of Plate Compactor Frequency/Speed The Mikasa MVC-88GE/GEW is a walk behind, plate compactor The compactor's vibrating plate has a frequency range between designed for the compaction of sand, mixed soils and asphalt. 5800 vpm (vibrations per minute). The forward and reverse travel...
  • Page 14 MVC-88GE/GEW PLATE COMPACTOR — COMPONENTS (COMPACTOR) Figure 1. Plate Compactor Controls Figures 1 shows the location of the basic controls and Belt Cover – Remove this cover to gain access to the V- components of the MVC-88GE/GEW Plate Compactor. The belt.
  • Page 15 MVC-88GE/GEW PLATE COMPACTOR — COMPONENTS (ROBIN ENGINE) Figure 2. Engine Controls and Components INITIAL SERVICING Throttle Lever – Used to adjust engine RPM speed (lever The engine (Figure 2) must be checked for proper lubrication and advanced forward SLOW , lever back toward operator filled with fuel prior to operation.
  • Page 16 MVC-88GE/GEW PLATE COMPACTOR — INSPECTION 3. Insert and remove the dipstick without screwing it into the filler CAUTION CAUTION CAUTION CAUTION CAUTION neck. Check the oil level shown on the dipstick. NEVER operate the compactor in a confined 4. If the oil level is low (Figure 4), fill to the edge of the oil filler area or enclosed area structure that does hole with the recommended oil type (Table 3).
  • Page 17 MVC-88GE/GEW PLATE COMPACTOR — INSPECTION 2. The V-belt tension is proper if the V-belt bends 10 to 15 mm V-Belt Check (Figure 7) when depressed with finger at midway between the clutch and vibration pulley shafts. CAUTI CAUTI CAUTI CAUTI CAUTION NEVER attempt to check the V-belt with the engine running.
  • Page 18 MVC-88GE/GEW PLATE COMPACTOR — OPERATION 3. Place the choke lever (Figure 11) in the " CLOSED " position CAUTION - Read Instructions if starting a cold engine. DO NOT attempt to operate the equipment until the Safety, General Information and Inspection sections of this manual have been read and thoroughly understood .
  • Page 19 MVC-88GE/GEW PLATE COMPACTOR — OPERATION 6. Grasp the starter grip (Figure 14) and slowly pull it out. The Stopping The Engine resistance becomes the hardest at a certain position, corre- Normal Shutdown sponding to the compression point. Pull the starter grip briskly 1.

  • Page 20: Inspection

    MVC-88GE/GEW PLATE COMPACTOR — MAINTENANCE CAUTI CAUTI CAUTI CAUTI CAUTION CAUTI CAUTI CAUTION CAUTI CAUTI These inspection intervals are for operation under normal Inspection and other services should always be carried out conditions. Adjust your inspection intervals based on the on hard and level ground with the engine shutdown.
  • Page 21 MVC-88GE/GEW PLATE COMPACTOR — MAINTENANCE ENGINE OIL 1. Drain the engine oil when the oil is warm as shown in e t I i t a Figure 20. 2. Remove the oil drain bolt and sealing washer and allow i t r the oil to drain into a suitable container.
  • Page 22 MVC-88GE/GEW— MAINTENANCE ■ CHANGING VIBRATOR OIL Replacing the V-belt 1. When changing the vibrator oil, remove the drain plug Remove the upper and lower belt covers. Engage an offset located at the bottom-right of the vibrator (Figure 8), and wrench (13 mm) or the like to vibrator pulley (lower) fastening simply tip the compactor to drain the oil.

  • Page 23: Preparation For Long Term Storage

    MVC-88GE/GEW— PREPARATION FOR LONG -TERM STORAGE Plate Compactor Storage For storage of the plate compactor for over 30 days, the following is required: ■ Drain the fuel tank completely or add STA-BIL to the fuel. ■ Run the engine until the fuel is completely consumed. ■...

  • Page 24: Troubleshooting (Engine)

    MVC-88GE/GEW—TROUBLESHOOTING (ENGINE) Practically all breakdowns can be prevented by proper If the problem cannot be remedied, please leave the unit handling and maintenance inspections, but in the event of a just as it is and consult or company's service department. breakdown, please take remedial action following the diagnosis based on the Engine , and Compactor Troubleshooting (Tables 7, and 8) information shown below...
  • Page 25 MVC-88GE/GEW—TROUBLESHOOTING (ENGINE COMPACTOR) r i A r i a e l c o l f s u j , t n - e r d l i l e v " " r e i s s . r o i f s i .
  • Page 26 MVC-88GE/GEW — EXPLANATION OF CODE IN REMARKS COLUMN The following section explains the different symbols and QTY. Column remarks used in the Parts section of this manual. Use the Numbers Used — Item quantity can be indicated by a help numbers found on the back page of the manual if there number, a blank entry, or A/R.
  • Page 27 MVC-88GE/GEW — SUGGESTED SPARE PARTS MVC-88GE/GEW 1 TO 5 UNITS WITH ROBIN EX170D40050 ENGINE 1 to 5 Units Qty. Description 3 ..070100332 ..V-BELT 5 ..0650140150 ..SPARK PLUG 1 ..2825011118 ..ROPE, RECOIL STARTER 5 ..2773261107 ..ELEMENT, CLEANER 1 ..

  • Page 28: Nameplate And Decals

    MVC-88GE/GEW— NAME PLATE AND DECALS NAME PLATE AND DECALS CAUTION READ 0WNER’S MANUAL NPA 629 NAMEPLATE NPA-845 J SAE 10W-30 MOTOR OIL NPA-195 J CAUTION Fill up the sumps with oil before starting. Engine : Automobile engine oil 10~30 Vibrator: Automobile engine oil 10~30 Warm up the engine at idle speed V BELT RPF-3330...
  • Page 29 MVC-88GE/GEW— NAME PLATE AND DECALS NAME PLATE AND DECALS PART NO PART NAME QTY. REMARKS 920206290 DECAL, READ OWNERS MANUAL ..1 ..NPA-629 920203290 DECAL, CAUTION ......... 1 ..NPA-329 920208450 DECAL, LIFTING ........1 ..NPA-845 920203060 DECAL, CAUTION (START ENG/VIBR) . 1 ..NPA-306 920208350 DECAL, V- BELT RPF-3330 ....
  • Page 30 MVC-88GE/GEW— BODY ASSY. VIBRATING PLATE ASSY. PAGE 30 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 31 MVC-88GE/GEW— BODY ASSY. BODY ASSY. PART NO PART NAME QTY. REMARKS 416115971 VIBRATING PLATE 939010140 SHOCK ABSORBER 50D-45H 020310080 NUT M10 030210250 WASHER SW M10 416115980 BASE 001221025 BOLT 10X25 T 030210250 WASHER, LOCK M10 911221701 ENGINE ASSY. EX170D40050 001220845 BOLT 8X45 T 030208200 WASHER, LOCK M8...
  • Page 32 MVC-88GE/GEW— VIBRATOR ASSY. VIBRATOR ASSY. PAGE 32 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 33 MVC-88GE/GEW— VIBRATOR ASSY. VIBRATOR ASSY. PART NO PART NAME QTY. REMARKS 416910030 VIBRATOR ASSY ........1 ... INCLUDES ITEMS W/ # 416115990 VIBRATING CASE 953400270 PLUG 1/4X14 10L 953405260 PACKING 1/4 001221635 BOLT 16X35 T 030216400 WASHER, LOCK M16 031116260 WASHER, FLAT M16 416338890 ECCENTRIC ROTATOR...
  • Page 34 MVC-88GE/GEW— SPRINKLER ASSY. (OPTION) SPRINKLER ASSY. (OPTION) PAGE 34 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 35 MVC-88GE/GEW— SPRINKLER ASSY. (OPTION) SPRINKLER ASSY. (OPTION) PART NO PART NAME QTY. REMARKS 4169100109 WATER TANK ASSY..... 1 ....INCLUDES ITEMS W/ 111A 416910010 WATER TANK (W/CAP ONLY) ..1 ....REPLACES 416116010 INCLUDES ITEMS W/# 033910050 WASHER 14.5X30X1.6 953406390 PACKING 13X28X2 954403241...
  • Page 36 MVC-88GE/GEW— TRANSPORT WHEEL ASSY. (OPTION) TRANSPORT WHEEL ASSY. (OPTION ) PAGE 36 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 37 MVC-88GE/GEW— TRANSPORT WHEEL ASSY. (OPTION) TRANSPORT WHEEL ASSY. (OPTION ) PART NO PART NAME QTY. REMARKS 416116160 WHEEL SHAFT 959404310 WHEEL 150X42 031120320 WASHER, FLAT M20 025203030 SPLIT COTTER PIN 3X30 416454150 ROLLER 025403025 SPRING PIN 3X25 MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11) — PAGE 37...
  • Page 38 EX-170D40050 — AIR CLEANER ASSY. AIR CLEANER ASSY. PAGE 38 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 39 EX-170D40050 — AIR CLEANER ASSY. AIR CLEANER ASSY. PART NO PART NAME QTY. REMARKS 2773261500 AIR CLEANER ASSY........ 1 ....INCLUDES ITEMS W/ 2773263008 BASE, CLEANER 2773261008 PACKING, CLEANER 2773260408 GASKET, CLEANER 2773264008 COVER, CLEANER 2773260908 LABEL, THROTTLE 2773274108 WING, NUT 2773274008 WING, NUT...
  • Page 40 EX-170D40050 — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 40 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 41 EX-170D40050 — CAMSHAFT ASSY. CAMSHAFT ASSY. PART NO PART NAME QTY. REMARKS 2773160101 CAMSHAFT ..........1 ....INCLUDES ITEMS W/ 2773510103 PIN, CAMSHAFT 0240060010 O-RING 2773860103 PIN, SPRING 2773640103 RELEASE LEVER 2773650103 CLIP 2773870103 RETURN SPRING 2773560101 CHAIN, TIMING 2773691103 TENSIONER 2773710103 SPRING, TENSIONER...
  • Page 42 EX-170D40050 — CARBURETOR ASSY. CARBURETOR ASSY. PAGE 42 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 43 EX-170D40050 — CARBURETOR ASSY. CARBURETOR ASSY. PART NO PART NAME QTY. REMARKS 2776230210 CARBURETOR ASSY........1..INCLUDES ITEMS W/ 210-1 2776253508 THROTTLE VALVE 210-2 2096235108 SCREW 210-3 2776252508 CHOKE VALVE 210-5 2466242008 PILOT JET 210-8 2776252008 CHOKE LEVER 210-11 2776253108 THROTTLE SHAFT 210-12...
  • Page 44 EX-170D40050 — CRANKCASE ASSY. CRANKCASE ASSY. PAGE 44 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 45 EX-170D40050 — CRANKCASE ASSY. CRANKCASE ASSY. PART NO PART NAME QTY. REMARKS 2771010141 CRANKCASE CP, W/OIL SENSOR ..... 1 ..INCLUDES ITEMS W/ 0440250200 OIL SEAL 0600280021 BALL BEARING 2771501103 PIPE KNOCK 0440060020 OIL SEAL 0401140030 PLUG 0211140020 GASKET 2771100131 MAIN BEARING COVER CP .......
  • Page 46 EX-170D40050 — CRANKSHAFT/PISTON ASSY. CRANKSHAFT/PISTON ASSY. PAGE 46 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 47 EX-170D40050 — CRANKSHAFT/PISTON ASSY. CRANKSHAFT/PISTON ASSY. PART NO PART NAME QTY. REMARKS 2772020111 CRANKSHAFT 0180140020 FLANGE NUT 0323030010 WOODRUFF KEY 0053005301 0200080050 WASHER 0011308200 BOLT & WASHER ASSY. 2772250110 CONNECTING ROD ASSY....... 1 ....INCLUDES ITEMS W/ 2772300103 CONNECTING ROD BOLT 2772330103 PISTON PIN 2772340103...
  • Page 48 EX-170D40050 — CYLINDER HEAD ASSY. CYLINDER ASSY. PAGE 48 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)

  • Page 49: Cylinder Head Assembly

    EX-170D40050 — CYLINDER HEAD ASSY. CYLINDER ASSY. PART NO PART NAME QTY. REMARKS 2371420203 VALVE GUIDE 2771601001 STEM SEAL 2793360103 VALVE, SPRING 2693370103 SPRING RETAINER 0105080250 STUD 0105060351 STUD 2773340113 INTAKE VALVE 2773350113 EXHAUST VALVE 13210KA031 COLLET VALVE 2773500123 PIN, ROCKER 2773610100 ROCKER, ARM ASSY.
  • Page 50 EX-170D40050 — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 50 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)

  • Page 51: Fuel Tank Assembly

    EX-170D40050 — FUEL TANK ASSY. FUEL TANK ASSY. PART NO PART NAME QTY. REMARKS 2776010201 FUEL TANK 0732005180 LABEL, WARNING 2779510103 LABEL, MODEL 0430440050 FUEL TANK, CAP 0641360010 FUEL FILTER 0505120020 UNION 0023806000 FLANGE, NUT 0110060130 FLANGE, BOLT 0851960000 RUBBER PIPE, 6DX11D 0561100030 HOSE CLAMP, 10DX8BX1T MVC-88GE/GEW PLATE COMPACTOR —...
  • Page 52 EX-170D40050 — GOVERNOR ASSY. GOVERNOR ASSY. PAGE 52 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 53 EX-170D40050 — GOVERNOR ASSY. GOVERNOR ASSY. PART NO PART NAME QTY. REMARKS 2774230113 GOVERNOR, LEVER 2774220133 GOVERNOR, SHAFT 2774270101 GOVERNOR, ROD 2774280113 ROD, SPRING 0031305000 CLIP 0130060240 BOLT & WASHER ASSY 0186060020 2794250223 GOVERNOR, SPRING 2774330113 SPEED CONTROL, LEVER 2774350103 STOP, PLATE 0200060170 WASHER...
  • Page 54 EX-170D40050 — IGNITION COIL/FLYWHEEL ASSY. ELECTRIC DEVICE ASSY. PAGE 54 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 55 EX-170D40050 — IGNITION COIL/FLYWHEEL ASSY. ELECTRIC DEVICE ASSY. PART NO PART NAME QTY. REMARKS 2777923001 FLYWHEEL 2777943011 IGNITION COIL 0011406250 BOLT & WASHER 2777310101 WIRE 1 X660000361 STOP SWITCH ASSY., ON-OFF 0150040090 TAPPING SCREW 0650140150 SPARK PLUG 0655000270 SPARK PLUG CAP MVC-88GE/GEW PLATE COMPACTOR —...
  • Page 56 EX-170D40050 — MUFFLER ASSY. MUFFLER ASSY. PAGE 56 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 57 EX-170D40050 — MUFFLER ASSY. MUFFLER ASSY. PART NO PART NAME QTY. REMARKS 2773010111 MUFFLER 2773420111 MUFFLER COVER 2773520103 GASKET, MUFFLER 9802008280 FLANGE, NUT 0152060090 TAPPING BOLT 0110060010 FLANGE BOLT 0110080150 FLANGE BOLT 2773700101 DEFLECTOR 0150040060 TAPPING SCREW MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11) — PAGE 57...
  • Page 58 EX-170D40050 — RECOIL STARTER ASSY. COOLING AND STARTING ASSY. PAGE 58 — MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11)
  • Page 59 EX-170D40050 — RECOIL STARTER ASSY. COOLING AND STARTING ASSY. COOLING AND STARTING ASSY. PART NO PART NAME QTY. REMARKS 2775120201 BLOWER, HOUSING CP 0732005140 LABEL, TRADEMARK 0110060030 FLANGE, BOLT 2775271111 BAFFLE, CASE 1 2775270203 BAFFLE, HEAD 2 0010406160 FLANGE, BOLT 0110060020 FLANGE, BOLT 2695020130...

  • Page 60: Terms And Conditions Of Sale - Parts

    TERMS AND CONDITIONS OF SALE — PARTS PAYMENT TERMS Parts must be in new and resalable Multiquip reserves the right to quote and condition, in the original Multiquip sell direct to Government agencies, and to Terms of payment for parts are net 30 days. package (if any), and with Multiquip part Original Equipment Manufacturer accounts numbers clearly marked.
  • Page 61 NOTE PAGE MVC-88GE/GEW PLATE COMPACTOR — OPERATION AND PARTS MANUAL — REV. #1 (01/10/11) — PAGE 61...
  • Page 62 OPERATION & PARTS MANUAL HERE’S HOW TO GET HELP PLEASE HAVE THE MODEL AND SERIAL NUMBER ON-HAND WHEN CALLING UNITED STATES Multiquip Corporate Offi ce MQ Parts Department 18910 Wilmington Ave. Tel. (800) 421-1244 800-427-1244 Fax: 800-672-7877 Carson, CA 90746 Fax (800) 537-3927 310-537-3700 Fax: 310-637-3284...
