Bosch PROFACTOR GCM18V-10SDN14 Operating/Safety Instructions Manual page 22

NOTE: Clean the bag at the end of the cutting session and be-
fore transporting or storing the saw.
Attaching a Vacuum Cleaner/Dust Extractor
The saw's dust port (Fig. 15, 43) will accept the typical noz-
zles from 35 mm (13/8") vacuum cleaner hoses, and Bosch
VH–Series hoses.
Fig. 15
1 / ˝ (35mm)
3
8
hose
Bosch VH-series
hose
1 / ˝ (32mm)
1
4
hose
1 / ˝ (38mm)
1
2
hose
To connect the saw with a 1¼" (32 mm) or 1½" (38mm) hose,
the Bosch VAC024 adapter can be used (sold separately).
NOTE: the sizes above indicate the hose diameters and not
the nozzle diameters.
Attaching to Vacuum – Insert the vacuum nozzle into (or
onto) the dust port (Fig. 15, 43) as far as it will go. Check to
see that the vacuum hose is free from the mechanism and cut-
ting path before reconnecting battery pack.
Assembly
VAC024
43
-22-
