1.3
Packing List
Your ET980 package should include the items listed below. If any of the
items below is missing, contact the distributor or dealer from whom you
purchased the product.
ET980 COM Express Module
•
Disk (including drivers and flash memory utility)
•
This User's Manual
•
1.4
Specifications
ET980LV-I7U - Intel® Core™ i7-1265UE with LVDS support
ET980LV-I7P - Intel® Core™ i7-1270PE with LVDS support
ET980LV-I5U - Intel® Core™ i5-1245UE with LVDS support
ET980-I5U - Intel® Core™ i5-1245UE with eDP support
ET980LV-I5P - Intel® Core™ i5-1250PE with LVDS support
ET980LV-I3P - Intel® Core™ i3-1220PE with LVDS support
Operating
System
Memory
Graphics
Video Output
Ethernet
Super I/O
USB 2.0
USB 3.X
Serial ATA
Audio
Expansion Slot
ET980 Series User's Manual
Product Models
System
Windows 10 (64-bit)
2x DDR4-3200 SO-DIMM sockets, Max. 64GB, ECC compatible
12th Gen Intel® Core™ P-series processor integrated graphics
HDMI, DisplayPort, VGA, LVDS or eDP on carrier board
Intel® I226LM 2.5 GbE RJ45 on carrier board
Fintek F81804U-I
8x USB 2.0 via carrier board
4x USB 3.1 (Gen 2) via carrier board
2x SATA III via carrier board
Built-in HD Audio controller
1x PCI-E(x8) [(Gen. 4) (PCIe(4x)+ PCIe(4x)], 1xPCI-E(x4)
(Gen. 3), 4x PCI-E(x1) (Gen. 2) to carrier board
1
General Information
x 1
x 1
x 1
