Installation Instructions

GB
Please Note:
This product should only be installed by a qualifi ed electrician
or competent heating installer and should be in accordance
with the current edition of the IEEE wiring regulations.
Product Specifi cation
Thermostat features
Power supply
Memory back-up
Temperature Range Sensing
Factory set calendar clock
Switching action of
output relay
Remote sensor inputs
(A models only)
Dimensions (mm)
Design standard
Rated impulse voltage
Ball hardness test
Control pollution situation
Temperature accuracy
Time accuracy
2
TP5001M
230V, ±10%, 50Hz
Retained for life of product
Automatic summer/winter time change
3(1)A, 10-230V
Can be set by installer for remote temperature
sensor, limit sensor, window contact or telephone
activated switch contacts
110 wide, 88 high, 28 deep
EN60730-2-9
±1 min. per month
TP5001M 24
24V, ±10%, 50Hz
5-30°C
Type 1B
2.5kV
75°C
Degree 2
±1°C
