- Page 1 A GYM OF YOUR OWN Wall-Mounted Frame PWM01 OWNER’ S MANUAL & ASSEMBLY INSTRUCTIONS...
- Page 2 Additional features on products may be added during seasonal production but may not be featured in line art diagrams at time of production. Changes of such will not affect the performance or assembly of the unit. If you would like further clarification during your assembly process please feel free to contact RITFIT for direction.
- Page 3 A. What’s Covered Under RitFit LLC’s Basic Warranty? Basic Warranty. B. Who Is Covered? You are covered by the Basic Warranty if you are a purchaser for use of the RitFit Wall- Mounted Frame. C. What’s Covered? The Basic Warranty covers the cost of all parts and labor needed to repair any item on your Wall-Mounted Frame when it left the manufacturing plant that is defective in material, workmanship or factory preparation.
- Page 4 Customer Service Department at support@rit- fitsports.com. To help us assist you, please note the product model number and serial number before calling. The model number is PWM01. BEFORE READING FURTHER, PLEASE REVIEW THE DRAWING BELOW AND FAMILIARIZE YOURSELF WITH THE PARTS THAT ARE LABELED.
- Page 5 PARTS LIST ·FASTENER AND TOOLS QUANTITY DESCRIPTION M10*100 Expansion Bolt Set Nut Cap ·PACKED IN THE BOX QUANTITY DESCRIPTION Main Frame How to Measure 70mm or 2.75" 10 mm 10mm or 0.40" M10 nut M10 x 70 bolt May not be printed on a 1:1 Ratio ASSEMBLY AND ADJUSTMENT Solid wall 6.7 in...
- Page 6 Please follow the steps: Firstly, check the type of the wall to install the Wall-Mounted Frame PWM01. Punch six holes with diameter of 0.055 in (14 mm) and depth of 4 in (100 mm) at the marked position on the wall.
- Page 7 Congratulations! You have assembled the Wall Mounted Frame! Now, you can officially add Wall-Mounted Frame Attachments and start strength training with RITFIT.
- Page 8 A GYM OF YOUR OWN www.ritfitsports.com support@ritfitsports.com...
