- Page 1 INSTRUCTIONS COLPOSCOPE OCS-500 USA: CAUTION: Federal law restricts this device to sale by or on the order of a physician.
-
Page 3: Table Of Contents
Moving and securing the colposcope..........Arm balance adjustment ..............Adjusting the rotation tension of rotating parts........ Turning ON the light source ............Interpupillary adjustment..............Diopter adjustment................Eyepiece shade height adjustment ..........Focusing ..................Zooming ..................4.10 Inserting and removing the filter............COLPOSCOPE OCS-500... - Page 4 Contents Chapter 5 Care and Storage ............. Care ....................Storage ................... Disposal ..................Chapter 6 Troubleshooting ............Troubleshooting guide ..............Returning the colposcope for repair ..........Appendix..................System chart .................... Operating environment ................Specifications ................... COLPOSCOPE OCS-500...
-
Page 5: Labels And Symbols
UDI label ( A label required by some countries’ regulations regarding identification of medical device also known as Unique Device Identification (UDI). For US Customers only For a Symbols Glossary, visit us: http://www.olympus-global.com/en/common/pdf/symbolsglossary.pdf COLPOSCOPE OCS-500... -
Page 6: Important Information - Please Read Before Use
Important Information — Please Read Before Use Intended use This instrument has been designed to be used with Olympus light source and documentation equipment to view the cervix, uterus, vagina, and external genitals, and to record the images. Do not use this instrument for any purpose other than its intended use. -
Page 7: User Qualifications
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. It may also be used to alert against unsafe practices or potential equipment damage. Indicates additional helpful information. COLPOSCOPE OCS-500... -
Page 8: Warnings And Cautions
• Do not hit or strike the objective. Otherwise, the objective may be damaged. • Avoid applying excessive force to the light guide, as this may damage it. COLPOSCOPE OCS-500... -
Page 9: Chapter 1 Checking The Package Contents
Match all items in the package with the components shown below. Inspect each item for damage. If the instrument is damaged, a component is missing or you have any questions, do not use the instrument; immediately contact Olympus. Balance arm Zoom microscope body... -
Page 10: Chapter 2 Instrument Nomenclature
Rotating the handle adjusts up-down movement tension of the balance arm. Stand (OCS5-STD) Balance adjustment handle Rotating the handle adjusts the balance of the balance arm. Horizontal arm Caster (OCS5-HA) Caster stopper Floorstand base Small tray (OCS5-STB) (OCS5-TYS) COLPOSCOPE OCS-500... -
Page 11: Microscope Body
Use only when the camera adapter Rotating the lever adjusts the zoom is mounted. microscope body tilt tension. Focusing knob Rotating the knob focuses the colposcope. Filter Insert and remove Zoom magnification the green filter knob into/from here. Filter button COLPOSCOPE OCS-500... -
Page 12: Chapter 3 Installation And Connection
Should the slightest irregularity be suspected, do not use this instrument and see Chapter 6, “Troubleshooting”. If the irregularity is still suspected after consulting Chapter 6, contact Olympus. Damage or irregularity may compromise patient or user safety and may result in more severe equipment damage. -
Page 13: Inspecting The Joints Of The Horizontal Arm, Balance Arm And Zoom Microscope Body
If you find that any of the connections are not completely secure, stop operation immediately and contact Olympus. Confirm that the horizontal arm, the balance arm and the microscope body are securely connected to the stand (see Figure 3.2). -
Page 14: Inspecting The Arm Movement And Balance
If the left and right images are focused differently, adjust the diopter of the eyepieces as described in Section 4.6, “Diopter adjustment”. • If the images are out of focus when the magnification is changed, adjust the diopter of the eyepieces as described in Section 4.6, “Diopter adjustment”. COLPOSCOPE OCS-500... -
Page 15: Inspecting The Focus And Zoom Functions
Confirm that the focus and zoom adjustment functions are working properly. Rotate the focusing knob and the zoom magnification knob (see Figure 3.3) and look through the eyepiece to confirm that both functions are active. Focusing knob Zoom magnification knob Figure 3.3 COLPOSCOPE OCS-500... -
Page 16: Chapter 4 Operation
• Do not hit or strike the objective lens to avoid damaging it. Moving and securing the colposcope Push up the caster stoppers on the floorstand base to release them (see Figure 4.1). Caster stopper Figure 4.1 COLPOSCOPE OCS-500... - Page 17 Hold the projecting part the stand and push it forward to move the floorstand base (see Figure 4.3). Projecting part Figure 4.3 Take care that your fingers do not get caught in the floorstand base as they could be injured if caught. COLPOSCOPE OCS-500...
- Page 18 (see Figure 4.4). Figure 4.4 Push down the two caster stoppers on the floorstand base to fix its position (see Figure 4.5). Caster stopper Figure 4.5 COLPOSCOPE OCS-500...
-
Page 19: Arm Balance Adjustment
Loosen the vertical movement tension adjustment handle so that the microscope body can move up and down freely (see Figure 4.6). Grip Figure 4.6 Hold the grip to move the microscope up and down, and confirm that it remains stationary at any desired point. COLPOSCOPE OCS-500... -
Page 20: Adjusting The Rotation Tension Of Rotating Parts
When you move the microscope body, be careful not to get your hand or fingers caught between the moving portions of the arm. If you loosen the rotation tension adjustment handle too much, it may fall off. Be careful not to let the handle fall off. COLPOSCOPE OCS-500... - Page 21 (see Figure 4.8). Tilt tension adjustment lever Figure 4.8 When the tilt tension has been adjusted, rotate the tilt tension adjustment lever as you pull it out and point it away from other operations (see Figure 4.9). Figure 4.9 COLPOSCOPE OCS-500...
- Page 22 Rotate the vertical movement tension adjustment handle to adjust the tension of the vertical movement of the balance arm so that it moves when a slight force is applied, and is easy to handle (see Figure 4.11). Vertical movement tension adjustment handle Figure 4.11 COLPOSCOPE OCS-500...
-
Page 23: Turning On The Light Source
While looking through the eyepieces, hold the binocular portions and rotate them clockwise and counterclockwise so that the fields of view on both sides overlap with each other (see Figure 4.12). Binocular portions Figure 4.12 COLPOSCOPE OCS-500... -
Page 24: Diopter Adjustment
Minimize the magnification, and confirm that the observation area is still in focus. If it is out of focus, repeat Steps 1. through 4. COLPOSCOPE OCS-500... -
Page 25: Eyepiece Shade Height Adjustment
For surgeons wearing eyeglasses, it is recommended that the eyepiece shade be folded down for ease of observation (see Figure 4.14). Eyepiece shade Figure 4.14 Focusing Rotate the focusing knob to adjust the focus of the observed area (see Figure 4.15). Focusing knob Figure 4.15 COLPOSCOPE OCS-500... -
Page 26: Zooming
As shown in the table below, the actual value of the magnification corresponds to the value shown on the scale on the zoom magnification knob and the focusing knob. Scale on the zoom magnification knob Scale on the 11.3 15.0 18.8 23.7 focusing 12.0 15.1 18.8 knob 10.7 13.4 16.9 COLPOSCOPE OCS-500... -
Page 27: 4.10 Inserting And Removing The Filter
When the button on the right is pushed in as far as it will go, the filter can be removed (see Figure 4.17). Green filter is removed. Green filter is inserted. Filter button Figure 4.17 COLPOSCOPE OCS-500... -
Page 28: Chapter 5 Care And Storage
If the OCS-500 becomes soiled, perform the following cleaning procedures immediately after use. If cleaning is delayed, organic debris will solidify and it may be difficult to effectively clean the OCS-500. The instrument should also be cleaned routinely. Wipe the equipment using a soft, lint-free cloth moistened with 70% ethyl or isopropyl alcohol to remove dust, dirt, etc. -
Page 29: Storage
Fold the horizontal arm and the balance arm and clamp the rotation tension adjustment handle securely (see Figure 5.1). Rotation tension adjustment handle Figure 5.1 Place the cords onto the projecting part of the stand (see Figure 5.2). Projecting part Figure 5.2 COLPOSCOPE OCS-500... -
Page 30: Disposal
Push down the two caster stoppers on the floorstand base to fix its position (see Figure 5.3). Caster stopper Figure 5.3 Place the dust cover on the microscope body. Disposal When disposing of this equipment, follow all applicable national and local laws and guideline. COLPOSCOPE OCS-500... -
Page 31: Chapter 6 Troubleshooting
If the equipment is visibly damaged, does not function as expected or is found to have other irregularities during the inspection described in Chapter 3, “Installation and Connection”, do not use the equipment; contact Olympus. Some problems that appear to be malfunctions may be correctable by referring to Section 6.1, “Troubleshooting guide”. -
Page 32: Returning The Colposcope For Repair
Returning the colposcope for repair Olympus is not liable for any injury or damage which occurs as a result of repairs attempted by non-Olympus personnel. Before returning the colposcope for repair, contact Olympus. With the... -
Page 33: Appendix
New products released after the introduction of this instrument may also be compatible for use in combination with this instrument. For further details, contact Olympus. If combinations of equipment other than those shown below are used, the full responsibility is assumed by the medical treatment facility. - Page 34 Appendix Video system (OTV-SC) Zoom microscope body (OCS5-ZB) Foot holder (MD-512) Light guide (OCS5-LG) Halogen light source (CLH-SC) Light source Foot holder (CLV-S40) etc. (MD-512) OES video system (OTV-S7) etc. System rack (OCS5-SR) COLPOSCOPE OCS-500...
- Page 35 Optional arm transformer (OCS5-OPA) MB-631 (NTSC) MB-761 (PAL) Horizontal arm (OCS5-HA) Stand Small tray (OCS5-STD) (OCS5-TYS) Floorstand base (OCS5-STB) Colposcope OCS-500 1 The 35 mm camera adapter (OCS5-35AD) and video adapter (AR-T10E or AR-T12E) cannot be used simultaneously. COLPOSCOPE OCS-500...
-
Page 36: Operating Environment
Overall magnifications WD220 3.7 – 23.7 × WD300 3.0 – 18.8 × WD350 2.7 – 16.9 × Field of view WD220 ø 59.1 – 9.4 mm WD300 ø 73.8 – 11.7 mm WD350 ø 81.8 – 13.0 mm COLPOSCOPE OCS-500... - Page 37 300 mm range Arm rotation range 270 Photography/ TV camera Compatible with a TV camera adapter cinematography (optional). equipment 35 mm still camera Compatible with a 35 mm camera adapter (optional). COLPOSCOPE OCS-500...
- Page 39 ©2001 OLYMPUS MEDICAL SYSTEMS CORP. All rights reserved. No part of this publication may be reproduced or distributed without the express written permission of OLYMPUS MEDICAL SYSTEMS CORP. OLYMPUS is a registered trademark of OLYMPUS CORPORATION. Trademarks, product names, logos, or trade names used in this document are generally registered trademarks or trademarks of each company.
- Page 40 Manufactured by 2951 Ishikawa-cho, Hachioji-shi, Tokyo 192-8507, Japan Fax: (042)646-2429 Telephone: (042)642-2111 Distributed by 3500 Corporate Parkway, P.O. Box 610, Center Valley, PA 18034-0610, U.S.A. Fax: (484)896-7128 Telephone: (484)896-5000 5301 Blue Lagoon Drive, Suite 290 Miami, FL 33126-2097, U.S.A. Fax: (305)261-4421 Telephone: (305)266-2332 (Premises/Goods delivery) Wendenstrasse 14-18, 20097 Hamburg, Germany (Letters) Postfach 10 49 08, 20034 Hamburg, Germany Fax: (040)23773-4656 Telephone: (040)23773-0...
