Polycom Vortex EF2280 Applications page 17
Polycom ef2280 audio: reference guide
Hide thumbs
Also See for Vortex EF2280:
- Programming manual (105 pages) ,
- Reference manual (76 pages) ,
- Brochure & specs (2 pages)
Table of Contents
Advertisement
Zone Speaker
Front Program
Audio Speakers
Left Program
Audio
Right Program
Audio
Zone Speaker
Left Program
Audio
Right Program
Audio
© Polycom, Inc.
In 1
Out 1
In 2
Out 2
In 3
Out 3
In 4
Out 4
Line In
In 5
Out 5
In 6
Out 6
In 7
Out 7
In 8
Out 8
®
Vortex
From AEC
In A
Out A
From Rem.
In B
Out B
In C
Out C
In D
Out D
Factory Preset 5:
In 1
Out 1
In 2
Out 2
In 3
Out 3
In 4
Out 4
In 5
Out 5
Out 6
In 6
In 7
Out 7
Submatrix
In 8
Out 8
®
Vortex
In A
Out A
In B
Out B
In C
Out C
In D
Out D
15
Video
CODEC
Line Out
Stereo
Recorder
To AEC
To Rem.
EF200
Phone
8 mics per Zone
Output 1 zone speaker
Outputs 7 & 8 stereo record
Outputs C & D stereo program
audio
Inputs A & B mix minus to
Outputs A & B for codec and
phone add
WM0: Mix of mics at unity gain
WM1: Reinforced mix of other
mics
XM0: Codec and Phone Add
YM0, ZM0: Stereo program
audio
®
Vortex
Applications and Presets Guide
P
RESETS
