Here is a chart showing how to make a cable to connect the modem's DB-25 port
to the Vortex device's DB-9 port:
DB-25 Pin DB-9
Pin
2 2
3 3
4 8
5 7
Remember that the modem and the Vortex device are wired as
DCE; thus, the wiring is exactly like wiring a null-modem
connection.
ABLING
Function
Transmit Data
Receive Data
Request to Send ( RTS Stands for
Request to Send. A way for the
computer or control system to indicate
to the EF Device that it si ready to
accept data. )
Clear to Send ( CTS Stands for Clear to
Send. A way for the EF Device to
indicate to the control system or
computer that it is ready to receive
commands. )
