- Page 1 VeriDri™ Moisture Transmitter User’s Manual 916-095 D panametrics.com Dec 2021...
- Page 3 VeriDri™ Moisture Transmitter User’s Manual 916-095 D Dec 2021 panametrics.com Copyright 2021 Baker Hughes company. This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries in one or more countries. All third-party product and company names are trademarks of their respective...
- Page 4 [no content intended for this page]...
- Page 5 Make sure that operators and maintenance personnel have all safety equipment applicable to the auxiliary equipment. Examples include safety glasses, protective headgear, safety shoes, etc. Unauthorized Operation Make sure that unauthorized personnel cannot gain access to the operation of the equipment. VeriDri™ User’s Manual...
- Page 6 The crossed-out wheeled bin symbol invites you to use those systems. If you need more information on the collection, reuse and recycling systems, please contact your local or regional waste administration. Visit www.bakerhughesds.com/health-safety-and-environment-hse for take-back instructions and more information about this initiative. VeriDri™ User’s Manual...
-
Page 7: Table Of Contents
7.4 Moisture Sensor Specifications ................8 VeriDri™ User’s Manual... - Page 8 Contents [no content intended for this page] VeriDri™ User’s Manual...
-
Page 9: Introduction
0 to 10,000 PPMv. The VeriDri is supplied with one 4 to 20 mA analog output that is factory-configured for a specified range. The VeriDri is easy to install, operate and maintain. This manual includes the following sections: •... -
Page 10: Inserting The Transmitter Into The System
Figure 1: Sample System Example Inserting the Transmitter into the System CAUTION! If you are mounting the VeriDri directly into the process line, you must consult Panametrics for proper installation instructions and precautions before beginning the following procedure. Complete the steps below to install the VeriDri: Make sure the sintered or sheet stainless-steel shield is in place. -
Page 11: Making The Wiring Connections
*The blue and brown leads also produce a current output equivalent to 4 to 20 mA. Trim any unused leads back to the outer cable jacket, to remove the bare tinned wire and prevent accidental short circuits. The VeriDri is now ready for operation. VeriDri™ User’s Manual... -
Page 12: Operating The Transmitter
Operating the Transmitter After proper installation, the VeriDri transmitter is very easy to use. Simply power the unit up and you are ready to begin taking measurements. As the VeriDri stores moisture calibration data in non-volatile FLASH memory, you do not have to enter data manually or worry about losing data during a power loss. -
Page 13: Powering Up
Powering Up After the VeriDri is wired as described in the previous section, you may apply power to the unit. The transmitter takes approximately 20 seconds to initialize and begin normal operation. The unit will meet specified accuracy in about 3 minutes. -
Page 14: Soaking The Sensor And Shield
If the probe is still not reading the ambient air accurately, repeat the cleaning procedure using soaking times that are 5 times the previous cleaning sequence, until two consecutive ambient air readings are within ±2°C (±3.6°F). If the above cleaning procedure does not result in accurate readings, contact Panametrics for assistance. VeriDri™ User’s Manual... -
Page 15: Specifications
10°C (–85 to 50 • ± 1.0°C (1.8°F) from –80 to –66°C (–112 to –87 Electronics Power • Supply Voltage: 7 to 28 VDC (loop-powered, customer supplied) • Output: 4 to 20 mA • Output Resolution: 0.01 mA VeriDri™ User’s Manual... -
Page 16: Mechanical Specifications
Thin-film aluminum oxide moisture sensor probe Calibration Each sensor is individually computer-calibrated against known moisture concentrations, traceable to NIST Calibration Interval Factory sensor recalibration by Panametrics is recommended every 6-12 months, depending on the application Calibration Data Factory-calibrated, stored in FLASH memory Flow Rate •... - Page 17 • If Panametrics determines that the damage is not covered under the terms of the warranty, or if the warranty has expired, an estimate for the cost of the repairs at standard rates will be provided. Upon receipt of the owner’s approval to proceed, the instrument will be repaired and returned.
- Page 18 Warranty [no content intended for this page] VeriDri™ User’s Manual...
- Page 19 Panametrics 1100 Technology Park Drive Billerica, MA 01821 declare under our sole responsibility that the VeriDri™ Moisture Transmitter to which this declaration relates, is in conformity with the following standards: • EN 61326-1: 2006, Class A, Table 2, Industrial Locations •...
- Page 20 [no content intended for this page]...
- Page 22 Customer Support Centers U.S.A. 1100 Technology Park Drive Billerica, MA 01821-4111 Web: mstechsupport@bakerhughes.com Ireland Sensing House Shannon Free Zone East Shannon, Co. Clare Ireland E-mail: mstechsupport@bakerhughes.com Copyright 2021 Baker Hughes company. This material contains one or more registered trademarks of Baker Hughes Company and its subsidiaries in one or more countries.
