CT Labs Testing Report: Polycom SoundStation2W
Testing Setup:
H
For the Small Conference Room Test Setup (shown in Figure 1), one male tester was located in a separate
office using a desktop phone with a handset to communicate with four testers (2 male and 2 female) located in
the conference room diagrammed above.
Wireless Test Setup
Office #2
Base Unit
For the Wireless Test Setup (shown in Figure 2), the base unit and the wireless phone unit were placed in the
interior of the CT Labs test facilities building, where a total of five walls separated the base unit from the wire-
less phone unit. Two testers (1 male, 1 female) performed the manual speech quality assessment. Tests in-
cluded two scenarios (1) a wireless router and a laptop placed several feet apart from each other with the con-
ference unit in between while the laptop was performing file transfers, and (2) the same setup but with the
wireless router and laptop wireless disabled. Both the router and the laptop were set to use first 802.11b, then
802.11g during the tests.
Small Conference Room
Test Setup
A B
31"
50"
76" CU
12"
50"
Laptop
G
F
Base
Unit
Figure 1: Small Conference Room Test Setup
Office #1
Desktop
Telephone
35 feet
50 feet
Figure 2: Wireless Test Setup
Page 2 of 6
18'-6 5/8"
Ceiling Height = 9'
C
51"
24"
51"
E
21'-5 3/8"
Conference Room
CU
2.5
feet
Laptop computer
D
2.4 GHz
2.5
Wireless
feet Router
