WMF coffeemachines
WMF 1300 S planning information
Open manual insert
Cleaning and manual
insert
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF GmbH | WMF Platz 1 | 73312 Geislingen (Steige)
Optional: vending unit
Card reader width 130 mm
Coin Checker and coin changer 105
mm
Card reader and coin
changer height 502 mm
Coin Checker height 462
mm
Optional: cut-out for lines and
hoses (water, waste water, power)
min. Ø60
Optional
feet
Pipe for grounds
disposal 70 X 120 x
250 mm
(extension with
second pipe possible)
Fix water connection
On site
Other power classes see countryspecific user manual
Length app.
Power depending on version
On site
µ
Optional: milk hose
through counter only
for Smart Milk
Optional: cut-out for
grounds through
counter
Advertisement
Related Manuals for WMF 1300S
Summary of Contents for WMF 1300S
- Page 1 Smart Milk Optional: cut-out for grounds through counter On site Other power classes see countryspecific user manual Length app. Power depending on version On site http://www.wmf-kaffeemaschinen.de/fachplaner WMF GmbH | WMF Platz 1 | 73312 Geislingen (Steige)
- Page 2 For operating, service, and safety reasons the machine should be installed with a clearance from Clearance the building or non-WMF components of not less than 50 mm at the sides and 60 mm at the back. A minimum working space of 800 mm in front of the coffee machine is recommended.
- Page 3 For connection from below through the counter a cut-out must be made in the hatched area on-site according to drawing (see top view). For drinking water with carbonate hardness above 5°dKH (carbonate hardness), a WMF water filter should be fitted upstream.
- Page 4 For more information as the instruction manual , safety data sheets and certificates , see: http://mediacenter.wmf.com/servicecenter/ All information refers to coffee machines/ equipment as standard version. Individual solutions can differ from the standard version. http://www.wmf-kaffeemaschinen.de/fachplaner WMF GmbH | WMF Platz 1 | 73312 Geislingen (Steige)
