  • Page 1 Razor Operator’s Manual Models Návod k obsluze 911373 – Push (SN 055000 +) Betriebsanleitung 911375 – Self-Propelled Instruktionsbog (SN 055000 +) Lea el Manual del operador 911379 – Self-Propelled, Electric Start Käyttäjän käsikirja (SN 055000 +) Manuel de l'opérateur Manuale d'uso Gebruikershandleiding Brukerhåndbok Instrukcja obsługi...
  • Page 2 ÖVERENSSTÄMMELSE UTFÄRDAD AV TILLVERKAREN – ÜRETİCİ TARAFINDAN DÜZENLENEN EC UYGUNLUK BEYANI We the undersigned, ARIENS COMPANY, certify that: My, nížepodepsaní, ARIENS COMPANY, prohlašujeme, že: Der Unterzeichnete, ARIENS COMPANY, bescheinigt, dass: Undertegnede, ARIENS COMPANY, attesterer, at: Nosotros, los abajo firmantes, ARIENS COMPANY, certificamos que: Allekirjoittanut, ARIENS COMPANY, vakuuttaa, että: Nous, soussignés ARIENS COMPANY, certifions que: La sottoscritta società...
  • Page 3 / Director Product Conformance Päivämäärä – Date – & Warranty (Archivar der technischen Akte) / Direktør for Data – Datum – Dato – Ariens Company produktoverholdelse & garanti (indehaver af teknisk fil)/ Data – Data – дата – Brillion, WI 54110-1072 USA Director de conformidad de los productos y de garantía...

  • Page 4: Table Of Contents

    Clean Grass Bag ....17 ariens.com. Wash Deck..... . . 18...

  • Page 5: Welcome

    WELCOME Original Instructions. Congratulations on your purchase and welcome to the Ariens family! Every machine in the Ariens lineup is designed for long-lasting and unsurpassed performance. We are confident your machine will be part of your family for many years to come.

  • Page 6: Safety

    Emission controls and components manual. Read and understand all safety can only be adjusted by an Ariens Company messages. dealer or an authorized engine 1. Danger manufacturer's service center.

  • Page 7: Safety Decals

    5. Important 1.1 Amputation Hazard IMPORTANT: Indicates general reference information worthy of special attention. To avoid amputation hazard SAFETY DECALS DO NOT put hands near rotating blades. The safety decals on your machine are visual reminders of the important safety information in this manual.

  • Page 8: Safety Rules

    Improper use of power equipment can cause 1.3 Tipping Hazard serous permanent injury or death to the operator or a bystander. SERIOUS INJURY OR Understand: DEATH MAY RESULT • How to operate all controls FROM MACHINE ROLLOVER • The functions of all controls •...
  • Page 9 NEVER modify or adjust as necessary or have the unit remove safety devices. inspected and repaired by an authorized Ariens dealer before using. DO NOT pull machine backward unless absolutely necessary. ALWAYS look down Be sure the area is clear of bystanders and behind before and while moving before operating.
  • Page 10 Stop the engine (motor) and wait until the DO NOT mow wet grass or excessive steep blade(s) comes to a complete stop before slopes. Poor footing could cause a slip and cleaning the machine, removing grass fall accident. catcher, or unclogging the discharge guard. DO NOT operate near drop-offs, ditches, or On self-propelled models, wheel drive must embankments.
  • Page 11 Use only Ariens Company-recommended attachments that are appropriate to your use Transporting Unit and can be used safely in your application. Use extra care when loading or unloading the machine onto a truck or into a trailer.

  • Page 12: Assembly

    ASSEMBLY CAUTION: AVOID INJURY. Read and understand the Safety section before proceeding. PACKAGE CONTENTS See Figure 3. Figure 4 3. Rotate handlebar to desired position and secure with mounting hardware. See Figure 5. 1. Mower 2. Side Discharge Chute 3. Mulch Plug 4.

  • Page 13: Controls & Features

    CONTROLS & FEATURES Figure 6 1. Operator Presence Control (OPC) Lever 8. Side Discharge Cover 2. Wheel Drive Control Lever (Models 9. Side Discharge Chute 911375, 911379) 10. Fuel Tank and Cap 3. Handlebar 11. Oil Fill / Dipstick 4. Cutting Height-Adjustment Lever 12.

  • Page 14: Operator Presence Control (Opc) Lever

    See engine and blade within 3 seconds. If feature Wash Deck on page 18. fails, see your Ariens dealer. REAR DOOR Opens to collect grass clippings while bagging or to install mulch plug for side discharge or mulching setup.

  • Page 15: Wheel Drive Control Lever

    87. DO NOT use E85 blended fuels; the engine is not E20 / E30 / E 85 compatible. The maximum recommended ethanol content is 10%. Ariens recommends using a quality fuel stabilizer in all fuel. See Short-Term Storage on page 25.
  • Page 16 CAUTION: If clog or obstruction prevents grass discharge, stop engine, wait for moving parts to stop and for hot parts to cool before clearing obstruction. Bag Grass Clippings CAUTION: Bag wears from normal use. Check bag frequently for wear and replace if necessary. 1.
  • Page 17 See Figure 13. 7. Slowly release side discharge cover and allow it to rest on discharge chute. 3. Lift rear door and install mulch plug. IMPORTANT: Mulch plug locks into position. Mulch Grass Clippings Ensure that mulch plug is secure by gently 1.

  • Page 18: Adjust Cutting Height

    ADJUST CUTTING HEIGHT 1. Stop engine, wait for all moving parts to stop and for hot parts to cool. 2. Pull cutting height-adjustment lever out of notch and rotate to desired setting. See Figure 16. Figure 17 • For storage, rotate handlebar completely forward and reinstall hardware.

  • Page 19: Operation

    Models 911375, 911379 OPERATION See Figure 19. 1. Push OPC lever forward and raise or lower handlebar to desired position. CAUTION: AVOID INJURY. Read 2. Release OPC lever and move handlebar and understand the Safety section up or down slightly until it locks in desired before proceeding.

  • Page 20: Mow Grass

    Pull handle firmly and quickly with a rapid, continuous full-arm stroke. Your Ariens dealer can provide service and c. Repeat until engine starts. If engine adjustments to keep your unit operating at does not start, see Troubleshooting peak efficiency.

  • Page 21: Service Parts

    SERVICE PARTS See your Ariens dealer to purchase service parts for your unit. Description Part No. Air Filter 21100120 Spark Plug 21100122 Figure 21 Blade 04544400 CHECK ENGINE OIL Battery 04765800 (Model 911379) NOTICE: Engine oil level MUST be maintained at correct level or engine damage...

  • Page 22: Wash Deck

    IMPORTANT: If water leaks from coupler, coupler is not secure. 6. Open water-supply valve. 7. Start engine and engage mower blade. Keep blade engaged until water color under deck changes from green to clear. See Start the Engine on page 15. 8.
  • Page 23 DO NOT sharpen to this pattern. Sharpen to this pattern. Figure 25 Sharpen Blade See Figure 26. CAUTION: AVOID INJURY. DO NOT sharpen blade while attached to unit. DISCARD if more than 1.3 cm (1/2"). 1. Remove mower blade. Discard blade if: 1.

  • Page 24: Check Drive Belt

    Install Blade 1. Lubricate the first 4 – 5 bolt threads with SAE 30-weight oil. See Figure 28. 2. Position blade against blade adapter and secure with one flat steel washer, locking washer and hex bolt. NOTICE: Blade MUST be installed with cutting edges positioned upward.

  • Page 25: Service & Adjustments

    CONTROL (OPC) LEVER The OPC lever is non-adjustable. If engine and / or blade does not stop within 3 seconds Figure 31 of releasing the OPC lever, see your Ariens dealer. See Figure 32. 4. Loosen jam nuts on cable adjustment barrel.

  • Page 26: Battery Service

    BATTERY SERVICE Remove Battery 1. Stop engine, remove key, wait for all Model 911379 moving parts to stop and for hot parts to cool. CAUTION: AVOID INJURY. Battery posts, terminals and 2. Disconnect spark plug wire. related accessories contain lead 3.
  • Page 27 See Figure 35. 6. Remove hardware retaining battery bracket and remove bracket. 7. Remove battery. Figure 35 Install Battery 1. Reinstall battery with terminals positioned to the right. 2. Reinstall battery bracket over battery and secure with two tapping screws. 3.

  • Page 28: Troubleshooting

    (Models of adjustment. Lever on page 21. 911375, 911379) Wheel bearings damaged. See your Ariens dealer. Debris caught in gears. See your Ariens dealer. Drive belt slips or speed is See Adjust Wheel Drive Control Lever on too slow. page 21 or replace drive belt. Refer to the service guide for your unit.

  • Page 29: Storage

    ACCESSORIES 6. Prepare fuel system for storage. NOTICE: Ariens recommends using a quality See your Ariens dealer for a complete list of fuel stabilizer in all fuel. Gasoline left in the compatible accessories and attachments for fuel system without a stabilizer, even for short your unit.

  • Page 30: Specifications

    SPECIFICATIONS Model Number 911373 911375 911379 Self-Propelled, Push Self-Propelled Description Electric Start Subaru EA175 Engine 175.0 (10.7) Displacement – cm Maximum RPM – No load. 2750 ± 50 Crank Case Capacity – L (oz) 0.59 (20.0) Air Cleaner Paper Element Oil Filter Engine Oil Refer to engine manual.

  • Page 31: Warranty

    Register the product immediately at the time of sale. If the dealer does not register the product, the customer must complete the product registration card in the literature package and return it to the Ariens Company, or register the unit online at www.ariens.com, www.gravely.com, www.countax.com.
  • Page 32 Exclusions – Items Not Covered by This Warranty • Parts that are not genuine Ariens, Gravely or Countax service parts are not covered by this warranty and may void the warranty. • Damages resulting from the installation or use of any part, accessory, or attachment which is not approved by the Ariens Company for use with product(s) identified herein are not covered by this war- ranty.
