Dual Frequency Body Composition Monitor
with integrated Bluetooth technology
RD-953
en
Instruction Manual
Please read this Instruction Manual carefully and keep it for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Tanita innerScan DUAL

Summary of Contents for Tanita innerScan DUAL

  • Page 1 Dual Frequency Body Composition Monitor with integrated Bluetooth technology RD-953 Instruction Manual Please read this Instruction Manual carefully and keep it for future reference.

  • Page 2: Table Of Contents

    Table of Contents Introduction …………………………………………………… 3 Features and Functions ………………………………………… 3 For Your Safety ………………………………………………… 4 Getting Accurate Readings ……………………………………… 5 Preparations before Use ………………………………………… 6 Connecting to Your Smartphone ……………………………… 7 Setting (Resetting) Date and Time ……………………………… 8 Setting and Storing Personal Data in the Memory ……………… 9 Taking Measurements ………………………………………...

  • Page 3: Introduction

    Thanks to major investment in the latest BIA Technology and sports science research, TANITA has upgraded the Athlete Mode function to make measurements more accurate and suitable for a wider range of users. Who should use Athlete Mode? Adults aged 18 years and over who either: ・Train or exercise for 12 hours or more a week and have been doing so for at least six months.

  • Page 4: For Your Safety

    For Your Safety This section explains precautionary measures to be taken to avoid injury to the users of this device and others, and to prevent damage to property. Please familiarise yourself with this information to ensure safe operation of this equipment. Warning Failure to follow instructions highlighted with this mark could result in death or severe injury.

  • Page 5: Getting Accurate Readings

    Place the monitor on a hard, flat surface where there is minimal vibration to ensure safe and accurate measurement. Avoid excessive impact or vibration to the monitor. Doing so may damage the monitor or cause it to malfunction,or may cause setting to be erased. Do not use or store this monitor in the following locations.

  • Page 6: Preparations Before Use

    Preparations before Use Inserting the Batteries Note: ・Be sure that the batteries are inserted in the correct orientation. If the batteries are  inserted incorrectly, fluid may leak from the batteries and damage the floor. ・If you do not intend to use this unit for a long period of time, remove the batteries  before storage.

  • Page 7: Connecting To Your Smartphone

    Turn the Bluetooth setting on, and use the URL to download the Health Planet app. http://www.tanita.asia/innerscandual/rd953.htm Note: ・See the Tanita website for details on supported models. ・If you do not wish to use the dedicated app, configure the settings manually  on the body composition monitor. (P.8) ・You need to register your smartphone again if you replace your smartphone.

  • Page 8: Setting (Resetting) Date And Time

    Setting (Resetting) Date and Time (Not required if connection to the smartphone is complete) 1. Set Date While the power is off, press the button to start setting. Press the buttons to set year and then press the button. Set the month and date in the same way. Note: •...

  • Page 9: Setting And Storing Personal Data In The Memory

    Setting and Storing Personal Data in the Memory (Not required if connection to the smartphone is complete) The Body Composition Monitor can only be operated if data has been programmed into one of the personal data memories. Only weight measurements can be taken if you use the Body Composition Monitor without registering personal data. 1.
  • Page 10 Setting and Storing Personal Data in the Memory 5. Measuring Your Body Composition Check “0.00kg” (0.0lb, 0.0stlb) is shown on the display, then step on the monitor. Registered personal data and the measurement results are displayed in order, then the power switches off automatically.

  • Page 11: Taking Measurements

    Taking Measurements When the monitor power is off, select "Input Data" in the app and then follow the instructions in the app. When “0.00kg” (0.0lb, 0.0stlb) is displayed, step onto the monitor. Measurement data is automatically sent to the smartphone. If there is unsent data stored on the monitor, that data is also sent to the smartphone.
  • Page 12 Taking Measurements You can start taking measurements when you have finished entering your personal data. 1. Step onto the Monitor Step onto the monitor when the power is off. The monitor starts measuring automatically. 2. View Your Results After taking measurements, your results are automatically displayed in the order listed on the next page. After the last result data is displayed, the weight is displayed again and then the monitor automatically turns off.

  • Page 13: Measurement Results

    Measurement Results Weight Body Fat % Muscle Mass Muscle Quality Score Basal Metabolic Rating Physique Rating Bone Mass Visceral Fat Metabolic Age Total Body Water % An assessment of your measurement results are indicated by the color of the backlight. Assessment Color (Applicable age) Over / Under Normal range...

  • Page 14: Specifying The Personal Data Number For Measurement

    Specifying the Personal Data Number for Measurement Follow these instructions if the monitor continues to mis-recognize your number. When the power is off, press the  button to start measuring. Select your personal number using the  buttons and then press the   button. Step onto the monitor when “0.00kg”...

  • Page 15: Programming The Guest Mode

    Programming the Guest Mode Guest mode allows you to program the monitor for one-time use without using a personal data number. Press the   button to select "GUEST", then press the  button. Next, follow the steps below: Set the age, gender (male/ female/ male athlete/ female athlete) and height. Step onto the monitor after “0.00kg”...

  • Page 16: Body Composition Guide

    Tanita Body Composition Monitors calculate your body composition using Dual Frequency Bioelectrical Impedance Analysis (BIA). Safe, low-level electrical signals are passed through the body via the Tanita foot pads on the monitor platform. The signal can flow easily through fluids in muscles and other body tissue but meets resistance as it passes through body fat, because body fat only contains a small amount of fluid.
  • Page 17 What Is Body Fat Percentage? (Applicable age 5-99) Body fat percentage is the amount of body fat as a proportion of your body weight. Reducing excess levels of body fat has shown to reduce the risk of certain conditions such as high blood pressure, heart disease, diabetes and cancer.
  • Page 18 Ensuring you have healthy levels of visceral fat may reduce the risk of certain diseases such as heart disease, high blood pressure, and the onset of type 2 diabetes. The Tanita Body Composition Monitor provides you with a visceral fat rating from 1 – 59. Rating 1 - 12.5  ...
  • Page 19 Muscle mass is judged by calculating the amount of muscle mass against the person’s height, and then the amount is classified. The Tanita Health Planet app that links with this device displays the muscle mass judgement as a muscle score, as shown below.
  • Page 20 This person has a lower than average body fat percentage while having above-average muscle mass. Source: Data from Columbia University (New York) & Tanita Institute (Tokyo) Index of amount of muscle against height = Muscle mass (Kg) / height (cm)
  • Page 21 What Is Muscle Quality Score? (Applicable age 18 - 99) Muscle quality score indicates the “quality (state) of muscle” which changes according to factors such as age and fitness. The muscles of young people or those who exercise regularly is normally in a good state, but the state of muscles deteriorates in elderly people or those who do not get enough exercise.
  • Page 22 Below is the result of estimated bone masses of persons aged 20 to 40, who are said to have the largest amounts of bone mass by weight. (Source: Tanita Body Weight Science Institute) Please use the charts below as a guide for comparing your bone mass readings.

  • Page 23: Troubleshooting

    Troubleshooting If the following problems occur, follow the instructions below. “Lo” appears on the display.   Check the orientation of the batteries, and insert them correctly. The batteries are running low. Replace the batteries promptly. Refer to page 6. “OL” appears on the display during use The maximum weight (weighing capacity) 200kg is exceeded.

  • Page 24: Specifications

    ・ The product design and specifications may be changed at any time without prior notice. ・ The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such mark by Tanita Corporation is under license.
