Owner's Guide and Installation Manual
Attach sales receipt to this card and retain as your proof of purchase
DATE OF PURCHASE:
MODEL NUMBER:
To register your fixture, please visit our website www.montecarlofans.com
3RZHR44XXX Series Fan
cETL Model NO. : 3RZHR44XXX
RETAILER NAME:
RETAILER ADDRESS:
4.5 kg
9.9 lbs
Total fan weight
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Monte Carlo Fan Company 3RZHR44 Series
Summary of Contents for Monte Carlo Fan Company 3RZHR44 Series
- Page 1 Owner’s Guide and Installation Manual 3RZHR44XXX Series Fan cETL Model NO. : 3RZHR44XXX Attach sales receipt to this card and retain as your proof of purchase DATE OF PURCHASE: RETAILER NAME: RETAILER ADDRESS: MODEL NUMBER: To register your fixture, please visit our website www.montecarlofans.com 4.5 kg 9.9 lbs Total fan weight...
-
Page 2: Cautions And Warnings
Cautions and Warnings WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70) including fire-rated construction. - Page 3 Outlet box Before you begin installing the fan, Switch Before installing this fan make sure the Use metal outlet box suitable for fan power off at Service panel and lock outlet box is properly installed to the support and use only the screws provided service disconnecting means to prevent house structure.
- Page 4 Black White Wall switch Black Power source White Green/Ground Green Ground/Green White (Neutral) wire from house to White wire from remote marked AC IN N. Black (Live) wire from house to Black wire from remote marked AC IN L. Connect all green grounded wires to Grounded wire from House. Make sure that no filaments are outside of the wire connectors.
- Page 5 Motor Light pan Plate on motor Install the flywheel with blades onto the Loosen 2 and remove 1 preassembled Place the lead wires from fan over the motor. Align the alignment posts on the screw from the plate on motor. Save central hole of light pan flywheel with any 3 holes on the motor screw for later use.
- Page 6 Remote Controller Operation Remove the battery cover from the remote control transmitter and install batteries. DIM (D) Replace the cover. This remote uses 2 1.5V/AAA batteries. ON/OFF (O) Note: If not using for long periods of time, remove battery to prevent damage to remote transmitter, and store the remote transmitter away from excess heat or humidity Dimming, Non Dimming Setting (Only available for fans with light)
- Page 7 Install Transmitter wall mount cradle with 2 screws provided. Useful tips: Take remote transmitter up by pushing it at lower area of the transmitter. The remote transmitter can be held on magnetic metal materials by a magnet built in the transmitter. Wall mount cradle The receiver provides the following protective functions Lock protection- The DC motor has a build-in safety feature...
-
Page 8: Troubleshooting
Troubleshooting or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, installation, please call our Customer Service Center at the number printed on your parts list insert sheet. Warning and lock the service panel to prevent the power from being switched back on accidentally. If the service panel cannot be locked to prevent the power from being switched on accidentally, securely fasten a warning sign to the service panel. - Page 9 Oct.2022...
