- Page 1 Operating manual G 1730 Alarm thermometer Permanently connected sensor Waterproof Precise and fast ...
-
Page 2: Table Of Contents
Table of contents Table of contents About this documentation ......................... 4 Foreword............................... 4 Purpose of the document........................ 4 Legal notices............................ 4 Correctness of content.......................... 4 Layout of this document........................ 4 Further information .......................... 5 Safety .............................. 6 Explanation of safety symbols ...................... 6 Foreseeable misuse .......................... - Page 3 Table of contents Disposal............................. 21 Technical data........................... 22 Spare parts and accessories ...................... 23 Service ............................... 24 12.1 Manufacturer............................ 24 12.2 Repairs ............................... 24 12.3 Sales subsidiaries.......................... 25 B-H86.0.0D.DB2-1.0 3 / 25...
-
Page 4: About This Documentation
1 | About this documentation G 1730 1 About this documentation 1.1 Foreword Read this document carefully and familiarise yourself with the operation of the product before you use it. Keep this document ready to hand and in the immediate vicinity of the product so that it is available to the personnel/user for reference at all times in case of doubt. -
Page 5: Further Information
G 1730 About this documentation | 1 Prerequisite All mandatory prerequisites are then listed for each step. Instruction Tasks to be carried out by the personnel / user are represented as numbered instruc- tions. Adhere to the sequence of the specified instructions. Representation Shows an illustrative instruction or a configuration of the product. -
Page 6: Safety
2 | Safety G 1730 2 Safety 2.1 Explanation of safety symbols DANGER This symbol warns of imminent danger which can result in death, severe bodily injury, or severe property damage in case of non-observance. CAUTION This symbol warns of potential dangers or harmful situations which can cause damage to the device or to the environment in case of non-observance. -
Page 7: Intended Use
G 1730 Safety | 2 CAUTION Erratic behaviour! On suspicion that the product can no longer be operated without danger, it must be decommissioned and prevented from recommissioning with appropriate labelling. The safety of the user can be impaired by the device if, for example, if it shows visible damage, it no longer works as specified or if it was stored for an extended period of time under unsuitable conditions. -
Page 8: Qualified Personnel
2 | Safety G 1730 2.5 Qualified personnel For commissioning, operation and maintenance, the relevant personnel must have ad- equate knowledge of the measuring process and use of the measurements, for which purpose this document makes a valuable contribution. The instructions in this docu- ment must be understood, observed and followed. -
Page 9: Description
G 1730 Description | 3 3 Description 3.1 Scope of delivery Please check to ensure the completeness of the product after opening the package. You should find the following components: – Quick reference guide – Handheld measuring device, ready for operation, including batteries –... -
Page 10: The Product At A Glance
4 | The product at a glance G 1730 4 The product at a glance 4.1 The G 1730 LCD Display G 1730 G 1730 4.2 Display elements Display Battery indicator Evaluation of the battery status Unit display Display of units, if applicable, with unstable symbol or type of mode, min/max/hold Main display Measurement of the current temperature or value... -
Page 11: Operation
G 1730 Operation | 5 5 Operation 5.1 Commissioning 5.1.1 Explanation Description The product is switched on with the On/Off button. It may be necessary to configure the product after switching on. See Configuration [} p. 11]. Prerequisite – Sufficiently full batteries are inserted in the product. Instruction –... -
Page 12: Configuring Parameters Of The Configuration Menu
5 | Operation G 1730 Representation Call up menu Next parameter Change value Save changes Discard changes Press: Single step Hold: Rapid change Outcome of an action The Configuration menu is closed after the last parameter. NOTE If the product is switched off without saving the configuration, the last save value is re- produced on the next start-up of the product. -
Page 13: Adjustment Of The Measuring Input
G 1730 Operation | 5 Backlighting L,TE Backlighting deactivated Automatic shut-off of the backlighting after a selec- 15 30 60 120 240 ted time in seconds, during which no buttons have been pressed No automatic shut-off of the backlighting Temperature unit UN,T Temperature display in °C °(... -
Page 14: Configuring Parameters Of The Adjustment Menu
5 | Operation G 1730 5. In order to save the new parameter value, press and hold the Function key for longer than 1 second. Representation Call up menu Hold Release Outcome of an action The Configuration menu is closed after the last parameter. NOTE If the product is switched off without saving the configuration, the last save value is re- produced on the next start-up of the product. - Page 15 G 1730 Operation | 5 – Display in water bath 36.6 °C – Display in water bath setpoint T.SL = 37.0 °C – T.OF = display zero point correction – setpoint zero point – T.OF = -0.2 °C – 0.0 °C = -0.2 °C –...
-
Page 16: Bases For Measurement
6 | Bases for measurement G 1730 6 Bases for measurement 6.1 Possible measuring errors 6.1.1 Immersion depth Liquids Immerse to a depth of at least 20 mm and then stir. Otherwise, measuring errors can occur due to the heat transmission of the sensor tube if the immersion depth is too shallow. -
Page 17: Maintenance
G 1730 Maintenance | 7 7 Maintenance 7.1 Operating and maintenance notices NOTE The product and temperature probe must be handled with care and used in accord- ance with the technical data. Do not throw or strike. NOTE If the product is stored at a temperature above 50 °C, or is not used for an extended period of time, the batteries must be removed. -
Page 18: Calibration And Adjustment Service
7 | Maintenance G 1730 NOTE Read the following handling instructions before replacing batteries and follow them step by step. If disregarded, the product could be damaged or the protection from moisture could be diminished. Description Proceed as follows to replace the batteries. Prerequisites –... - Page 19 G 1730 Maintenance | 7 NOTE The product is delivered with a test report. This confirms that the measuring device has been adjusted and tested. NOTE Only the manufacturer can check the basic settings and make corrections if neces- sary. B-H86.0.0D.DB2-1.0 19 / 25...
-
Page 20: Error And System Messages
8 | Error and system messages G 1730 8 Error and system messages Display Meaning Possible causes Remedy No suitable measur- Incorrect measuring Connect a suitable measur- ---- ing probe connected probe ing probe Measurement far Measuring probe or Measurement leaves the outside of the meas- product defect permissible range... -
Page 21: Disposal
The valid legal regulations and directives applicable at the time must be observed. NOTE Fill in the return form available from the information base online at www.ghm-group.de and sent it in with the product. NOTE The device must not be disposed of with household waste. -
Page 22: Technical Data
10 | Technical data G 1730 10 Technical data Measuring range temperature -70.0 .. +250.0 °C (-94.0 .. +482.0 °F) Accuracy temperature -20 .. +100 °C: ±0.1 K ±1 digit otherwise: ±0.2 % of measured value ± 2 digits Response time T90 water (0.4 m/s) approx. -
Page 23: Spare Parts And Accessories
G 1730 Spare parts and accessories | 11 11 Spare parts and accessories A selection of spare parts and accessories for this product is listed below. Article Number Name Description 610049 Mignon battery Mignon AA spare battery 611373 ST-G1000 Device protection bag with 1 round cut-out A complete list of all accessories and spare parts is available in our product catalogue or on our home page. -
Page 24: Service
GHM Messtechnik GmbH Hans-Sachs-Str.26 Service Centre 93128 Regenstauf | GERMANY Phone: +49 94029383-39 Fax: +49 94029383-33 service@greisinger.de NOTE Fill in the return form available from the information base online at www.ghm-group.de and sent it in with the product. 24 / 25 B-H86.0.0D.DB2-1.0... -
Page 25: Sales Subsidiaries
12.3 Sales subsidiaries Austria Brazil & Latin America Czech Republic / Slovakia GHM Messtechnik GmbH GHM Messtechnik do Brasil Ltda GHM Greisinger s.r.o. Office Austria Av. José de Souza Campos, 1073, cj 06 Ovci hajek 2 / 2153 Breitenseer Str. 76/1/36...
