Summary of Contents for GHM Delta OHM HD2101.1
- Page 1 English Operating manual Hygrometers / thermometers HD2101.1 – HD2101.2 Companies / Brands of GHM www.deltaohm.com Keep for future reference.
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..............................3 KEYBOARD AND MENU DESCRIPTION ......................8 THE PROBES ................................14 ........................14 EASUREMENT OF RELATIVE HUMIDITY Calibration of the combined humidity/temperature probe ...................14 Humidity and Comfort indices ...........................16 Pt100, Pt1000 Ni1000 T ..............18 IRECT INPUT INTO EMPERATURE PROBES How to measure ..............................18 Instructions to connect the TP47 connector for 4 wire Pt100, Pt1000 and Ni1000 probes ........18 Direct connection of 4 wire Pt100 sensors ......................20... -
Page 3: Introduction
INTRODUCTION The HD2101.1 and HD2101.2 are portable instruments with a large LCD display. They measure relative humidity and temperature using a Pt100 sensor or thermocouple humidity/temperature combined probe. Temperature only is measured by immersion, penetration or air contact probes. The sensor can be a Pt100, Pt1000 or Ni1000. When the combined humidity/temperature probe is connected, the instrument calculates and displays the absolute humidity, the dew point, the partial vapour pressure, and the comfort indices. - Page 4 Hygro-Thermometer HD2101.1 - 4 - HD2101 V2.3...
- Page 5 HD2101.1 1. Input for probes, 8-pole DIN45326 connector. 2. External auxiliary power supply connector input. 3. Battery symbol: displays the battery charge level. 4. Functions indicators. 5. Secondary display line. 6. HOLD/ key: freezes the measurement during normal operation; in the menu, increases the current value.
- Page 6 Hygro-Thermometer HD2101.2 - 6 - HD2101 V2.3...
- Page 7 HD2101.2 1. Input for probes, 8-pole DIN45326 connector. 2. External auxiliary power supply connector input. 3. Battery symbol: displays the battery charge level. 4. Main display line. 5. Secondary display line. 6. HOLD/ key: freezes the measurement during normal operation; in the menu, increases the current value.
-
Page 8: Keyboard And Menu Description
KEYBOARD AND MENU DESCRIPTION Foreword The instrument keyboard is composed of single-function keys, like the MENU key, and double- function keys such as the ON-OFF/Auto-OFF key. In the double-keys, the function in the upper part is the "main function", while the one in the bottom part is the "secondary function". - Page 9 The automatic turning off function is disabled when external power is used. On the other hand, it cannot be disabled when the batteries are discharged. FUNC/ENTER key During normal measurement this enables the display and logging of the maximum (MAX), minimum (MIN) and average (AVG) value of the measurements captured by the probe connected to the instrument, updating them with the acquisition of new samples.
- Page 10 %RH probe calibration Simultaneous pressure on the UNIT and FUNC keys starts the calibration procedure of the probe connected to the instrument. Please see the paragraph dedicated to calibration on page 14. °C/°F - ESC key Changes the unit of measurement for the temperature from degrees Celsius to Fahrenheit for both the main and secondary variable.
- Page 11 2) Probe type: the message ">>>_PRBE_TYPE" is scrolled in the comment line. The main line in the center of the display shows the type of probe connected to the instrument. The following probes can be connected to the input: • humidity/temperature combined probes with Pt100 sensor complete with SICRAM module •...
- Page 12 9) MIN (minutes): to set the current minutes. In order to correctly synchronize the minute, it is possible to reset the seconds by pressing the UNIT key. Use the arrows to set the current minute plus one, and as soon as that minute is reached press UNIT: this synchronizes the time to the second.
- Page 13 The printing operation is accompanied by the display of the RS232 symbol and the blinking of the battery symbol; when using an external power supply the battery symbol does not appear. Press SERIAL to end the continuous printing. Before starting the printing with SERIAL, set the baud rate. To do so, select the Baud Rate menu item and select the maximum value equal to 38400 baud by using the arrows.
-
Page 14: The Probes
THE PROBES The instrument works by using combined humidity/temperature probes (temperature with a Pt100 sensor or thermocouple) and with temperature only probes with 4 wire Pt100, or 2 wire Pt1000 or Ni1000. The combined humidity/temperature probes are fitted with SICRAM module that acts as an interface between the sensor on the probe and the instrument. - Page 15 The probes are calibrated in our laboratory at 23°C at the points of 75%RH, 33%RH and 11.4%RH. On request, the probes can be checked at different isotherms. The calibration of the temperature sensor by the user is not required: the sensor is calibrated in the factory and the Callendar Van Dusen parameters are recorded in the SICRAM module.
-
Page 16: Humidity And Comfort Indices
this case the chamber cannot reach its saturation anymore. For the saturated solutions at 75%RH, check that the salt is not dry (crystallized) for in order to reach the saturation, it needs to be wet 5) Storage of the saturated solutions: the saturated solutions must be stored in a dark environment at a constant temperature of about 20°C with the container well closed inside a dry room Relative humidity of saturated salts at different temperatures Temp... - Page 17 According to the value supplied by the DI index (Discomfort Index), the climatic conditions range from comfortable to somewhat annoying, and then intolerable: Comfortable Not very annoying Annoying Very annoying Intolerable There are four possible causes of local discomfort: • high vertical difference of temperature •...
-
Page 18: Direct Input Into Pt100, Pt1000 And Ni1000 Temperature Probes
Pt100, Pt1000 and Ni1000 T IRECT INPUT INTO EMPERATURE PROBES The instrument accepts the input of Platinum temperature probes with resistances of 100Ω and 1000Ω, as well as Nickel temperature probes with a 1000Ω resistance. The Pt100 are connected to 4 wires, the Pt1000 and Ni1000 to 2 wires, with the excitation current chosen minimizing the sensor self-heating effects. - Page 19 Open the two module shells: the printed circuit to which the probe must be connected is housed inside. On the left there are the 1…4 points on which the sensor wires must be welded. The JP1…JP4 jumpers are in the center of the board. These must be closed with a tin bead for some type of sensors: Not Used Ni1000...
-
Page 20: Direct Connection Of 4 Wire Pt100 Sensors
Direct connection of 4 wire Pt100 sensors 4 wire Pt100 sensors can be soldered di- Sensor Direct soldering to the connector rectly to the pins of the free female con- nector without making use of the TP47 board. The 4 wires of the Pt100 sensors have to be soldered as indicated in the figure on the left. -
Page 21: Warnings And Operating Instructions
WARNINGS AND OPERATING INSTRUCTIONS 1. Do not expose the probes to gases or liquids that could corrode the material of the sensor or the probe itself. Clean the probe carefully after each measurement. 2. Do not bend the probe connectors or force them upward or downward. 3. -
Page 22: Instrument Signals And Faults
INSTRUMENT SIGNALS AND FAULTS The following table lists all error indications and information displayed by the instrument and supplied to the user in different operating situations: Display indications Explanation This appears if the probe has already been detected by the instrument, but is disconnected. - Page 23 The following table reports the indications provided by the instrument as they appear on the display, together with their description. Display indications Explanation >>>_LOG_DUMP_or_ERAS transfer or erase data >>>_PRBE_TYPE type of probe connected battery discharged - replace it immediately BATT TOO LOW - CHNG NOW baud rate value BAUDRATE >>>...
-
Page 24: Low Battery Warning And Battery Replacement
LOW BATTERY WARNING AND BATTERY REPLACEMENT The battery symbol on the display constantly shows the battery charge status. To the extent that batteries have discharged, the symbol "empties". When the charge decreases still further it starts blinking… In this case, batteries should be replaced as soon as possible. If you continue to use it, the instrument can no longer ensure correct measurement. -
Page 25: Instrument Storage
ALFUNCTIONING UPON TURNING ON AFTER BATTERY REPLACEMENT After replacing the batteries, the instrument may not restart correctly; in this case, repeat the operation. After disconnecting the batteries, wait a few minutes in order to allow circuit condensers to discharge completely; then reinsert the batteries. ARNING ABOUT BATTERY USE •... -
Page 26: Serial Interface And Usb
SERIAL INTERFACE AND USB The HD2101.1 and HD2101.2 instruments are fitted with an electrically isolated RS-232C serial interface; the HD2101.2 also has a USB 2.0 interface. The following serial cables can be used: • HD2110CSNM: serial connection cable with 8-pole MiniDin connector on one end and 9-pole Sub D connector on the other end;... - Page 27 Command Response Description M=Thermo-Hygrometer Model description SN=12345678 Instrument serial number Firm.Ver.=01-00 Firmware version Firm.Date=2004/06/15 Firmware date cal 0000/00/00 00:00:00 Calibration date and time Probe=Sicram RH-Pt100 Type of probe connected to input Probe SN=11119999 Probe serial number Probe cal.=2004/01/12 Probe calibration date User ID=0000000000000000 User code (set with T2xxxxxxxxxxxxxxxx) Print instrument's heading...
-
Page 28: Storing And Transferring Data To A Personal Computer
STORING AND TRANSFERRING DATA TO A PERSONAL COMPUTER The HD2101.1 and HD2101.2 instruments can be connected to a personal computer via an RS232C serial port or USB 2.0 port, and exchange data and information through the DeltaLog9 software running in a Windows operating environment. Both models can send in real time input measured values directly to a PC, through the PRINT function;... -
Page 29: The Print Function
PRINT FUNCTION The PRINT function sends the measurements taken in real time by the instrument inputs directly to a PC or a printer. Print data units of measurements are the same as those used on the display. The function is started by pressing SERIAL. The time interval between two consecutive prints can be set from 1 second to 1 hour (please see the Print and log interval menu item on page 10). -
Page 30: Connection To A Pc
CONNECTION TO A PC HD2101.1 Connection to the PC with the cable: • HD2110CSNM: 8-pole MiniDin connector on one end and 9-pole Sub D connector on the other end; • C.206: 8-pole MiniDin connector on one end and USB type A connector on the other end. With integrated RS232/USB converter (requires the installation of the USB drivers). -
Page 31: Notes About Working And Operating Safety
NOTES ABOUT WORKING AND OPERATING SAFETY Authorized use The technical specifications as given in chapter "TECHNICAL CHARACTERISTICS" must be ob- served. Only the operation and running of the measuring instrument according to the instructions given in this operating manual is authorized. Any other use is considered unauthorized. General safety instructions This measuring system is constructed and tested in compliance with the EN 61010-1:2010 safety regulations for electronic measuring instruments. -
Page 32: Instrument Technical Characteristics
INSTRUMENT TECHNICAL CHARACTERISTICS Instrument Dimensions (Length x Width x Height) 185x90x40mm Weight 470g (complete with batteries) Materials ABS, rubber Display 2x4½ digits plus symbols Visible area: 52x42mm Operating conditions Working temperature -5…50°C Stocking temperature -25…65°C Working relative humidity 0…90%RH without condensation Protection degree IP66 Power Supply... - Page 33 USB interface - model HD2101.2 Type 1.1 - 2.0 electrically isolated Connections Input module for the probes 8-pole male DIN45326 connector RS232 serial interface 8-pole MiniDin connector USB interface (only HD2101.2) Mini-USB type B connector Mains adapter (cod. SWD10) 2-pole connector (positive at centre) Relative humidity measurement Measurement range 0…100%RH...
-
Page 34: Technical Data Of Probes And Modules In Line With The Instrument
ECHNICAL DATA OF PROBES AND MODULES IN LINE WITH THE INSTRUMENT Pt100 EMPERATURE PROBES SENSOR USING SICRAM MODULE Model Type Application range Accuracy ±0.25°C (-196°C…+300°C) TP472I Immersion -196°C…+500°C ±0.5°C (+300°C…+500°C) TP472I.0 Immersion -50°C…+300°C ±0.25°C 1/3 DIN – Thin Film ±0.25°C (-50°C…+300°C) TP473P.I Penetration -50°C…+400°C... -
Page 35: Relative Humidity And Temperature Probes Using Sicram Module
ELATIVE HUMIDITY AND TEMPERATURE PROBES USING SICRAM MODULE Application range Accuracy Temperature Model sensor Temperature Temp. HP472ACR Pt100 0…100%RH -20°C…+80°C ±0.3°C HP572ACR Thermocouple K 0…100%RH -20°C…+80°C ±0.5°C ±1.5% (0…90%RH) Pt100 0…100%RH -20°C…+80°C ±2% (90…100%RH) ±0.3°C HP473ACR Pt100 0…100%RH -40°C…+150°C ±0.3°C HP474ACR @ T=15…35°C Pt100... -
Page 36: Order Codes
ORDER CODES HD2101.1 The kit includes the instrument HD2101.1, 4 x 1.5V alkaline batteries, operating manual, case and DeltaLog9 software. HD2101.2 The kit includes the HD2101.2 datalogger, 4 x 1.5V alkaline batteries, operating manual, case and DeltaLog9 software. Probes, saturated solutions and cables have to be ordered separately. HD2110CSNM Connection cable 8-pole MiniDin –... - Page 37 TP49AC.I Contact probe, sensor Pt100. Stem Ø 4 mm, length 150 mm. Cable length 2 metres. Aluminium handle. TP49AP.I Penetration probe, sensor Pt100. Stem Ø 2.7 mm, length 150 mm. Cable length 2 metres. Aluminium handle. TP875.I Globe-thermometer Ø 150 mm with handle. Cable length 2 metres. TP876.I Globe-thermometer Ø...
- Page 38 SICRAM EMPERATURE PROBES WITHOUT MODULE TP47.100.O Immersion probe, sensor Pt100 direct 4 wires. Probe's stem Ø 3mm, length 230mm. 4-wire connection cable with connector, length 2 metres. TP47.1000.O Immersion probe, sensor Pt1000. Probe's stem Ø 3mm, length 230mm. 2-wire connection cable with connector, length 2 metres. TP87.100.O Immersion probe, sensor Pt100 direct 4 wires.
- Page 40 GU AR AN T E E TERMS OF GUARANTEE All DELTA OHM instruments are subject to accurate testing, and are guaranteed for 24 months from the date of purchase. DELTA OHM will repair or replace free of charge the parts that, within the warranty period, shall be deemed non efficient according to its own judgement.
- Page 41 GHM GROUP – Delta OHM | Delta Ohm S.r.l. a socio unico Via Marconi 5 | 35030 Caselle di Selvazzano | Padova | ITALY Phone +39 049 8977150 | Fax +39 049 635596 www.deltaohm.com | info@deltaohm.com The quality level of our instruments is the result of the constant development of the product. This may produce some differences between the information written in this manual and the instrument you have purchased.
- Page 42 GHM GROUP – Delta OHM | Delta Ohm S.r.l. a socio unico Via Marconi 5 | 35030 Caselle di Selvazzano | Padova | ITALY Phone +39 049 8977150 | Fax +39 049 635596 www.deltaohm.com | info@deltaohm.com V2.3 28/08/2017...
