- Page 1 Compact manual G 1700 series Alarm thermometer...
-
Page 2: Table Of Contents
Table of contents G 1700 series Table of contents About this documentation ............4 Foreword ..................4 Legal notices .................. 4 Further information ................. 4 Safety ..................5 Explanation of safety symbols ............5 Foreseeable misuse ............... 5 Safety instructions ................6 Intended use ................... - Page 3 G 1700 series Table of contents Battery ..................14 6.2.1 Battery indicator................14 6.2.2 Changing battery ................14 Error and system messages ..........16 Disposal ................. 17 Technical data ............... 18 Service ................... 20 10.1 Manufacturer ................20 10.2 Calibration and adjustment service ..........20 B-H86.0.0X.DK2-3.1 3 / 20...
-
Page 4: About This Documentation
1 | About this documentation G 1700 series About this documentation Foreword Read this document carefully and familiarise yourself with the operation of the device before you use it. Keep this document ready to hand and in the immediate vicinity of the device so that it is available to the personnel/user for reference at all times in case of doubt. -
Page 5: Safety
G 1700 series 2 | Safety Safety Explanation of safety symbols DANGER This symbol warns of imminent danger, which can result in death, severe bodily injury, or severe property damage in case of non-observance. CAUTION This symbol warns of potential dangers or harmful situations, which can cause damage to the device or to the environment in case of non-observance. -
Page 6: Safety Instructions
2 | Safety G 1700 series Safety instructions CAUTION Risk of injury at the temperature sensor! Devices with insertion probes entail the risk of stab injuries due to the pointed probe design. – Handle insertion probes with care! – Fit a protective cap on the measuring probe if probe is not in use! There is a risk of burns when measuring in high (and very low) temperatures. -
Page 7: Intended Use
G 1700 series 2 | Safety Intended use The device is a water-protected thermometer. It is designed for precise and instanta- neous temperature measurements in the following media: – Food – Liquids – Gases – Soft plastic materials – Bulk material Qualified personnel For commissioning, operation and maintenance, the relevant personnel must have adequate knowledge of the measuring process and the significance of the measure-... -
Page 8: The Device At A Glance
3 | The device at a glance G 1700 series The device at a glance Top view G 1700|-01 LCD Display Front view Display elements Battery indicator Evaluation of the battery status Unit display Display of units or type of mode, min/max/hold Measurement of the current temperature or value Main display for min/max/hold... -
Page 9: Operating Elements
G 1700 series 3 | The device at a glance Operating elements On / Off button Press briefly Switch on the device Activate / deactivate lighting Long press Switch off the device Reject changes in a menu Up / Down button Display of the min/max value Press briefly Change value of the selected parameter... -
Page 10: Operation
4 | Operation G 1700 series Operation Opening the configuration menu Press the Function key for 2 seconds to open the Configuration menu. (ONF appears in the display. Release the Function key. Parameter Values Meaning Alarm No alarm active Alarm via text insertion, acoustic signal and flashing of the background lighting BEEP Alarm via text insertion and acoustic signal... - Page 11 G 1700 series 4 | Operation POFF Shut-off time No automatic shut-off 15, 30, 60, 120, 240 Automatic shut-off after a selected time in minutes, during which no buttons have been pressed L,TE Backlight Backlight deactivated 15, 30, 60, 120, 240 Automatic shut-off of the backlight after a selected time in seconds, during which no buttons have been pressed No automatic shut off of the backlight...
-
Page 12: Adjustment Of The Measuring Input
4 | Operation G 1700 series Adjustment of the measuring input The temperature input can be adjusted with the zero point correction and the gradient correction. If an adjustment is made, you change the pre-adjusted factory settings. This is signalled with the display text T.OF or T.SL when switching on. Switch the device off. -
Page 13: Measurement Basics
G 1700 series 5 | Measurement Basics Measurement Basics Sensor/device accuracy The device can be equipped with different interchangeable sensors. The temperature sensors are divided into the following classes according to EN 60751. class deviation temperature range -50 … +500 °C ±0,3 °C ±0,5 % of measured value -30 …... -
Page 14: Operation And Maintenance
6 | Operation and maintenance G 1700 series Operation and maintenance Operating and maintenance notices NOTE The device and temperature probe must be handled with care and used in accordance with the technical data. Do not throw or strike. NOTE Plugs and sockets must be protected from soiling. - Page 15 G 1700 series 6 | Operation and maintenance CAUTION Damage! If the batteries have different charge levels, leaks and thus damage to the device can occur. – Only use high-quality and suitable alkaline batteries! – Do not use different types of batteries! –...
-
Page 16: Error And System Messages
7 | Error and system messages G 1700 series Error and system messages Display Meaning Possible causes Remedy ---- No suitable meas- Incorrect or no Connect a suitable meas- uring probe con- measuring probe uring probe nected Measurement far Measurement Stay within allowable outside of the outside of the... -
Page 17: Disposal
G 1700 series 8 | Disposal Disposal Separation by material and recycling of device components and packaging must take place at the time of disposal. The valid regional statutory regulations and directives applicable at the time must be observed. NOTE The device must not be disposed of with household waste. -
Page 18: Technical Data
9 | Technical data G 1700 series Technical data G 1700, G 1701 Measuring range -200.0 .. +450.0 °C (-328.0 .. +842.0 °F). Observe the permissible range of application of the sensor that is used! Accuracy -20 .. +100 °C: ± 0.1 K ± 1 digit Other range: ±... - Page 19 G 1700 series 9 | Technical data Adjustment Offset and gradient correction Housing Break-proof ABS housing Protection rating IP65 / IP67 (only with sensors identified as waterproof in the connected state for devices with BNC socket) Dimensions L*W*H 108 * 54 * 28 mm, without BNC socket or kink protection Weight ~ 130 g incl.
-
Page 20: Service
Service 10.1 Manufacturer If you have any questions, please do not hesitate to contact us: Contact: GHM Messtechnik GmbH GHM GROUP - Greisinger Hans-Sachs-Str. 26 93128 Regenstauf | GERMANY Email: info@greisinger.de | www.greisinger.de WEEE reg. no. DE 93889386 10.2 Calibration and adjustment service The purpose of the calibration is to verify the precision of the measuring device by comparing it with a traceable reference.
