The transmitters included with the security system have been pre-programmed
at the factory, with each button pre-assigned to control a specific function of the
security system. Although the security system in the vehicle has either a 3 or 4
channel receiver, depending on the model, the transmitters included with the
system are capable of transmitting 7 distinct signals. This allows you to program
each transmitter to more than one vehicle in two car families, and also allows you
to change which button(s) control certain functions of the system.
(Example: Transmitter channel 5 can be programmed to activate Receiver
channel 2.) Refer to the chart below for access to each of the transmitter channels,
and for the standard factory button assignments.
TRANSMITTER
CHANNEL
BUTTON
CHANNEL
1
1
2
2
3
or
3
4
&
4
5
&
5
6
&
6
All 3
7
7
Buttons
Some of the more common accessories for these additional channels are;
AS 9554
AS 9075
AS 9153
AS 9256
Revision A: Added Pad # 73 for Circuit City Program
on last page
Revision B Added reference for PBLED 6/06
TRANSMITTER
PROGRAMMING GUIDE
Model : OE3B4
SYSTEM RECEIVER
FUNCTION
Remote Arm
Remote Emergency Panic
Remote Door Lock
Remote Disarm
Remote Emergency Panic
Remote Door Unlock/Unlock 2
Single Push Pulsed Output for Optional Accessory
Or Double Push For Additional Optional Accessory
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
RF Channel For Options
RF Channel For Options
Remote Garage Door Interface
Remote car starter
Remote window roll up
Remote trunk release relay
128-6505B
1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUTO SECURITY Prestige OE3B4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Audiovox AUTO SECURITY Prestige OE3B4

  • Page 1 TRANSMITTER PROGRAMMING GUIDE Model : OE3B4 The transmitters included with the security system have been pre-programmed at the factory, with each button pre-assigned to control a specific function of the security system. Although the security system in the vehicle has either a 3 or 4 channel receiver, depending on the model, the transmitters included with the system are capable of transmitting 7 distinct signals.
  • Page 2 PROGRAMMING THE TRANSMITTERS: It is important to remember that during program- ming, each individual step of the procedure must be executed within 15 seconds of the previous step. When the 15 second time limit is allowed to expire, the system will automatically terminate the programming mode.
  • Page 3 15. The dash LED will flash four times, and the sounding device will beep four times, indicating the system is ready to accept programming for receiver's channel 4. 16. Press and hold any button combination as shown on the front cover of this guide until the sounding device emits a long beep, indicating the signal has been stored into memory.
  • Page 4 10. Mail this form, and your check, to : Audiovox Electronics Corp., 150 Marcus Blvd. Hauppauge, N.Y., 11788 Attn.: TRANSMITTER DEPARTMENT © 2006 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY, 11788 128-6505B 128-6505B 4 of 4...

This manual is also suitable for:

Prestige oe3b4sPrestige oe3b4s72prPrestige oe3b4s73Prestige oe3b4s71
