TRANSMITTER PROGRAMMING GUIDE

The transmitters included with the security system have been pre-programmed at the
factory, with each button pre-assigned to control a specific function of the security
system. Although the security system in the vehicle has either a 3, 4 or 5 channel
receiver, depending on the model, the transmitters included with the system are
capable of transmitting 7 distinct signals. This allows you to program each transmitter
to more than one vehicle in two car families, and also allows you to change which
button(s) control certain functions of the system.
(Example: Transmitter channel 5 can be programmed to activate Receiver channel 2.)
Refer to the chart below for access to each of the transmitter channels, and for the
standard factory button assignments.
TRANSMITTER
CHANNEL
BUTTON
CHANNEL
1
1
2
2
3
3
4
&
4
5
&
5
6
&
6
All 3
7
7
Buttons
Some of the more common accessories for these additional channels are;
AS 9554
AS 9075
AS 9153
AS 9256
Model: OE3-FT3
SYSTEM RECEIVER
FUNCTION
Remote Arm
Remote Emergency Panic
Remote Door Lock
Remote Disarm
Remote Emergency Panic
Remote Door Unlock/Unlock 2
Single Push Pulsed Output for Optional Accessory
Or Double Push For Additional Optional Accessory
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
Single Push Pulsed Output for Optional Accessory
Or Push And Hold For Extended Output
RF Channel For Options
RF Channel For Options
Remote Garage Door Interface
Remote car starter
Remote window roll up
Remote trunk release relay

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit OE3-FT3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Audiovox Pursuit OE3-FT3

  • Page 1 RF Channel For Options Buttons Some of the more common accessories for these additional channels are; AS 9554 Remote Garage Door Interface AS 9075 Remote car starter AS 9153 Remote window roll up AS 9256 Remote trunk release relay Model: OE3-FT3 FUNCTION...
  • Page 2 PROGRAMMING THE TRANSMITTERS It is important to remember that during programming, each individual step of the procedure must be executed within 15 seconds of the previous step. When the 15 second time limit is allowed to expire, the system will automatically terminate the programming mode.
  • Page 3 16. Press and hold any button combination as shown on the front cover of this guide until the sounding device emits a long beep, indicating the signal has been stored into memory. 17. If you have additional transmitters (up to 4) that need to be programmed, repeat step 16 for each transmitter.
  • Page 4 Simply dial 1 - 800 - 645 - 4994, and follow the instructions from the operator interface. 10. Mail this form, and your check, to ; Audiovox Electronics Corp., 150 Marcus Blvd. Hauppauge, N.Y., 11788 Attn.: TRANSMITTER DEPARTMENT 128-5759...
