MEASUREMENTS
90
85
80
75
70
65
Figure 8. Frequency responses on the horizontal plane. Off-axis angle indicated
in degrees.
90
75
60
45
30
15
0
−15
−30
−45
−60
−75
−90
100
Figure 9. Horizontal directivity plot of the 4410A. Colour bar indicates dB level.
14
4410A (2021−06−02)
100
Frequency (Hz)
4410A horizontal plane, normalized with on−axis
1k
Frequency (Hz)
1k
10k
10k
0
−3
−6
−9
−12
−15
−18
−21
