IBM 4 U Rack Mount Tape Enclosure
Installation Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4 U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IBM 4 U

Summary of Contents for IBM 4 U

  • Page 1 IBM 4 U Rack Mount Tape Enclosure Installation Guide...
  • Page 3 IBM 4 U Rack Mount Tape Enclosure Installation Guide...
  • Page 4 Note: Before using this information and the product it supports, read the general information in Appendix A, “IBM Statement of Limited Warranty Z125-4753-09 08/2006,” on page 23 and the notices information in Appendix B, “Notices,” on page 39. First Edition (October 2007) ©...
  • Page 5 Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza. Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. © Copyright IBM Corp. 2007...
  • Page 6 2. First, remove power cords from outlet. 3. Attach signal cables to connectors. 3. Remove signal cables from connectors. 4. Attach power cords to outlet. 4. Remove all cables from devices. 5. Turn device ON. IBM 4 U Rack Mount Tape Enclosure: Installation Guide...

  • Page 7: Table Of Contents

    Chapter 1. Introduction ..... . 1 The IBM Documentation CD ....1 Notices and statements in this document .
  • Page 8 IBM 4 U Rack Mount Tape Enclosure: Installation Guide...

  • Page 9: Chapter 1. Introduction

    The tape enclosure comes with a limited warranty. For information about the terms of the warranty, see Appendix A, “IBM Statement of Limited Warranty Z125-4753-09 08/2006,” on page 23. You can obtain up-to-date information about the tape enclosure at http://www.ibm.com/support/.

  • Page 10: Notices And Statements In This Document

    The following notices and statements are used in this document: v Note: These notices provide important tips, guidance, or advice. v Important: These notices provide information or advice that might help you avoid inconvenient or problem situations. IBM 4 U Rack Mount Tape Enclosure: Installation Guide...
  • Page 11 v Danger: These statements indicate situations that can be potentially lethal or extremely hazardous to you. A danger statement is placed just before the description of a potentially lethal or extremely hazardous procedure step or situation. Chapter 1. Introduction...

  • Page 12: Specifications

    Parts list The enclosure is a Tier 1 customer replaceable unit (CRU). Replacement of Tier 1 CRUs is your responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged for the installation. For more information about the terms of the warranty and getting service and assistance, see Appendix A, “IBM Statement of Limited Warranty Z125-4753-09...
  • Page 13 Table 1 lists the replaceable components. Table 1. CRU list Description CRU part number Enclosure 40K2586 SCSI accessory kit 42C3917 SAS accessory kit 42C3918 SCSI cable (3 m external) 42C3941 Slide rails 25R0016 PDU power cord 39M5377 SAS cable (3 m external) 43W8496 SCSI ID converter 43W8472...
  • Page 14 IBM 4 U Rack Mount Tape Enclosure: Installation Guide...

  • Page 15: Chapter 2. Installing The Tape Enclosure

    Unpacking the enclosure and accessory cartons The following illustrations show the items that come with the IBM 4 U Rack Mount Tape Enclosure and accessory option kits. Notes: 1.
  • Page 16 Note: You can use the SAS accessory kit to install either a SAS drive or a SATA drive in the tape drive enclosure. SAS signal connector and screws External SAS cable Figure 3. SAS accessory kit contents IBM 4 U Rack Mount Tape Enclosure: Installation Guide...

  • Page 17: Installation Guidelines For Rack-Mount Enclosures

    Note: You can use the USB accessory kit to install either a USB drive or a SATA drive in the tape drive enclosure. USB-to-SATA converter External USB cable USB signal connector and screws Internal USB cable Figure 4. USB accessory kit contents Installation guidelines for rack-mount enclosures Review the documentation that comes with your rack cabinet for safety and cabling information.

  • Page 18: Setting Up The Enclosure And Installing A Drive

    9, and the safety documentation that comes with your rack cabinet. Loosen the six screws on the top of the enclosure; then, remove the cover from the enclosure. IBM 4 U Rack Mount Tape Enclosure: Installation Guide...
  • Page 19 Install the slide rails on the enclosure. (The six 10-32 x 3/8-inch screws are provided in the miscellaneous hardware bag.) Attach the adjustable rear-rack rails to the front-rack rails. (The four 10-32 x 1/2-inch screws and nuts are provided in the miscellaneous hardware bag.) Chapter 2.
  • Page 20 Insert and tighten eight M5 screws to secure both slide-rail assemblies. Cage nuts Front Rear IBM 4 U Rack Mount Tape Enclosure: Installation Guide...
  • Page 21 Install the signal connectors: Remove the cover plates from the rear of the enclosure. For a SCSI drive, use the tip of a pen or a straightened paper clip to set the ID on the SCSI ID connector. The rear of the enclosure is marked “0” through “8”, just above the openings for the SCSI ID connectors.
  • Page 22 Remove the filler panel from the front of the enclosure. c. Slide the drive into the enclosure; then, insert and tighten four screws to secure the drive. (The four screws come with the drive.) Filler panel IBM 4 U Rack Mount Tape Enclosure: Installation Guide...
  • Page 23 Connect the cables to the rear of the drive. For SCSI and SAS option kits, see Figure 5. For USB option kits, see Figure 6 on page 16. SCSI ID Power Alignment key Power SCSI SCSI Power SATA SATA Figure 5. Internal cable connections using SCSI and SAS option kits Chapter 2.
  • Page 24 (30.5 cm) USB cable that came with the USB option kit to connect the USB-to-SATA converter to the USB signal connector Power Power USB-to-SATA converter SATA USB drive SATA drive Figure 6. Internal cable connections using a USB option kit IBM 4 U Rack Mount Tape Enclosure: Installation Guide...
  • Page 25 Install the cover on the enclosure and tighten the six screws. Install the tape enclosure in the rack: a. Extend both slide rails out of the rack cabinet until they lock. b. Align the rails on the sides of the enclosure with the slide rails in the rack cabinet;...
  • Page 26 2. First, remove power cords from outlet. 3. Attach signal cables to connectors. 3. Remove signal cables from 4. Attach power cords to outlet. connectors. 5. Turn device ON. 4. Remove all cables from devices. IBM 4 U Rack Mount Tape Enclosure: Installation Guide...
  • Page 27 Attach the external cables to the enclosure: Attach the signal cable to the host; then, connect the other end of the signal cable to the connector on the rear of the enclosure. Connect the power cord to the enclosure; then, connect the power cord to a properly grounded electrical outlet.
  • Page 28 IBM 4 U Rack Mount Tape Enclosure: Installation Guide...

  • Page 29: Chapter 3. Getting Help And Technical Assistance

    If you need help, service, or technical assistance or just want more information about IBM products, you will find a wide variety of sources available from IBM to assist you. This section contains information about where to go for additional information about IBM and IBM products, what to do if you experience a problem with your system, and whom to call for service, if it is necessary.

  • Page 30: Software Service And Support
