User Guide
Power Supply
Mains Supply
Tracing Mode
Trace Frequency
Gain control knob
Offset control knob
Volume control knob
Mechanical
Dimensions
Weight
IP class
Approvals
Environment
Power Supply
Mains Supply
Tracing Mode
Trace Frequency
Volume control knob
Other
Mechanical
Dimensions
Weight
IP class
Approvals
Environment
BC421332622232en-010101
DEVItector™ II V2
Magnetic tracer on crutch unit
4 x 1,5 V⎓, battery type AA
1,8 kHz
Adjust to control amplification of tracer signal
Used to compensate for induction of a signal reflected by
the pointer indicator.
Adjustment of sound in headphones and ON/OFF unit
160 × 300 × 970 mm
1,5 kg
IP20
The equipment has been tested by Intertek according to
EN/IEC 61010-1 with amendments, EN/IEC 61010-2-030
with amendments and EN/IEC 61326-1 with amendments.
For HVU tracer mode: indoor and outdoor use.
Temperature range: 5 ºC to 40 ºC.
Magnetic tracer - Hand held unit
1 x 9 V⎓, battery type PP3 / 6F22 / 6LF22
1,8 kHz
Adjustment of sound in headphones and ON/OFF unit
65 x 105 x 40 mm
0,2 kg
IP20
The equipment has been tested by Intertek according to
EN/IEC 61010-1 with amendments, EN/IEC 61010-2-030
with amendments and EN/IEC 61326-1 with amendments.
For HVU tracer mode: indoor and outdoor use.
Temperature range: 5 ºC to 40 ºC.
