MANUAL
ENGLISH
EVO 4T/EVO 5T/EVO 6T/EVO 8T
V1
Ordercode: D3680/D3681, D3682/D3683, D3684/D3685, D3686/D3687
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVO 4T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DAPAudio EVO 4T

  • Page 1 MANUAL ENGLISH EVO 4T/EVO 5T/EVO 6T/EVO 8T Ordercode: D3680/D3681, D3682/D3683, D3684/D3685, D3686/D3687 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 EVO 4T – D3680 (Black) / D3681 (White) ........................5 EVO 5T – D3682 (Black) / D3683 (White) ........................5 EVO 6T – D3684 (Black) / D3685 (White) ........................5 EVO 8T –...
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: ● 2 x DAP Audio EVO 4T/EVO 5T/EVO 6T/EVO 8T ● 2 x mounting bracket ●...
  • Page 4: Operating Determinations

    EVO 4T/EVO 5T/EVO 6T/EVO 8T ● Do not open the device and do not modify the device. ● Do not set the input signal level higher than required to drive the equipment to full output. ● Only use system indoors, avoid contact with water or other liquids.
  • Page 5: Return Procedure

    EVO 4T/EVO 5T/EVO 6T/EVO 8T Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
  • Page 6: Description Of The Device

    EVO 4T/EVO 5T/EVO 6T/EVO 8T Description of the device Features EVO 4T – D3680 (Black) / D3681 (White) EVO 5T – D3682 (Black) / D3683 (White) ● ● Speaker system: 2-way, full range 100V Speaker system: 2-way, full range 100V ●...
  • Page 7: Installation

    Do not attempt to operate a 120V specification product on 230V power, or vice versa. 100V Mode 01) Turn the controls on the rear of the speakers to select the desired power tap: 2/4/8/16W (EVO 4T/5T), 4/8/16/32W (EVO 6T) or 6,25/12,5/25/50W (EVO 8T). It will also determine the volume. The higher the setting, the higher the volume.
  • Page 8: Conventional Amplifier Mode

    EVO 4T, EVO 5T or EVO 6T. 04) If you are using the EVO 8T, connect the power amplifier to the speakers, using a speaker cable. EVO 4T, EVO 5T, EVO 6T Setup Example Fig. 03 EVO 8T Setup Example Fig.
  • Page 9: Maintenance

    EVO 4T/EVO 5T/EVO 6T/EVO 8T Maintenance The DAP Audio EVO requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents.
  • Page 10: Product Specifications

    EVO 4T/EVO 5T/EVO 6T/EVO 8T Product Specifications EVO 4T – D3680 (Black) / D3681 (White) EVO 5T – D3682 (Black) / D3683 (White) ● Speaker system: 2-way, full range 100V ● Speaker system: 2-way, full range 100V ● Impedance: 8 Ω...
  • Page 11: Dimensions

    EVO 4T/EVO 5T/EVO 6T/EVO 8T Dimensions EVO 4T EVO 5T EVO 6T EVO 8T Ordercode: D3680/D3681, D3682/D3683, D3684/D3685, D3686/D3687...
