Maintenance
* The oscilloscope displays a clock symbol when the flash drive is active, and a hint line when a save or recall operation is complete.
Figure 6- - 7: Oscilloscope troubleshooting tree (4 of 4)
6- - 24
Install a compatible
USB flash drive in
the front--panel port
Does the
No
flash drive
blink?*
Yes
Examine the
contents of the
flash drive through
the file controls
Does
the data
No
match what is
visible on the
PC?
Yes
Check that the
TekVISA software
(OpenChoice PC
Communications) is
installed on the PC
Connect the
oscilloscope to
the PC
Transfer data from
the oscilloscope to
the PC
E
From Figure 6-4
Replace the
Main board
Does the data
No
match what is
visible on the
oscilloscope?
Yes
Good oscilloscope
